SPECIFICATIONS

Wingspan: 48 in

[1220mm]

Wing

Area:

354 in2

[22.8 dm2]

Weight: 30.4 oz

[860 g]

Wing

Loading:

12.4 oz/ft2

[38 g/dm2]

Length: 33 in

[840mm]

Radio: 4-channel

(required)

READ THROUGH THIS MANUAL BEFORE STARTING CONSTRUCTION. IT CONTAINS IMPORTANT

INSTRUCTIONS AND WARNINGS CONCERNING THE ASSEMBLY AND USE OF THIS MODEL.

WARRANTY

Hobbico guarantees this kit to be free from defects in both

material and workmanship at the date of purchase. This warranty

does not cover any component parts damaged by use or

modification. In no case shall Hobbico’s liability exceed the

original cost of the purchased kit. Further, Hobbico reserves

the right to change or modify this warranty without notice.

In that Hobbico has no control over the final assembly or material

used for final assembly, no liability shall be assumed nor

accepted for any damage resulting from the use by the user of

the final user-assembled product. By the act of using the

user-assembled product, the user accepts all resulting liability.

If the buyer is not prepared to accept the liability associated

with the use of this product, the buyer is advised to return

this kit immediately in new and unused condition to the

place of purchase.

To make a warranty claim send the defective part or item to

Hobby Services at the address below:

Hobby Services

3002 N. Apollo Dr. Suite 1

Champaign IL 61822 USA

Include a letter stating your name, return shipping address, as

much contact information as possible (daytime telephone

number, fax number, e-mail address), a detailed description of

the problem and a photocopy of the purchase receipt. Upon

receipt of the package the problem will be evaluated as quickly

as possible.

I N S T R U C T I O N M A N U A L

™

TABLE OF CONTENTS

INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . .2

ADDITIONAL ITEMS REQUIRED . . . . . . . . . . . . . . . . . . .3

Radio Control System . . . . . . . . . . . . . . . . . . . . . . . . .3

Additional Battery and Charging System (Optional) . .3

Required Assembly Tools. . . . . . . . . . . . . . . . . . . . . . .3

ORDERING REPLACEMENT PARTS . . . . . . . . . . . . . . . .3

KIT INSPECTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

KIT CONTENTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4

ASSEMBLE THE MODEL . . . . . . . . . . . . . . . . . . . . . . . . .5

Mount the Main Landing Gear . . . . . . . . . . . . . . . . . . .5

Mount the Vertical and Horizontal Stabilizers. . . . . . . .5

Hook Up the Controls. . . . . . . . . . . . . . . . . . . . . . . . . .7

Check the Control Throws . . . . . . . . . . . . . . . . . . . . . .9

Increased Elevator Throw for Expert Pilots (Optional) . .10

Mount the Wing . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

FINAL PREPARATION . . . . . . . . . . . . . . . . . . . . . . . . . .12

Mount the Propeller . . . . . . . . . . . . . . . . . . . . . . . . . .12

Check the C.G. (Center of Gravity) . . . . . . . . . . . . . .12

GET THE MODEL READY TO FLY . . . . . . . . . . . . . . . . .14

Identify Your Model . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Charge the Battery. . . . . . . . . . . . . . . . . . . . . . . . . . .14

FLYING THE PIPER Super CUB . . . . . . . . . . . . . . . . . . .14

Find a Suitable Flying Site . . . . . . . . . . . . . . . . . . . . .14

Know Your Frequency. . . . . . . . . . . . . . . . . . . . . . . . .14

Perform a Range Check. . . . . . . . . . . . . . . . . . . . . . .15

Monitor Your Flight Time. . . . . . . . . . . . . . . . . . . . . . .15

Take Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

Flying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

Landing . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

After Flight . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover

INTRODUCTION

Thank you for purchasing the Piper Super Cub RxR (receiver

ready). The Cub is forgiving and “friendly” enough for pilots

with little experience, but also responsive enough for

experienced pilots who desire a durable Piper Cub that they

can “toss” around the sky.

