Datasheet WBE510D
The WBE510D is the BE6500 (2.4GHz: 2x2:2, 5 or 6GHz: 4x4:2) dual-radio access
point, offering blazingly fast WiFi 7 speeds of up to 6.5Gbps. With its built-in
dual-optimized antennas, it provides the most effective solution to ensure
smooth and consistently fast service to each client at all times, whether wall-
mounted or ceiling-mounted.
With two additional antennas in the 5GHz/6GHz bands compared to other
dual-radio (2x2 + 2x2) AP models on the market, it extends coverage range
and boosts performance. Its flexible BandFlex radio can support either 5GHz
or 6GHz by configuration, making it the most economical choice for fitting
into your existing 5GHz coverage while future-proofing the use of 6GHz.
Coupled with Zyxel Nebula’s extensive suite of management and security
innovations, it guarantees robust connectivity and reliability to meet today’s
secure connectivity demands. The WBE510D with NebulaFlex Pro provides
users with complete flexibility to switch between standalone, on-premises
controller, or intuitive Nebula cloud-managed modes as needed. It comes
bundled with a 1-year Nebula Professional Pack license, eliminating upfront
licensing costs when transitioning to full-featured cloud management.
WBE510D
BE6500 WiFi 7 Dual-Radio NebulaFlex Pro Access Point
BE6500 (2.4GHz: 2x2:2, 5 or
6GHz: 4x4:2) dual-radio access
point offers blazingly fast WiFi
7 speeds of up to 6.5Gbps,
ensuring lower latency for real-
time responsiveness
BandFlex design supports
either 5GHz or 6GHz by
configuration, fitting seamlessly
into existing 5GHz coverage
while futureproofing for 6GHz
The dual-optimized antenna
offers wall and ceiling mounting
modes to accommodate your
deployment needs
WiFi 7’s MLO enables
simultaneous data transmission
across 2.4GHz, 5GHz, and
6GHz bands, boosting
speed, reducing latency, and
enhancing reliability
Advanced Cellular Coexistence
minimizes interferences from
4G/5G cellular networks
NebulaFlex Pro allows users to
switch between standalone, on-
premises controller, or intuitive
Nebula cloud managed modes
as needed
2Datasheet WBE510D
Benefits
Bringing next generation WiFi within reach
WiFi 7, also known as IEEE 802.11be, represents the next
evolution in WiFi standards, supporting all three frequency
bands – 2.4GHz, 5GHz, and 6GHz. With its revolutionary
technological advancements, it promises to redefine
the concept of speed, delivering unprecedented rates to
elevate online experiences in the digital realm.
Coupled with Zyxel’s comprehensive range of management
and security innovations, the WBE510D ensures the utmost
connectivity and reliability for demanding enterprise-grade
connectivity.
MLO: Transforming WiFi 7 for unprecedented
connectivity
Fundamentally, one of the most pioneering advancements
of WiFi 7 is the introduction of MLO (Multiple Link
Operation). MLO represents a WiFi technology that
empowers devices linked to a WiFi access point (AP) to
concurrently transmit and/or receive data through various
frequency bands and channels. This entails simultaneous
connections across the 2.4GHz, 5GHz, and 6GHz bands, a
capability absent in earlier WiFi generations where devices
were restricted to a solitary WiFi band connection.
The result is a significant amplification in data throughput,
a reduction in latency, and an enhancement in reliability.
These outcomes undeniably enhance the user experience
and unveil novel opportunities for emerging applications
such as VR/AR, online gaming, remote office setups, and
cloud computing.
Superior performance with innovative
“Dual-optimized” antenna
People without RF expertise may not realize that installing
an AP optimized for ceiling-mount as wall-mount may
cause the ceiling-mount radiation pattern to interfere with
other devices up- or downstairs as well as to deliver signals
with shorter-than-expected range for its clients. Designed
with the innovative “Dual-optimized” antenna, the WBE510D
adapts to both wall- and ceiling-mount installations. Thus,
users can switch between the two optimized antenna
modes easily to fit either situation. To boost WiFi speeds for
your network, the WBE510D is definitely an excellent choice.
RF first by design
The advanced RF filter design eliminates interference
between the 5GHz and 6GHz bands, while the built-in
4G/5G interference filter allows seamless coexistence with
4G/5G cellular networks and minimizes interference, all
of which guarantees a seamless WiFi experience without
interruptions.
