Oldal 1/10
STANDARD EQUIPMENT
PXBUVS-1825
INSTRUCTION MANUAL
SPECIFICATIONS
Input: 18V
No Load Speed: 4,500-15,000/min
Air Speed: 250km/h max.
Air Volume: 120m/h max.
Noise Rating: 94dB
Weight: 1.10kg
ozito.com.au
1123
Universal Blower
Blower Tube
CORDLESS
UNIVERSAL
BLOWER
IN ORDER TO MAKE A CLAIM UNDER THIS WARRANTY YOU
MUST RETURN THE PRODUCT TO YOUR NEAREST BUNNINGS
WAREHOUSE WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO
RETURNING YOUR PRODUCT FOR WARRANTY PLEASE TELEPHONE
OUR CUSTOMER SERVICE HELPLINE:
Australia 1800 069 486
New Zealand 0508 069 486
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL
NUMBER AND DATE OF PURCHASE AVAILABLE. A CUSTOMER
SERVICE REPRESENTATIVE WILL TAKE YOUR CALL AND
ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE
WARRANTY POLICY OR PROCEDURE.
OZITO INDUSTRIES PTY. LTD. 25 Fox Drive, Dandenong South, Victoria 3175, Australia.
The benets provided under this warranty are in addition to other rights and
remedies which are available to you at law.
Our goods come with guarantees that cannot be excluded at law. You are entitled to
a replacement or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled to have the goods
repaired or replaced if the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
Generally you will be responsible for all costs associated with a claim under this
warranty, however, where you have suffered any additional direct loss as a result of
a defective product you may be able to claim such expenses by contacting our
customer service helpline above.
WARNING
The following actions will result in the warranty being
void.
• If the tool has been operated on a supply voltage other than that specied
on the tool.
• If the tool shows signs of damage or defects caused by or resulting from
abuse, accidents or alterations.
• Failure to perform maintenance as set out within the instruction manual.
• If the tool is disassembled or tampered with in any way.
• Professional, industrial or high frequency use.
5 YEAR REPLACEMENT WARRANTY
Your Product is guaranteed for a period of 60 months from the original date of
purchase and is intended for DIY (Do It Yourself) use only. If a product is defective it
will be replaced in accordance with the terms of this warranty. Lithium Ion
batteries and chargers are covered by a 36 month
warranty and are excluded from the warranty extension. Warranty excludes
consumable parts.
Blower Tube Extension
Blower Nozzle
ONLINE MANUAL
Scan this QR Code with your
mobile device to take you to
the online manual.
b
a b
Installing The Blower Tubes
1. Push the blower tube onto the blower motor housing as far as it will
go, aligning the groove (a) on the blower tube and the guide (b) on the
outlet of the universal blower as you do this.
2. Turn the blower tube to lock in
place.
1. Blower Tube Extension
2. Blower Tube
3. Speed Control
4. On/Off Trigger
5. Sure Grip Handle
6. Battery Seating
7. Integrated Wall Holder
8. Motor Housing
9. Scraper
10. Blower Nozzle
This tool is compatible with all batteries & chargers
from the Ozito PXC range.
CORDLESS UNIVERSAL BLOWER
BATTERY & CHARGER
KNOW YOUR PRODUCT
1. ASSEMBLY
SETUP & PREPARATION
1 2
8
34 5
7
9
10
WARNING! ENSURE THE BLOWER IS SWITCHED OFF
AND THE BATTERY IS REMOVED BEFORE PERFORMING
ANY OF THE FOLLOWING TASKS.
WARNING! DO NOT USE ANY ATTACHMENTS
OR ACCESSORIES NOT RECOMMENDED BY THE
MANUFACTURER OF THIS PRODUCT, AS IT CAN RESULT
IN SERIOUS PERSONAL INJURY.
WARNING! THE BLOWER TUBE TURNED AS FAR AS
IT WILL GO AND LOCK INTO PLACE TO ENSURE IT IS
FIRMLY SECURED IN POSITION.
3. Depending on your application the blower tube extension can be
attached to the end of the blower tube, to install follow the above
steps to correctly install the tubes together.
6
“CLICK”
PRESS
Inserting the Battery
Align the ribs of the battery
with the recess below the
handle of the blower and push
in until it clicks into place.
Removing the Battery
Press and hold the battery
release tab as you slide the
battery out.
2. INSERTING & REMOVING THE BATTERY
Run Time
The operating time of the PXC battery (the amount of operating time
and the area you can cover with a single battery charge) is largely
dependent on the battery age, speed selected and the rate of work.
Frequently turning the equipment on and off will also reduce the
runtime. If the operating time of the PXC battery (runtime) is still
unsatisfactory in spite of the above measures, you can remedy the
problem by using PXC battery with a larger capacity (Ah).
Installing The Blower Nozzle
Depending on your application the blower nozzle can be attached to the
blower motor housing. Follow steps 1-2 in Installing the Blower
Tubes to correctly install.
Note: To remove the tubes or nozzle proceed in reverse order.
