Immerse in 3D surround sound of Dolby Atmos

® or DTS:X in 5.2.2ch speaker layout, or you can still enjoy similar effects by Dolby Atmos Height

Virtualizer and DTS Virtual:X even without height or surround speakers. Featuring Ultra HD, HDR10, HLG, and Dolby Vision™ pass through, offering

evermore life-like images. Plus, the VSX-935 supports HDMI 2.1*

1 for 8K, VRR, ALLM, QFT pass-through for next-generation video/gaming with HDCP

2.3. You can stream songs from various sources via Music Server, Bluetooth

®, DTS Play-Fi, Sonos system and Apple AirPlay 2. It is Roon Tested,

making music streaming easy from AV equipment. Other highlights include Powered Zone 2 feature with a dedicated DAC, Personal Preset buttons, 2

HDMI outputs, and it for voice control.

works with Alexa/Hey Google

Amplication

> Channels: 7

> Amplication Type: Direct Energy

> 170 W/ch (6 ohms, 1 kHz, THD 10 %, 1ch Driven)

> 80 W/ch (8 ohms, 20 Hz-20 kHz, THD 0.08 %, 2ch Driven, FTC)

Audio Features

> Dolby Atmos®, Dolby Surround Upmixer

> DTS:X®, DTS Neural:X® Upmixer

> Reex Optimizer

> Dolby Atmos Height Virtualizer

> DTS Virtual:X

> Dolby® TrueHD, Dolby Digital Plus

> DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES,

DTS-HD Express

> DSD Disc (SACD) Playback via HDMI (2.8 MHz/2ch, 5.1ch)

> Digital Quad-Core 32-bit DSP (Cirrus Logic)

> 192 kHz/24-bit D/A Conversion for Hi-Res Audio

> Enhanced Audio Return Channel (eARC) on HDMI OUT (MAIN)

> MCACC Auto Room Tuning

• Phase Control

• Subwoofer EQ

> Advanced Sound Retriever (2ch)

> Advanced Surround Modes

• Classical, Unplugged, Entertainment Show, Drama, Advanced Game,

Action, Rock/Pop, Sports, Extended Stereo, Mono Music, Front Stage

Surround Advance

Video Features

> Support HDMI 2.1 (HDMI IN 1-3) with 8K, VRR (Variable Refresh Rate),

ALLM (Auto Low Latency Mode), QFT (Quick Frame transport), DSC (Display

Stream Compression), and QMS (Quick Media Switching) pass-through

> Supports HDR10+, HDR10, and HLG; 8K/60p (4:2:0/10-bit), 8K/30p (4:4:4/10-

bit, 4:2:2/12-bit), 4K/120p (4:4:4/10-bit, 4:2:2/12-bit), 4K60p (4:4:4/12-bit) and

BT.2020 color; Deep Color™ (36-bit), "x.v.Color", LipSync, and HDCP 2.3

> Dolby Vision Compatible

> Ultra HD Upscaling (4K to 8K, 1080p to 8K/4K)

Home Network Features

> Works with Alexa supporting multi-room music

> Works with Hey Google and Chromecast built-in

> DTS Play-Fi® supporting Critical Listening mode with Pioneer Music Control

App*2

> Apple AirPlay 2 with Siri Voice Control

> Works with SONOS supporting multiple Sonos Connect control and Volume

Pass Through mode

> Amazon Music HD*3, Pandora®, Spotify, TIDAL, and Deezer Hi-Fi Music-

Streaming Services Ready*4

> Internet Radio with TuneIn

> Hi-Res Audio File Playback via USB/Network

> Up to 192 kHz/24-bit ALAC*5 , AIFF, FLAC, WAV (RIFF) and 5.6 MHz DSD*

Convenience Features

> Personal Preset

> Dialog Enhancement

> Dual Band (5 GHz/2.4 GHz) Wi-Fi® Built-in

> Bluetooth® Wireless Technology (Version: 4.2, Prole: A2DP 1.2/AVRCP 1.3,

Codec: SBC/aptX/aptX HD (TX), SBC/AAC(RX)) Built-in

> Pioneer Remote App*2 Ready for Multi-room Entertainment Control and

Network Streaming

> User-Friendly GUI with System Setup Menu

> On-Screen Information for Audio, Video and Network

> Web Setup

> Auto Power Off in HDMI Standby Through

> FM/AM Tuner 40 Presets

> Sleep Timer

> User-Friendly Simple Remote Control

Front Terminals

> USB 1 In for USB Drive

> MCACC Setup MIC In

> Audio 1 In (Mini Stereo Jack)

> Phones 1 Out

Rear Terminals

> HDMI 6 In (4 Assignable)

> HDMI 2 Out

> Ethernet 1 In

> USB 1 In for USB Drive

> Audio 4 In (Assignable)

> Phono (MM) 1 In

> Digital Coaxial 1 In (Assignable)

> Digital Optical 1 In (Assignable)

> Subwoofer 2 Pre Out

> ZONE 2/ZONE B Line Out

> Speaker 9ch Out (FRONT, CENTER,

SURROUND/HEIGHT, HEIGHT/SURROUND

BACK/Bi-AMP, ZONE 2)

> FM/AM Antenna

Specications

> Power Requirements: AC 120 V, 60 Hz

> Power Consumption/Standby: 460 W/0.1 W

> Dimensions (W x H x D): 17-1/8 x 6-13/16 x

14-9/16 inches (435 x 173 x 370.5 mm)

> Weight: 21.2 lbs. (9.6 kg)

> Carton Dimensions: 21-1/8 x 10-7/16 x

18-1/16 inches (536 x 265 x 458 mm)

> Carton Included Weight: 26.5 lbs. (12.0 kg)

*1 HDMI IN 1-3, HDMI OUT MAIN and SUB/ZONE 2 in sub output mode. *2 Available for free download from the App Store/The Google Play Store. *3 Amazon Music HD is supported via DTS Play-Fi.

