Használati útmutató SoundBot SB1011

SoundBot hangszóró SB1011

Olvassa el alább 📖 a magyar nyelvű használati útmutatót SoundBot SB1011 (7 oldal) a hangszóró kategóriában. Ezt az útmutatót 4 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra

Letöltés PDF
Oldal 1/7
www.soundbot.com
Soundbot is a registered trademark and property. Other trademark and
trade names are those of their respective owners. All rights reserved.
SB1011 Quick Start Guide & User Manual
Feel the Vibe, Live the Moment, Rock with SoundBot.
Music is the soul to your ears. For good time and bad
- happy and sad - we believe that every moment deserves
a song. Whether you're celebrating anniversary or getting
through adversity, there's a song that transcends the
moment. At SoundBot, our mission is to enhance your
overall experience through quality, technology and value.
PRODUCT FEATURE
1
USB
Charging Port
Power Input
3.5mm Aux Audio Line-in
Temperature
Sensor
Time Button:Set-Adjust Time-Stop Alarm
Change Mode
Temperature button:
Adjust between Celsius and
Fahrenheit
Alarm Setting Button
Hours Minutes Microphone
Temperature
Wireless/FM Mode
-
+SNOOZE Press “SNOOZE” to
Adjust LED Display Brightness.
Play/Pause
Multi-Function
Alarm On/Off Indicator
2
FEATURES
BUILT-IN MIC
FOR HANDS-
FREE TALKING
BUILT-IN
3.5mm
AUDIO PORT
ALARM
CLOCK
STEREO 3W + 3W
AUDIO SPEAKER
2.1A USB
CHARGING
PORT
WIRELESS
CONNECTIVITY
FROM 33’ AWAY
THERMOMETER
LED
DATE&TIME
DISPLAY
FM RADIO
TUNER W/ ONE
TOUCH SCAN
DC 5V AUX
SB1011
5V 2.1A
TIME
12/24
ALARM
MODE
TMPERATUR
F C
12/24
Made in China
3
TEMPERATURE & TIME CONFIGURATION
The included AC adapter is required to operate SoundBot SB1011. Do not
use other power source with SB1011 for safety reason. Using other adapter
may short circuit the components of the speaker and void the warranty.
Time Setting
The LED clock will display random time initially. Press “ TIME ” button once
to switch the clock display between 12 hour mode and 24 hour mode. Once
the desired setting is configured, press & hold “ TIME ” button for 2 seconds
to confirm the hour mode setting, followed by flashing “ HOUR ” LED display.
Press “ ” or “ ” touch sensory button on the top side of SB1011 to adjust ＋ －
the HOUR setting and “ TIME ” button again to confirm the HOUR setting,
followed by flashing “ MINUTE ” LED display. Press “ ” / “ ” to configure ＋ －
the “ MINUTE “ setting and press and hold " TIME " button again for 2
seconds to confirm the “ MINUTE ” setting.
Tips: SB1011 will exits time setting automatically after 15 seconds of idle.
Temperature Setting
Press TEMPERATURE button to switch Fahrenheit or Celsius.
Tips: The heat generated from internal circuit board of SB1011 during
operation may result plus or minus 2 degree difference than the
actual temperature.
4
ALARM SETTING
Press & hold “Alarm” button to enter the alarm setting. The lower right corner
of LED screen will display “ON” or “OFF ”. Press “+” or “ ” to activate or －
deactivate the alarm. Press & hold the “ALARM” button again to configure the
alarm setting. The alarm LED indicator will turn to solid to represent active
mode. Configuration sequence goes by ON/OFF SETTING ---> TIME SETTING.
To Wake Up via FM RADIO
When alarm is set to “On” position, press & hold the " SNOOZE " touch sensory
button on top of SB1011 to choose wake up by FM radio or alarm alert. "A"
represents Alarm and "F" represents FM radio. Press the “ALARM” button
again to confirm and complete the alarm setup. The setting sequence goes
by ON/OFF ---> snooze button for A(ALARM) / F(FM RADIO)
SETTING ---> TIME SETTING
Alarm Time Setting Configuration: Press & hold “ALARM” button to enter
alarm time setup, followed by flashing “HOUR” figure on the LED display.
Press “ ” / “ ” to adjust the HOUR and then press "ALARM“ button again ＋ －
to configure the hour setup. Repeat the same process for the minutes setting.
Press & hold "ALARM" button to complete the configuration of the alarm
setting. (Tips: SB1010 will exit alarm setting automatically after 15 seconds
of idle time).
When alarm goes off, press & hold the“ SNOOZE ” button to snooze for 5
minutes. The alert can last for 1 hour at 5 minutes of internvals. To pause the
alarm in the middle of the snooze cycle, press any of “TIME” / “ALARM” /
“MODE” / “TEMPERATURE” buttons to set off the alarm. After the alarm is
paused, it will be re-activated again after 24 hours.