For the latest technical updates or manual corrections to

the Super Cub visit the Hobbico web site at www.hobbico.

com. Open the “Airplanes” link, then select “Super Cub”. If

there is new technical information or changes to this model

a “tech notice” box will appear in the upper left corner of

the page.

AMA

If you are not already a member of the AMA, please join!

The AMA is the governing body of model aviation and

membership provides liability insurance coverage, protects

modelers’ rights and interests and is required to ﬂ y at most

R/C sites.

ACADEMY OF MODEL AERONAUTICS

5151 East Memorial Drive

Muncie, IN 47302-9252

Tele. (800) 435-9262

Fax (765) 741-0057

Or via the Internet at:

http://www.modelaircraft.org

http://www.modelaircraft.org/parkﬂ yer.aspx

IMPORTANT!!!

Two of the most important things you can do to preserve the

radio controlled aircraft hobby are to avoid ﬂ ying near full-

scale aircraft and avoid ﬂ ying near or over groups of people.

PROTECT YOUR MODEL, YOURSELF

& OTHERS… FOLLOW THESE

IMPORTANT SAFETY PRECAUTIONS

1. Your Super Cub should not be considered a toy, but rather

a sophisticated, working model that functions very much like

a full-size airplane. Because of its performance capabilities,

the Cessna Skylane, if not assembled and operated correctly,

could possibly cause injury to yourself or spectators and

damage to property.

2. You must assemble the model according to the

instructions. Do not alter or modify the model, as doing so

may result in an unsafe or unﬂ yable model. In a few cases

the instructions may differ slightly from the photos. In those

instances the written instructions should be considered

as correct.

3. If you are not an experienced pilot or have not ﬂ own

this type of model before, we recommend that you get

the assistance of an experienced pilot in your R/C club for

your ﬁ rst ﬂ ights. If you’re not a member of a club, your local

hobby shop has information about clubs in your area whose

membership includes experienced pilots.

4. While this kit has been ﬂ ight tested to exceed normal use,

if the plane will be used for extremely high stress ﬂ ying, such

as racing, or if an engine larger than one in the recommended

range is used, the modeler is responsible for taking steps to

reinforce the high stress points and/or substituting hardware

more suitable for the increased stress.

We, as the kit manufacturer, provide you with a top quality,

thoroughly tested kit and instructions, but ultimately the

quality and ﬂ yability of your ﬁ nished model depends

on how you build it; therefore, we cannot in any way

guarantee the performance of your completed model,

and no representations are expressed or implied as to the

performance or safety of your completed model.

ADDITIONAL ITEMS REQUIRED

Radio Control System

The Piper Super Cub comes with the servos installed, so all

that is required is a 4-channel transmitter and receiver. The

Tactic™ TTX404 2.4GHz spread spectrum 4-channel radio

control system (TACJ0404) is included with the RTF (ready

to ﬂ y) version of the Piper Super Cub, so this same radio

system is ideal for your RXR version, too.

❏

Tactic TTX404 2.4GHz 4-channel system (TACJ0404)

❏

(8) AA batteries will be required to operate the

recommended transmitter (FUGP7308).

❏

A 6" [152mm] servo extension wire (HCAM2000) will also

be required.

Battery and Charger

Your Piper Super Cub was designed for the Flyzone 1300mAh

11.1V LiPo battery (HCAA6310). Other batteries similar in

size with the same voltage and capacity may also work, but

they may not ﬁ t properly in the battery compartment or have

the same kind of battery connectors. In addition to a battery,

a LiPo battery charger is also required and there are several

that will work (depending on your budget and requirements).

A safe, economical charger is the Great Planes® 3S

(3-cell/11.1V) LiPo Smart Charger (GPMM3318). The Smart

Charger includes adapters to charge from a 110V wall outlet

or a 12V DC outlet from a car. The Smart Charger charges

at a rate of 800mA, which works out to a charge time of an

hour-and-a-half (1300mAh divided by 800mA = 1.625 x 60

minutes = 97 minutes). But some pilots prefer to have several

batteries and charge them faster so they can ﬂ y more. For

charging up to four batteries faster (60 minutes) all at the

same time, the Great Planes PolyCharge4™ DC-powered

LiPo charger (GPMM3015) is recommended. But unlike the

included ElectriFly charger, the PolyCharge4 does not have

an internal LiPo cell balancer which is a critical component in

making sure your LiPo batteries charge efﬁ ciently and evenly.

