VME 8013

Multimedia Receiver

Thank you for choosing a Audiovox product. We hope you will find the instructions in this owner’s manual clear and easy to follow. If you take a few

minutes to look through it, you’ll learn how to use all the features of your new Audiovox VME 8013 Mobile Multimedia Receiver for maximum

enjoyment.

TABLE OF CONTENTS

Introduction 2

Installation 3

Wiring 5

Front Panel Release 6

Remote Control 7

Operation 9

Radio Operation 10

DISC/MP3/WMA Playback 12

Setup Menu 16

Care and Maintenance 17

Troubleshooting 18

Specifications 20

Subject to technical changes

Introduction

Congratulations on your purchase of the Audiovox VME 8013 Mobile Multimedia Receiver. It’s a good idea to read all of the instructions before

beginning the installation. We recommend having your Audiovox VME 8013 installed by a reputable installation shop.

Installation

This unit is designed for installation in cars, trucks and vans with an existing radio opening. In many cases, a special installation kit will be required

to mount the radio to the dashboard. These kits are available at electronics supply stores and car stereo specialty shops. Always check the kit

application before purchasing to make sure the kit works with your vehicle.

Tools and Supplies

The following tools and supplies are needed to install the radio:

• Torx type, flathead and Philips screwdrivers

• Wire cutters and strippers

• Tools to remove existing radio (screwdriver, socket wrench set or other tools)

• Electrical tape

• Crimping tool

• Volt meter/test light

• Crimp connections

• 18 gauge wire for power connections

• 16-18 gauge speaker wire

Preparation

Disconnect Battery

Before you begin, always disconnect the battery negative terminal.

NOTE:

If the VME 8013 is to be installed in a car equipped with an onboard

drive or navigation computer, do not disconnect the battery cable. If the cable is disconnected, the computer memory may be lost.

Under these conditions, use extra caution during installation to avoid causing a short circuit.

Remove Radio from Sleeve

Lift latches on both sides of sleeve to remove half-sleeve from radio.

Mounting Sleeve Installation

1. Slide the mounting sleeve off the chassis. If it is locked into position,

use the removal tools (supplied) to disengage it.

2. Check the dashboard opening size by sliding the mounting sleeve into it. If the opening is too small, carefully cut or file as necessary until the

sleeve easily slides into the opening. Do not force the sleeve into the opening or cause it to bend or bow. Check for sufficient space behind

the dashboard for the radio chassis.

3. Locate the series of bend tabs along the top, bottom, and sides of the mounting sleeve. With the sleeve fully inserted into the dashboard

opening, bend as many of the tabs outward as necessary to firmly secure the sleeve to the dashboard.

CAUTION: For proper operation of the DVD player, the chassis must be mounted within 20° of horizontal. Make sure the unit is mounted

within this limitation.

4. Place the radio in front of the dashboard opening so the wiring can be brought through the mounting sleeve. Follow the wiring diagram carefully

and make certain all connections are secure and insulated with wire nuts or electrical tape. See “Wiring” on page 5. After completing the wiring

connections, turn the unit on to confirm operation (vehicle ignition must be on). If the unit does not operate, re-check all wiring until the problem is

corrected.

5. Make sure the radio is right-side up, then carefully slide the radio into the mounting sleeve until it is fully seated and the spring clips

lock it into place.
