2019 NEW PRODUCT RELEASE

TX-SR393 5.2-Channel A/V Receiver

BL ACK

Class-beating sound shaped to your lifestyle

Premiere Dolby Atmos® and DTS:X® sound at home with the TX-SR393. Choose a speaker layout to suit your room, from a space-saving

2.1-ch setup enhanced with 3D surround-sound courtesy Dolby Atmos Height Virtualizer* or DTS Virtual:X® to a 3.2.2-ch system for

native object-audio playback. Whatever way you play it, dynamic power is ready to thrill thanks to authentic high-current analog amps

backed by a thumping custom transformer. For true-to-life video, the AVR supports 4K/60p and HDR video passthrough. If all this tech

sounds scary, relax: every aspect of this product is designed to erase frustration, from the automated AccuEQ system calibration to

quick connection guide. The receiver integrates your players and TV and adds practical features such as Vocal Enhancer for clear dialog.

There’s even a Zone B line-out to distribute all your home theater sources to a component with an analog RCA line in, such as a wireless

headphone dock or hi-fi system. Or just sit back and stream from apps via Bluetooth® technology and let Advanced Music Optimizer™

enrich every note of the golden Onkyo sound. * Enabled with a future firmware update.

AMPLIFIER FEATURES

• 155 W/Ch (6 ohms, 1 kHz, 10% THD, 1 channel driven),

80 W/Ch (8 ohms, 20 Hz–20 kHz, 0.08% THD,

2 channels driven, FTC)

• High-Output Low-Noise Power Transformer

• High-current 5-channel analog amplification system

• Discrete high-power output transistors

• Original low-impedance amp-circuit topology

VIDEO & AUDIO SUPPORT

• Supports HDCP 2.2, 4K/60p, HDR (Dolby Vision, HDR10,

HLG, BT.2020), 4:4:4 color-space, BT.2020, 3D Video,

ARC (Audio Return Channel), DeepColor™, x.v.Color™, and

LipSync via HDMI

• Dolby Atmos, DTS:X, Dolby

® TrueHD, and

DTS-HD Master Audio™ decoding

• Supports SACD (Super Audio CD) Playback via

HDMI (2.8 MHz/2ch, multi-channel)

• Dolby Atmos Height Virtualizer and DTS Virtual:X 3D

sound processing

• Dolby Surround® and DTS Neural:X® upmixing technologies

• Premium 384 kHz/32-bit AKM multichannel DAC

• Direct Mode for source-authentic stereo sound

CONNECTION FEATURES

• 4 HDMI inputs and 1 output with ARC (Audio Return Channel)

• 2 digital audio inputs (1 optical and 1 coaxial, assignable)

• 3 analog audio inputs (assignable)

• Zone B line out

• 2 subwoofer pre-outs

• Speaker terminals (banana-plug x 2 [Front L/R], lever-type x 3)

• Rear USB power supply terminal (5 V/1 A) for

media streaming devices

• 1/4˝ (6.35 mm) headphone output (front)

• 1/8˝ (3.5 mm) AccuEQ setup mic input (front)

ADVANCED FEATURES

• AccuEQ Room Acoustic Calibration, Subwoofer EQ,

and AccuReflex

• Zone B line-out shares any audio source to components with

an RCA input, such as mini hi-fi systems, integrated amps,

wireless headphone docks, etc.

• DSP-controlled Vocal Enhancer function boosts dialog audibility

via remote keys or front-panel controls

• Bluetooth wireless technology supports high-quality audio

streaming from phones, tablets, and PCs

• Advanced Music Optimizer improves playback quality of

compressed audio

• GUI with OSD via HDMI features media input/output

information window for easy confirmation of playback settings

• 1080p Full HD to 4K Ultra HD upscaling over HDMI

• Quick Connection Guide on rear panel for stress-free setup

• A/V sync control (up to 500 ms in 5 ms steps at 48 kHz)

• Direct Power On function switches on receiver when an input

key is pressed on the remote control or front panel

• HDMI passthrough function on standby

• Tone controls for Front L/R channels (bass/treble)

• 3-Mode front-panel display dimmer (Normal/Dim/Dimmer)

• AM/FM tuner with 40 random presets

• Sleep timer

• Simple remote control

• 155 watts per channel

• Supports 4K/60p and HDR

(HDR10, HLG, Dolby Vision®, BT.2020)

• Dolby Atmos® and DTS:X® playback

• Dolby Atmos Height Virtualizer

* and DTS Virtual:X®

• AccuEQ with subwoofer EQ and AccuReflex™

• Discrete high-current analog amp system with

4-ohm drive capability

• Bluetooth® technology and Advanced Music Optimizer

™

• Vocal Enhancer function improves voice audibility

• OSD window shows media format data for

quick confirmation

* Enabled with a future firmware update.

PRODUCT HIGHLIGHTS

Dolby Atmos® and DTS:X® sound is here

The TX-SR393 supercharges your Dolby Atmos

® and DTS:X®

experience. Object-based audio is mixed in 3D space and

lets any sound play through any speaker, tracking the action,

localizing effects, and moving around you. Dolby Surround

and DTS Neural:X

® complement native 3D audio playback.

These technologies find localization cues in legacy stereo or

multichannel soundtracks and upmix these elements to create

immersive top-to-bottom dimensionality.

