Oldal 1/5
Datasheet NWA210BE
Introducing the NWA210BE: a high-performance access point with BandFlex
radio design, harnessing the full capabilities of WiFi 7. It combines easy setup,
flexibility, and high speeds to empower today’s modern, connected offices.
NWA210BE — The BE12300 is a dual-radio access point with 2x2:2 at 2.4GHz
and 4x4:4 at 5 or 6GHz, providing ultra-fast WiFi 7 speeds of up to 12.3Gbps to
boost coverage range and enhance performance.
Its flexible BandFlex radio can support either 5GHz or 6GHz by configuration,
making it the most economical choice to fit into your existing 5GHz coverage
as well as futureproofing the use of 6GHz.
Coupled with Zyxel Nebula’s extensive suite of management and security
innovations, it guarantees robust connectivity and reliability for today’s
modern office demands.
The NWA210BE, equipped with NebulaFlex technology, offers users complete
flexibility to seamlessly switch between standalone mode or the intuitive
Nebula cloud-managed mode as needed.
NWA210BE
BE12300 WiFi 7 Dual-Radio NebulaFlex Access Point
BE12300 (2.4GHz: 2x2:2, 5 or
6GHz: 4x4:4) dual-radio access
point offers blazingly fast
WiFi 7 speeds of up to 12.3Gbps,
ensuring lower latency for
real-time responsiveness
BandFlex design supports
either 5GHz or 6GHz by
configuration, fitting seamlessly
into existing 5GHz coverage
while futureproofing for 6GHz
Dual 2.5GbE ports unlock speeds
beyond gigabit providing a
cost-effective upgrade to enjoy
WiFi 7 performance while
seamlessly integrating with
existing infrastructure
The advanced RF filter prevents
interference between the 5GHz
and 6GHz bands while
guaranteeing performance in
all channels
Can be powered by PoE at
(PoE+) or USB Type C charger to
offer flexible powering options
NebulaFlex allows users to
switch between standalone or
intuitive Nebula cloud managed
modes as needed
2Datasheet NWA210BE
Benefits
Bringing next generation WiFi within reach
WiFi 7, also known as IEEE 802.11be, represents the next
evolution in WiFi standards, supporting all three frequency
bands – 2.4GHz, 5GHz, and 6GHz. With its revolutionary
technological advancements, it promises to redefine
the concept of speed, delivering unprecedented rates to
elevate online experiences in the digital realm.
Coupled with Zyxel’s comprehensive range of management
and security innovations, the NWA210BE ensures the
utmost connectivity and reliability for demanding
enterprise-grade connectivity.
MLO: Transforming WiFi 7 for unprecedented
connectivity
Fundamentally, one of the most pioneering advancements
of WiFi 7 is the introduction of MLO (Multiple Link
Operation). MLO represents a WiFi technology that
empowers devices linked to a WiFi access point (AP) to
concurrently transmit and/or receive data through various
frequency bands and channels. This entails simultaneous
connections across the 2.4GHz, 5GHz, and 6GHz bands, a
capability absent in earlier WiFi generations where devices
were restricted to a solitary WiFi band connection.
The result is a significant amplification in data throughput,
a reduction in latency, and an enhancement in reliability.
These outcomes undeniably enhance the user experience
and unveil novel opportunities for emerging applications
such as VR/AR, online gaming, remote office setups, and
cloud computing.
RF first by design
The advanced RF filter design eliminates interference
between the 5GHz and 6GHz bands, while the built-in
4G/5G interference filter allows seamless coexistence with
4G/5G cellular networks and minimizes interference, all
of which guarantees a seamless WiFi experience without
interruptions.
Additionally, 4K QAM (MCS-13) requires a good Signal-to-
Noise Ratio (SNR). The rectangular design helps maintain
excellent isolation between antennas, meeting this
requirement more effectively than a circular design.
NebulaFlex – simply manage it your way!