*4 Service availability depends on country or region. *5 Up to 96 kHz supported via wireless LAN. *6 Converted to PCM. Not guaranteed via wireless LAN.

VSX-935(B)

7.2-ch Network AV Receiver

VSX-935(B) UPC: 889951003793

All other trademarks and registered trademarks are the property of their respective holders.

Note: Specications and design subject to change without notice.

DTS:X 5.2.2ch Speaker System

Dolby Atmos 5.2.2ch Speaker System

HDMI 2.1 for a powerful viewing and gaming experience

The VSX-935 ensures its HDMI terminals*1

support 8K/60p (4:4:4/12-bit*2, 4:2:0/10-bit),

8K/30p (4:4:4/12-bit*2, 4:4:4/10-bit, 4:2:2/12-bit),

4K/120p (4:4:4/12-bit*2, 4:4:4/10-bit, 4:2:2/12-bit)

video passthrough to compatible displays, as well

as HDCP 2.3 so you will have no problem when

upgrading to new devices. HDMI 2.1 also supports

VRR (Variable Refresh Rate) to eliminate lag, stutter and frame-tearing to deliver a

uid gaming experience. Various enhancements such as ALLM (Auto Low Latency

Mode) and QFT (Quick Frame Transport) help to optimize latency and further limit

lag to ensure you’ll always be on top of your game.

*1 HDMI 2.1 specication, HDR10+, and passthrough capabilities described are supported on HDMI IN 1–3, HDMI

OUT MAIN and SUB/ZONE 2 in sub mode output. *2 DSC signals only.

Dolby Atmos ®/Dolby Surround Upmixing

The VSX-935 is compatible with 5.2.2ch

conguration of the latest cinema sound

platform, Dolby Atmos ®

. You can

reproduce object-oriented sound in

smooth, curving movements, or the

realistic three-dimensional movement

overhead by the top speakers. Other

audio codecs such as PCM and DSD

can be upmixed using Dolby Surround

for enjoying 3D surround sound.

DTS:X®/DTS Neural:X Upmixing

DTS:X is the next-generation audio codec from DTS

that leverages object-based audio to enable new

immersive and interactive audio experiences. Since

DTS:X can automatically adapt the

audio to the existing channels and

speaker system, no specic speaker

layout is required. Experience an

immersive soundscape with incredibly

rich and life-like audio. Other audio

codecs such as PCM and DSD can

be upmixed using DTS Neural:X for

enjoying 3D surround sound.

Dolby Atmos Height Virtualization

When playing any Dolby format, engaging the Dolby Atmos Height Virtualizer

enables a more immersive listening experience, creating a virtual surround

and height effect from traditional speaker layouts without employing additional

surround or height speakers.

DTS Virtual:X

With DTS Virtual:X, you can enjoy a three-dimensional immersive sound similar

to DTS:X, without the need of height or rear speakers. The technology supports

2 to 7.1.4-channel input source, for delivery on 2 to 5.1 or even 7.1-channel

speaker layout. DTS Virtual:X works with all DTS codecs, including DTS:X.

Personal Preset

Just press the Personal Preset button on the front panel for three seconds, and

your current settings such as volume level and listening mode can be saved. Up

to three presets can be registered and easily called up from the front panel button

or the remote control.

Dialog Enhancement

With this unique mid-range sound control feature, you can make independent

volume adjustments to the range including dialogs in lms, with the up/down key

on the remote control.

MCACC Auto Room Tuning

Create the optimum acoustic environment with Pioneer’s

MCACC (Multi-Channel Acoustic Calibration System),

developed with the expertise of professional recording studios.

With the custom microphone, the system automatically compensates for

differences in speaker size, level and distance, and equalizes response.

Works with SONOS

By bringing the VSX-935 into the Sonos eco-system with

Connect or Port, you can play any music or audio source on

your Sonos app. With "Volume Pass Through" mode selected

at the Sonos App settings, you’ll be able to control the volume of the unit by

Sonos app or by itself. Enjoy high-quality playback from the AV receiver by Sonos

app, just as you would with your favorite Sonos system.

*Connection of maximum 2 Sonos devices is supported

Powered Zone 2 with Dedicated DAC

With the powered feature, the VSX-935 can directly drive

speakers in another room, without the need for a separate

amplier. What’s more, the dedicated DAC for Zone 2 lets you

listen to all digital audio sources.

Zone B Output for Wireless Headphones

The VSX-935 is equipped with Zone B audio output terminals

for expanding the Main Zone sound by connecting your

wireless headphone dock. You can listen to the sound playing

in the living room via wireless headphones.

High-quality Audio Transmission by Bluetooth ® Wireless

technology

Stream songs from compatible devices with the built-in Bluetooth

Wireless Technology (ver. 4.2). The VSX-935 features A2DP/AVRCP

proles, supporting SBC/aptX/aptX HD codecs for transmitter and

SBC/AAC codecs for receiver. Not only you can listen music with the

receiver via , but also listen to the main Bluetooth

source sound of the receiver with a high-quality

codec using compatible headphones. With Wake

on Play function, the AV receiver automatically

wakes up and switches input when a source starts playing.Bluetooth

Voice Control

The VSX-935 works with Hey Google, so you can

control playback of various music services supported

by Chromecast by asking a Google Assistant enabled

device to play, stop, skip, or take the volume up or

down. This receiver also works with Alexa, so you can

also use voice commands to control supported music

services in multiple rooms by Alexa built-in devices.

Thanks to both voice controls, you can easily operate

and enjoy music services or Internet radio with your

voice, without using a remote control or smartphone app.

Integrated Technologies
