Oldal 1/8
STANDARD EQUIPMENT
Motor Housing
Tubes
Collection Bag & Shoulder Strap
Wall Support Bracket
Assembly Fasteners x 3
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
No Load Speed: 8,000-14,000/min
Max. Air Speed: 210km/h
Max. Suction Power: 500m/h
Max. Blowing Power: 180m/h
Mulching Ratio: 10:1
Collection Bag: 45 litres
Noise Rating: 98dB
Weight: 3.0kg
BLOWER VAC
ozito.com.au
PXBVS-018
WARRANTY
0524
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts.
OZITO 25 Fox Drive, Dandenong South, Victoria 3175, Australia.
KNOW YOUR PRODUCT SETUP & PREPARATION
1. ASSEMBLY
BRUSHLESS BLOWER VAC
BATTERY & CHARGER
This tool is compatible with all battery and chargers from the Ozito PXC
Range.
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to the
online manual.
ACCESSORIES
a
12345678
11 12
9
10
13
11 14 15
Assembling the Tubes
1. Connect the lower tube onto
the upper tube. Ensure the two
halves latch together fully and
the guide lug (a) sits correctly
in the recess.
2. Secure the tubes together with
the one-way assembly screw
using a at tip screwdriver (not
included).
3. Feed the assembled
suction tubes into the
motor housing. Push
together until they are
connected rmly.
4. Using the two thumb screws secure the suction tubes to the motor
housing.
Note: Integrated safety switches prevent the motor from operation
unless the suction tubes are fully assembled and secured to the motor
housing. If the tubes are not tted and secured against the motor
housing, the safety switch will trip and prevent the motor from working.
WARNING! ENSURE THE BLOWER VAC IS SWITCHED
OFF AND THE BATTERY IS REMOVED BEFORE
PERFORMING ANY OF THE FOLLOWING TASKS.
WARNING! DO NOT USE ANY ATTACHMENTS
OR ACCESSORIES NOT RECOMMENDED BY THE
MANUFACTURER OF THIS PRODUCT, AS IT CAN RESULT
IN SERIOUS PERSONAL INJURY.
1. Guide Wheels
2. Lower Tubes
3. Upper Tubes
4. Connector
5. Mode Selector
6. Front Handle
7. Variable Speed Dial
8. On/Off Trigger
9. Sure Grip Handle
10. Collection Bag
11. Wall Support Bracket
12. Battery Seating
13. Shoulder Strap
14. Thumb Screws x 2
15. One-way Screw
WARNING! NEVER OPERATE WITHOUT THE LOWER
TUBES FITTED TO THE UPPER TUBES OTHERWISE RISK
OF INJURY.
2. CONTROLS
“SNAP”
b
Attaching and Removing the Collection Bag
1. Attach the plastic connector on
the collection bag to the outlet in
the motor housing. Ensure that it
latches in place correctly.
2. Attach the collection bag to
the rst hole on the suction
tube.
Fitting the Wall Bracket
1. Slide the wall bracket onto the motor housing as far as it will go.
Make sure that the V-shaped cut-out faces the tubes.
3. To remove the collection bag, rst unhook it from the suction tube,
then press the release levers (b) simultaneously on both sides and
pull off the plastic connector away from the motor housing.
Fitting the Shoulder Strap
1. Hook the carabiner to the motor
housing.
On/Off Trigger
Variable Speed Dial
The ow of air can be regulated by turning the variable speed dial.
MAX MIN = Maximum speed, = Minimum speed
1. To achieve the greatest ow
of air, move the dial to the
“MAX” setting.
2. To lower the air speed rotate
the variable speed dial to
a lower speed, or “MIN”
setting.
Mode Selection
1. To select the Blower
function turn the lever right
to the blower icon.
2. To select the Vacuum/
Mulching function move
the lever left to the vacuuming
icon.
1. Squeeze the on/off trigger to
start. Motor will start after a
short delay.
2. To stop operation, release the
on/off trigger.
WARNING! DO NOT SWITCH ON IN ENCLOSED OR
POORLY VENTILATED SPACES OR IN THE PRESENCE OF
FLAMMABLE AND/OR EXPLOSIVE LIQUIDS, GASES AND
POWDERS.