NebulaFlex offers extended flexibility, enabling users to
effortlessly switch between standalone mode and our
intuitive cloud-managed NCC (Nebula Control Center)
modes at any time, without incurring additional costs. This
ensures adaptability to changing needs while safeguarding
investments in wireless technology.
Nebula, the intelligent cloud management
Nebula offers comprehensive monitoring and reporting
capabilities, including real-time notifications for critical
events via email or the mobile app. With Nebula, you can
enjoy a streamlined experience for network installation
and management without the need for additional costs for
software or hardware controllers.
• Enhance your WiFi with Nebula
Nebula automates wireless network management and
optimization with features like WiFi Aid and Wireless
Health, ensuring the best possible user experience. These
features enhance network performance and reliability,
delivering an exceptional WiFi experience.
• Smooth and secure wireless experience
The Connect & Protect Plus (CNP+) service is a Nebula-
cloud mode license focused on SB hotspot WiFi scenarios.
It protects network users from cybersecurity threats
and supports application-level network visibility and
bandwidth throttling.
Optimized wireless experience with advanced
features
The NWA210BE ensures an optimized wireless experience
for users with a range of wireless features such as
Dynamic Channel Selection (DCS), Load Balancing and
Smart Client Steering. DCS minimizes the interference of
co-channel and overlapping channels. Load Balancing
enables administrators to set limits on the number of
clients associated with each AP. Furthermore, Smart Client
Steering features with Band Select, Signal Threshold and
Band Balancing combine to deliver stable, reliable wireless
connections. Band Select and Signal Threshold monitor
the capabilities of each wireless client and steer them to
the less-congested band and AP with better signals. Band
Balancing detects dual-radio and triple-radio clients
and distributes clients across 2.4GHz, 5GHz, and 6GHz
bands on AP. All of these deliver a smooth, consistent and
uninterrupted wireless experience to its users.
3Datasheet NWA210BE
Application Diagram
Specifications
Model NWA210BE
Product name BE12300 WiFi 7 Dual-Radio NebulaFlex Access Point
Wireless
Standard IEEE 802.11 be/ax/ac/n/g/b/a
MIMO MU-MIMO
Wireless speed 2.4GHz 688Mbps
5GHz 8646Mbps
6GHz 11530Mbps
Frequency band 2.4GHz • USA (FCC): 2.412 to 2.462GHz
• Europe (ETSI): 2.412 to 2.472GHz
5GHz • USA (FCC): 5.15 to 5.35GHz; 5.470 to 5.850GHz
• European (ETSI): 5.15 to 5.35GHz; 5.470 to 5.725GHz
6GHz • USA (FCC): 5.925 to 6.425GHz; 6.525 to 7.125GHz
• European (ETSI): 5.925 to 6.425GHz
Bandwidth 20-, 40-, 80-, 160-, 240- and 320-MHz
Conducted typical
transmit output power*1
US
(2.4GHz/5GHz/6GHz)
26/28/25dBm
EU
(2.4GHz/5GHz/6GHz)
19/26/22dBm
RF Design
Antenna type Internal antenna
Antenna gain 2.4GHz 1.49dBi, 2x2:2SS
5GHz 2.78dBi, 4x4:4SS
6GHz 3.17dBi, 4x4:4SS
Minimum receive sensitivity Min. Rx sensitivity up to -99dBm
*1: Maximum transmit power is limited by local regulatory settings.
Internet
Main
Building
Nebula
Control Center
Internet
Traffic
Management
Traffic
Conference Room
Office Floor
USG FLEX 200H
USG FLEX Firewall
XMG1915-18EP
16-port 2.5GbE Smart
Managed PoE Switch
with 2 SFP+ Uplink
Video
conferencing
8K
streaming
NWA210BE
BE12300 WiFi 7
Dual-Radio
NebulaFlex
Access Point
NWA210BE
BE12300 WiFi 7
Dual-Radio
NebulaFlex
Access Point
NWA210BE
BE12300 WiFi 7
Dual-Radio
NebulaFlex
Access Point
2.5G PoE Wireless
2.5G Copper
