Short press to skip song
Press and hold to turn
the volume up(+)
/
Power On/Off:
Hold power button for 3 seconds
to switch SB517 on and 5 secondsturn off.
Built-in Microphone
for phone calls.
pick up or hang up a phone call.
Press and hold 3 seconds to redial the last number.
/
Play/Pause
the music
Short press to previous song
Press and hold to turn
the volume down(-)
SB517 Quick Start Guide & User Manual
PRODUCT FEATURE
SAFETY INSTRUCTIONS
PACKAGE CONTENTS
All trade names are registered trademarks of respective manufacturers listed.
Bluetooth technology and trademark are registered property of Bluetooth SIG.
All rights reserved.
RECHARING THE DEVICE
1. Release the DC 5V charging port cover.
2. Connect the USB charging cable to a standard USB charging
port such as computer or USB charger from the DC 5V socket
on SB517.
SB517 Speaker
USB Charging Cable
User Manual
Suction Cup
Bluetooth: V3.0 + EDR
Range: 10 meters
Transmitting Frequency: 2.4GHz
Charging Input: DC 5V/100-120mA
Battery Capacity: 600 mAh
Charging Time: Approximately 3 Hours
Playback Time: Approximately 6 Hours
Waterproof Grade: IPX7
Net Weight: Approximately 5 oz or 135 gram
SPECIFICATIONS
TROUBLE SHOOTING
Keep the unit away from heat sources. Direct sunlight, humity, water and
any other liquids. Do no operate the unit if it has been exposed to water,
moisture or any other liquids to prevent against electric shock, explosion
and/or injury to yourself and damage to the unit.
Do not use the unit if it as been dropped or damaged in any way.
Do not puncture or disassemble the exterior surface of the product in any way.
Keep the unit free from dust, lint, etc. Do not use this unit for anything other
than its intended use or purpose. Doing so may damage the device.
Keep the product out of reach of children. Do not use the headset at
excessive levels as this may damage hearing.
Do not expose batteries or battery pack to excessive heat, such as direct
sunlight or open flame.
www.SoundBot.com
KEY FUNCTION
Volume down / Previous
Press and hold to turn down the volume.Short press to play the previous
song.
Volume up / Next
Press and hold to turn up the volume.Short press to skip song.
Play or pause the music
Pick up or hang up the call.
Press twice to redial the last number.
Power On: Hold the Power button for 3 seconds to switch SB517 on
and 5 seconds turn off.
The Bluetooth speaker is powered by a built-in
rechargeable lithium battery that can be oprated by
the following steps
Symptoms
Causes
Solutions
SB517 cant be
powered on
Not able to pair
w/ the speaker Volume too low
Low battery level
SB517 is already
on or not to the
pairing mode
Battery is not charged
up or Volume is not set
to the maximum on
SB517 & media player
Recharge
the
battery
Refer to Bluetooth
pairing section in
the previous page
Increase the volume via
press & hold the volume
up button on SB517
Increase the volume on
the Media Players.
To enter to the pairing mode, first be sure that SB517
is in power off mode. Press and hold the on/off button
on SB517 for 6 seconds until the LED light blinks in blue
papidly.
Activate the bluetooth device search function from
the media players such as smartphone, tablets, or
music players.
Choose device name “SB517” from the list of bluetooth
devices discovered and pair with the media player.
Enter password “0000” if appliable.
The blue LED light will flash approximately once per
second indicating When the pairing is successful and
connected to the Bluetooth.
BLUETOOTH PAIRING
