Oldal 1/12

FLZA4054

SPECIFICATIONS

Power

System:

900kV Outrunner,

40A ESC,

2200 mAh 11.1 V

LiPo battery

Wing Loading: 20.9 oz/ft2

[63.7 g/dm2]

Length: 44.5 in [1130 mm]

Radio: 6 channel

Wingspan: 56.5 in [1435mm]

Wing Area: 421 in2 [27.2 dm2]

Weight: 61 oz [1729 g]

READ THROUGH THIS MANUAL BEFORE STARTING CONSTRUCTION. IT CONTAINS IMPORTANT

INSTRUCTIONS AND WARNINGS CONCERNING THE ASSEMBLY AND USE OF THIS MODEL.

READ THROUGH THIS MANUAL BEFORE STARTING CONSTRUCTION. IT CONTAINS IMPORTANT

INSTRUCTIONS AND WARNINGS CONCERNING THE ASSEMBLY AND USE OF THIS MODEL.

Flyzone ®

guarantees this kit to be free from defects in both

material and workmanship at the date of purchase. This

warranty does not cover any component parts damaged by use

or modication. In no case shall Flyzone’s liability exceed the

original cost of the purchased kit. Further, Flyzone reserves

the right to change or modify this warranty without notice.

In that Flyzone has no control over the nal assembly or

material used for nal assembly, no liability shall be assumed

nor accepted for any damage resulting from the use by the user

of the nal user-assembled product. By the act of using the

user-assembled product, the user accepts all resulting liability.

If the buyer is not prepared to accept the liability associated

with the use of this product, the buyer is advised to return this

kit immediately in new and unused condition to the place of

purchase.

For warranty claims contact Hobbico Product Support:

Hobbico Product Support

3002 N. Apollo Drive Suite 1

Champaign IL 61822 USA

Telephone: (217) 398-8970 ext. 6

Fax: (217) 398-7721

E-mail: airsupport@hobbico.com

WARRANTY

I N S T R U C T I O N M A N U A L

®Champaign, Illinois

(217) 398-8970

E-mail: airsupport@hobbico.com

INTRODUCTION

Thank you for purchasing the Flyzone Seawind. The Flyzone

Seawind is scaled after the popular full size Seawind. The

retractable landing gear allows the plane to be  own from

your favorite runway or lake. The plane is quick to build so

you can spend more time  ying.

For the latest technical updates

or manual corrections scan the

QR code, or visit the Flyzone web

site at www. yzoneplanes.com.

Click the airplane icon at the top of

the page, then select the Seawind

when the airplane page opens.

A “Tech Notice” box indicates

corrected or updated technical information.

ADDITIONAL ITEMS REQUIRED

Radio System

To operate all the functions of the Flyzone Seawind (ailerons,

elevator, throttle, rudder,  aps and landing gear) a minimum

of 6 channels is required. The lighting harness is connected

to the  ap channel. The Futaba 6J 6-channel 2.4GHz

FHSS airplane radio (FUTK6000) or the Tactic TTX610 SLT

transmitter (TACJ2610) and TR625 SLT receiver (TACL0625)

are suitable and capable of operating all the functions.

LiPo Battery

A 3S 2200mAh LiPo battery is recommend to  y the

Seawind:

❍ 3S 11.1V 2200mAh 30C LiPo (GPMP0861)

For additional batteries more adhesive-back hook-&-loop

Velcro is also required:

❍ Great Planes Velcro Hook & Loop 1x 6" (GPMQ4480)

LiPo Charger

We recommend the DuraTrax® Onyx 235 AC/DC Advance

Peak Charger (DTXP4235). The 235 features 110V AC or

12V DC input power, adjustable charge rate (to charge the

recommended 2200 mAh batteries in as little as 30 minutes)

and an LCD digital display screen (so you can see how

much capacity it took to charge the battery – handy for

calculating optimum  ight time).

SAFETY PRECAUTIONS

Protect Your Model, Yourself & Others…

Follow These Important Safety Precautions

1. Your Seawind should not be considered a toy, but rather a

sophisticated, working model that functions very much like

a full-size airplane. Because of its performance capabilities,

the Seawind, if not assembled and operated correctly,

could possibly cause injury to yourself or spectators and

damage to property.

2. You must assemble the Seawind according to the

instructions. Do not alter or modify the model, as doing so

may result in an unsafe or un yable model. In a few cases

the instructions may differ slightly from the photos. In those

instances the written instructions should be considered

as correct.

3. You must use an R/C radio system that is in good

condition. All components must be correctly installed so

that the model operates correctly on the ground and in

the air. You must check the operation of the model and all

components before every  ight.

4. If you are not an experienced pilot or have not  own

this type of model before, we recommend that you get

the assistance of an experienced pilot in your R/C club

for your  rst  ights. If you’re not a member of a club, your

local hobby shop has information about clubs in your area

whose membership includes experienced pilots.

5. While this kit has been  ight tested to exceed normal

use, if the plane will be used for extremely high stress

 ying, such as racing, or if a battery larger than the one

recommended is used, the modeler is responsible for taking

steps to reinforce the high stress points and /or substituting

hardware more suitable for the increased stress.

We, as the kit manufacturer, provide you with a top quality,

thoroughly tested kit and instructions, but ultimately the

quality and  yability of your  nished model depends

on how you build it; therefore, we cannot in any way

guarantee the performance of your completed model,

and no representations are expressed or implied as to

the performance or safety of your completed model.

ADDITIONAL ITEMS REQUIRED . . . . . . . . . . . . . . . . . . .2

ASSEMBLE THE MODEL . . . . . . . . . . . . . . . . . . . . . . . . .3

Install the Main Landing Gear . . . . . . . . . . . . . . . . . . . .3

Install the Horizontal Stabilizer . . . . . . . . . . . . . . . . . . .3

Install the Wing Halves. . . . . . . . . . . . . . . . . . . . . . . . . .4

Install the Receiver. . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

Set the Fail Safe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Finish the Assembly. . . . . . . . . . . . . . . . . . . . . . . . . . . .6

Check/Set the Control Throws . . . . . . . . . . . . . . . . . . .7

Mount the Propeller . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Check the C.G. (Center of Gravity) . . . . . . . . . . . . . . . .8

PREFLIGHT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Identify Your Model . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

Ground Check and Range Check . . . . . . . . . . . . . . . . .8

ELECTRIC MOTOR SAFETY . . . . . . . . . . . . . . . . . . . . . .9

FLIGHT TIPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Takeoff . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Flight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

Landing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

REPLACEMENT PARTS . . . . . . . . . . . . . . . . . . . . . . . . .10

TABLE OF CONTENTS

Academy of Model Aeronautics

If you are not already a member of the AMA, please join!

The AMA is the governing body of model aviation and

membership provides liability insurance coverage, protects

modelers’ rights and interests and is required to  y at

most R/C sites.

Academy of Model Aeronautics

5151 East Memorial Drive

Muncie, IN 47302-9252

Tele. (800) 435-9262

Fax (765) 741-0057

Or via the Internet at: http://www.modelaircraft.org

ASSEMBLE THE MODEL

Install the Main Landing Gear

❑ 1. Note that the main landing gear has an ‘L’ and an ‘R’

on the left and right gear.

❑ 2. Remove the M2.5 x 10mm machine screws.

❑ 3. Attach the main landing gear to the aluminum pivot.

❑ 4. Connect the arms.

❑ 5. Install the main landing gear on the other side.

Install the Horizontal Stabilizer

❑ 1. Insert the tabs into the  n.