So, for each LiPo battery you wish to charge simultaneously,

one Great Planes Equinox™ LiPo Cell Balancer (GPMM3160)

will also be required. Finally, the PolyCharge4 does not have

AC capability, so if wall-charging is a priority a separate A/C

12-Volt power source must also be purchased separately.

A suitable power supply for the PolyCharge4 is the Great

Planes 12V 12A DC power supply (GPMP0901).

Required Assembly Tools

Other than common hobby tools this is the list of adhesives

and building supplies that are required to ﬁ nish the Cub.

❏

Small needle-nose pliers (HCAR0625) or hemostats

(BRUR1302)

❏

#1 Phillips screwdriver (DTXR0174)

❏

Thread-locking cement (GPMR6060)

❏

Small crescent wrench

❏

Great Planes stick-on lead weight (Optional, GPMQ4485)

ORDERING REPLACEMENT PARTS

Replacement parts for the Hobbico Flyzone Super Cub

are available using the order numbers in the Replacement

Parts List that follows. The fastest, most economical service

can be provided by your hobby dealer or mail-order company.

To locate a hobby dealer, visit the Hobbico web site at www.

hobbico.com. Choose “Where to Buy” at the bottom of the

menu on the left side of the page. Follow the instructions

provided on the page to locate a U.S., Canadian or

International dealer.

Parts may also be ordered directly from Hobby Services

by calling (217) 398-0007, or fax at (217) 398-7721, but full

retail prices and shipping and handling charges will apply.

Illinois and Nevada residents will also be charged sales tax.

If ordering via fax, include a Visa® or MasterCard® number

and expiration date for payment.

Mail parts orders and payments by personal check to:

Hobby Services

3002 N. Apollo Drive, Suite 1

Champaign, IL 61822

Be certain to specify the order number exactly as listed in

the Replacement Parts List. Payment by credit card or

personal check only; no C.O.D.

If additional assistance is required for any reason, contact

Product Support by telephone at (217) 398-8970, or by

e-mail at .productsupport@hobbico.com

Termékspecifikációk

Márka:	Flyzone
Kategória:	Rádióvezérlésű játékok
Modell:	Super Cub

Szüksége van segítségre?

Ha segítségre van szüksége Flyzone Super Cub, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek

Az Ön neve*

Az Ön e-mail címe*

Írja ide kérdését

Útmutatók Rádióvezérlésű játékok Flyzone

Flyzone Calypso Útmutató

27 Augusztus 2024

Flyzone A6M2 Zero Útmutató

27 Augusztus 2024

Flyzone B-25 Mitchell Útmutató

27 Augusztus 2024

Flyzone Cessna 182 Skylane Útmutató

26 Augusztus 2024

Flyzone Seawind Útmutató

26 Augusztus 2024

Flyzone Sensei FS Útmutató

26 Augusztus 2024

Flyzone Extra 300 SX Útmutató

26 Augusztus 2024

Flyzone DHC-2 Beaver Útmutató

26 Augusztus 2024

Flyzone Super Cub Útmutató

26 Augusztus 2024

Flyzone Micro Calypso Útmutató

11 Augusztus 2024

Útmutatók Rádióvezérlésű játékok

Legújabb útmutatók Rádióvezérlésű játékok

Reely JoVage 4x4 V2 Útmutató

12 December 2024

MJX Hyper GO Útmutató

12 December 2024

Amewi MEW4 Útmutató

11 December 2024

Spektrum AR6600T Útmutató

15 Október 2024

Little Tikes Tire Twister Útmutató

8 Október 2024

Futaba 12Z Útmutató

4 Október 2024

Graupner 33718.XT60 Útmutató

3 Október 2024

Proline Trencher Útmutató

3 Október 2024

Amewi Hyper Go Útmutató

1 Október 2024

Carson Drift Burner Útmutató

1 Október 2024