Additionally, 4K QAM (MCS-13) requires a good Signal-to-
Noise Ratio (SNR). The rectangular design helps maintain
excellent isolation between antennas, meeting this
requirement more effectively than a circular design.
NebulaFlex Pro – simply manage it your way!
The NebulaFlex Pro provides extended flexibility, allowing
users to easily switch among standalone, on-promises
controller or our intuitive NCC (Nebula Control Center)
modes any time according to your needs without additional
cost while protecting wireless technology investments. The
privilege of one-year professional pack you can get once
upon registration on Nebula includes wireless health, site-
wide topology, 365-day statistics on the devices and clients
monitoring along with more upcoming advanced features
on NCC and its App.
Nebula, the intelligent cloud management
Nebula offers comprehensive monitoring and reporting
capabilities, including real-time notifications for critical
events via the mobile app. With Nebula, you can enjoy
a streamlined experience for network installation and
management, without the need for an additional cost for
software or hardware controllers.
• Automated WLAN management & optimization
With features like WiFi Aid and Wireless health, Nebula
enables automated wireless network management
and optimization, ensuring the best possible WiFi user
experience.
• Enhanced privacy & security
A range of security add-on features like CDR, Secure
WiFi, CNP+, DPPSK, and advanced authentication
methods work together to create a robust and protected
environment for your network.
Optimized wireless experience with advanced
features
The WBE510D ensures an optimized wireless experience for
users with a range of wireless features such as Dynamic
Channel Selection (DCS), Load Balancing and Smart Client
Steering. DCS minimizes the interference of
co-channel and overlapping channels. Load Balancing
enables administrators to set limits on the number of
clients associated with each AP. Furthermore, Smart Client
Steering features with Band Select, Signal Threshold and
Band Balancing combine to deliver stable, reliable wireless
connections. Band Select and Signal Threshold monitor
the capabilities of each wireless client and steer them to
the less-congested band and AP with better signals. Band
Balancing detects dual-radio and triple-radio clients
and distributes clients across 2.4GHz, 5GHz, and 6GHz
bands on AP. All of these deliver a smooth, consistent and
uninterrupted wireless experience to its users.
3Datasheet WBE510D
Internet
Main
Building
Nebula
Control Center
Internet
Traffic
Management
Traffic
Conference Room
Lobby
USG FLEX 200H
USG FLEX Firewall
XMG1915-18EP
16-port 2.5GbE Smart
Managed PoE Switch
with 2 SFP+ Uplink
Video
conferencing
8K
streaming
WBE510D
BE6500 WiFi 7
Dual-Radio
NebulaFlex Pro
Access Point
WBE510D
BE6500 WiFi 7
Dual-Radio
NebulaFlex Pro
Access Point
WBE510D
BE6500 WiFi 7
Dual-Radio
NebulaFlex Pro
Access Point
2.5G PoE Wireless
2.5G Copper
Application Diagram
Specifications
Model WBE510D
Product name BE6500 WiFi 7 Dual-Radio NebulaFlex Pro Access Point
Wireless
Standard IEEE 802.11 be/ax/ac/n/g/b/a
MIMO MU-MIMO
Wireless speed 2.4GHz 688Mbps
5GHz 4324Mbps
6GHz 5764Mbps
Frequency band 2.4GHz • USA (FCC): 2.412 to 2.462GHz
• Europe (ETSI): 2.412 to 2.472GHz
5GHz • USA (FCC): 5.15 to 5.35GHz; 5.470 to 5.850GHz
• European (ETSI): 5.15 to 5.35GHz; 5.470 to 5.725GHz
6GHz • USA (FCC): 5.925 to 6.425GHz; 6.525 to 7.125GHz
• European (ETSI): 5.925 to 6.425GHz
Bandwidth 20-, 40-, 80-, 160-, 240- and 320-MHz
Conducted typical
transmit output power*1
US
(2.4GHz/5GHz/6GHz)
26/28/25dBm
EU
(2.4GHz/5GHz/6GHz)
19/26/22dBm
RF Design
Antenna type Dual-optimized antenna
Antenna gain 2.4GHz 1.49dBi, 2x2:2SS
5GHz 2.78dBi, 4x4:2SS
6GHz 3.17dBi, 4x4:2SS
Minimum receive sensitivity Min. Rx sensitivity up to -99dBm
*1: Maximum transmit power is limited by local regulatory settings.