Dolby Atmos Height Virtualizer

When playing any Dolby

® format, engaging Dolby Atmos

Height Virtualizer enables a more immersive listening

experience, creating a virtual surround and height effect from

traditional speaker layouts without employing additional

surround or height speakers.

Note: Enabled with a future firmware update.

Spatial sound elevated with DTS Virtual:X®

DTS Virtual:X is a new surround-sound virtualization

technology that creates an immersive 3D soundfield from any

speaker layout, such as 2.1, 3.1, and 5.1 configurations without

height, surround, or rear surround speakers deployed. It uses

sophisticated DSP-based algorithms to place the audience at

the center of a multidimensional soundfield with height and

surround spatiality, and is equally effective in large or small

spaces. DTS Virtual:X works in the 3D domain with DTS:X

soundtracks, DTS formats, and non-encoded stereo.

Ready for 4K HDR entertainment

Enjoy comprehensive support for 4K/60p and HDR (High

Dynamic Range) video formats including HDR10, HLG, Dolby

Vision®, and BT.2020. The 4:4:4 color-space is also supported.

All four HDMI® inputs and ARC-ready output pass video from

player to your compatible TV, unlocking everything the latest

films and games have to offer. You can easily confirm A/V

input-output status via a new OSD window.

More power, more realism, more magic

It’s tempting to see watts as the most important figure on

an amp’s spec sheet. However, watts are an indication of

loudness, not sound quality. Amperes—electrical current—

tell the real story. The more current an amplifier develops,

the better it controls the speakers. Better control equals fast

transient response, wide dynamic

range, and clear, accurate sound.

The high-output transformer,

large capacitors, and discrete amps

inside the TX-SR393 produce the

most current in its class. And that’s

one big reason why it sounds as

good as it does.

AccuEQ Room Acoustic Calibration

with AccuReflex™

AccuEQ creates a harmonious soundfield in your room.

It detects speaker presence, size, and distance from a

measurement position, and sets sound-pressure levels. It then

selects the ideal subwoofer crossover and applies equalization

to all speakers. AccuReflex optimizes object-based audio

reproduction through Dolby Atmos-enabled speakers. It

resolves phase-shift arising from path differences between

directional and non-directional sounds. Enjoy improved

localization and a 3D field with vertical movement and

overhead dimensionality.

Hear dialog clearly at the touch of a button

Finally, a fast and effective solution to

inaudible dialog in TV programs and

movies. The TX-SR393 features

DSP-controlled Vocal Enhancer that

identifies vocal frequencies and allows

you to raise or lower them to taste

using keys on the remote or via the tone

controls on the receiver’s front panel.

Share the atmosphere or relax in privacy

A fantastic addition to the TX-SR393 is a Zone B line-out. It

connects a component with an analog RCA line input to audio

sources available to the receiver, including HDMI and digital

audio. Share sound to a hi-fi in a nearby space, or connect a

supported charging transmitter dock for wireless headphones

and enjoy your entertainment without disturbing anybody.

Simple steps to sweet sound

The TX-SR393 simplifies your room’s entertainment setup.

Components plug into labelled ports while your TV connects

via one easy-to-conceal HDMI cable. Hook up your speakers

as shown by a friendly diagram next to the numbered speaker

terminals. Setup takes moments, enjoyment is limitless.

Smooth and easy Bluetooth ® streaming

Whatever audio is playing on your phone, tablet, or PC

app can be streamed to the TX-SR393 with Bluetooth

wireless technology. Once the receiver has paired with and

remembered your device, it will start playback automatically

whenever it detects an incoming audio stream.Bluetooth

Decompress with Advanced Music Optimizer™

When an audio file is squeezed into a small container (such as

MP3), high-frequency data is lost. This can affect sound quality.

Onkyo’s Advanced Music Optimizer DSP listening mode

reconstructs the missing bit data. Playback quality is greatly

improved, while you enjoy the same convenient file sizes. This

mode also optimizes streaming playback quality.Bluetooth

USB power for streaming dongles

A USB port on the rear panel powers any media streaming

stick plugged into an adjacent HDMI input—great if you don’t

have enough power-points.

TX-SR393

5.2-Channel A/V Receiver

SPECIFICATIONS

Due to a policy of continuous product improvement, Onkyo reserves the right to change specifications and appearance without notice. Manufactured under license from Dolby Laboratories. Dolby, the double-D symbol, Dolby Atmos, Dolby Surround, Dolby

Vision, and Dolby TrueHD are trademarks of Dolby Laboratories. For DTS patents, see http://patents.dts.com. Manufactured under license from DTS, Inc. DTS, the Symbol, DTS and the Symbol together, DTS:X and the DTS:X logo, DTS Virtual:X and the DTS

Virtual:X logo, DTS Neural:X and the DTS Neural:X logo, and DTS-HD Master Audio and the DTS-HD Master Audio logo are registered trademarks or trademarks of DTS, Inc. in the United States and/or other countries. © DTS, Inc. All Rights Reserved. The

terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries. The Bluetooth® word mark and logos are registered

trademarks owned by Bluetooth SIG, Inc. Products displaying the Hi-Res Audio logo conform to the Hi-Res Audio standard as defined by Japan Audio Society. The Hi-Res Audio logo is used under license from Japan Audio Society. AccuEQ and Music

Optimizer are trademarks of Onkyo Corporation. All other trademarks and registered trademarks are the property of their respective holders.

NPR No. 19N01 12/18
