Oldal 1/92
1
1. Package Contents
You should have received the following items inside of package:
- UPS Unit
- Quick Guide
2. Product Overview
Front View:
Back View:
Line Interactive UPS Quick Guide V. 2.0
Power Switch
UPS status LED
AC Mode: green lighting
Battery Mode: green flashing
○
A Output receptacles
○
B AC input
Options –
○
C Circuit breaker / Fuse
○
D USB port
○
E Modem/phone or Network surge protection
EN
2
4 hours
CAUTION: NEVER connect a laser printer or scanner to the
UPS unit. This may cause damage to your equipment .
3. Installation and Initial Startup
NOTE: Before installation, please inspect the unit. Be sure that nothing
inside the package is damaged.
Placement & Storage Conditions
Install the UPS in a protected area that is free of excessive dust and has adequate air flow.
Please place the UPS away from other units at least 20 cm to avoid interference. Do NOT
operate the UPS where the temperature and humidity is outside the specific limits. (Please
check the specs for the limitations.)
Connect to Utility and Charging
Plug in the AC input cord to the wall outlet. For the best results,
we suggest to charge the battery for at least 4 hours before
initial use. The unit charges its battery while connecting to the
mains.
Connect the Loads
Plug in the loads to output receptacles on the rear panel of the UPS. Simply turn on the
power switch of UPS unit, then devices connected to the UPS will be protected by UPS unit.
Turn On/Off the Unit
Turn on the UPS unit by pressing the power switch. Turn off the UPS unit by pressing
again the power switch.
3
4. Important Safety Warning (SAVE THESE INSTRUCTIONS)
CAUTION! To prevent the risk of fire or electric shock, install in a temperature and humidity
controlled indoor area free of conductive contaminants. (See the specifications for the
acceptable temperature and humidity range.)
CAUTION! To reduce the risk of overheating the UPS, do not cover the UPS's cooling vents
and avoid exposing the unit to direct sunlight or installing the unit near heat emitting
appliances such as space heaters or furnaces.
CAUTION! Do not attach non-computer-related items, such as medical equipment,
life-support equipment, microwave ovens, or vacuum cleaners to UPS.
CAUTION! Do not plug the UPS input into its own output.
CAUTION! Do not allow liquids or any foreign object to enter the UPS. Do not place
beverages or any liquid-containing vessels on or near the unit.
CAUTION! In the event of an emergency, press the OFF button and disconnect the power
cord from the AC power supply to properly disable the UPS.
CAUTION! Do not attach a power strip or surge suppressor to the UPS.
CAUTION! If the UPS is with metal chassis, for safety purpose, grounding is a must during
UPS installation in order to reduce leakage current below 3.5mA.
ATTENTION! Even when the UPS is disconnected from the mains, there may still be
hazardous voltage from the battery. The battery should therefore be disconnected at the plus
and minus terminals of the battery before maintenance or service work inside the UPS is
performed.
CAUTION! Servicing of batteries should be performed or supervised by qualified service
personnel. Keep unauthorized personnel away from batteries.
CAUTION! When replacing the batteries; use the same number and type of batteries.
CAUTION! Internal battery voltage is 12VDC. Sealed, lead-acid, 6-cell battery.
CAUTION! Do not dispose of batteries in a fire. The battery may explode. Do not open or
mutilate the battery / tteries. Released electrolytes are harmful to the skin and eyes. ba
CAUTION! Unplug the UPS prior to cleaning and do not use liquid or spray detergent.
CAUTION! A battery can present a risk of electric shock and high short circuit
current. The following precautions should be observed before replacing batteries:
1) Remove watches, rings, or other metal objects.
2) Use tools with insulated handles.
3) Wear rubber gloves and boots.
4) Do not lay tools or metal parts on top of batteries.
5) Disconnect charging source prior to connecting or disconnecting battery
terminals.
