[TEATRO® TFS1.0 & TCE1.5 FEATURES]
• Wall Mount or Table Top Options Available
• Brushed Black Aluminum Cabinet
• Pressure-Fitted Powder-Coated Aluminum Grille
• 1.5” Deep; Modeled Afer the TSB3.0
INCLUDED IN THE BOX 2
SAFETY INSTRUCTIONS 3
WALL MOUNTING INSTRUCTIONS 4
HOOK UP DIAGRAM FOR THE TCE1.5 SPEAKER 6
CARING FOR YOUR SPEAKERS 6
MAINTENANCE AND SERVICE 7
TROUBLESHOOTING 7
WARRANTY 7
SPECIFICATIONS 8
TEATRO® ULTRA-THIN
OWNER’S MANUAL: TFS1.0 • TCE1.5
2
Thank you for purchasing the Phase Technology TEATRO
® Ultra-Thin
Speakers. These high-denition slim line speakers are the perfect
complement to today’s thin prole at panel TVs. These speakers
incorporate unique technologies to provide you with outstanding
dialogue clarity along with wide open sound stage imaging for a great
home theater experience.
The TEATRO® TSF1.0 or TCE1.5 speaker designs are made to t
seamlessly next to a at panel TV. Both tabletop and wall mounting
options are included with the product. For on-wall applications, the
mounting brackets are adjustable for lining up and vertically leveling
the speaker with the TV. The speaker cabinets also have threaded
inserts for mounting the TEATRO
® speakers to a display wall bracket
mechanism.
The TEATRO® TCE1.5 speakers are designed to be the main front
sound stage in a home theater system by providing 3 channels
from 2 speaker systems. The center channel acoustic information is
created by independent speaker elements located in each speaker
enclosure. This eliminates the need for a center speaker that needs
to be located either under or over the display monitor. The TCE1.5 is
made from an extruded aluminum enclosure that provides several
mounting options. There are threaded brass inserts in the rear of
the cabinet for use with the included wall hanging bracket or smoked
Plexiglass table top stand.
The Teatro TFS1.0 speaker system offers the same audio performance
and utilizes the same extruded aluminum construction as the TCE1.5
speaker system. It is designed to complement the TCE1.5 LCR or
the TSB3.0 Sound Bar speakers as rear channel surround speakers.
In addition the TFS1.0 may be used as main separate front and
surround speakers for a complete 5.1 to 7.2 surround home theater
system. The TFS1.0 may either be hung on the wall with the provided
brackets or placed horizontally on a shelf with the provided feet. The
speaker can also use the optional TPB-1 Plexiglas display stand for
vertical table top placement.
Regardless of application, serious audiophile listening or home
theater, we recommend that you take the time to read this manual
thoroughly before connecting speakers to your amplier or receiver.
In the highly unlikely event that you should experience a problem with
set-up or operation, please contact one of our authorized dealers for
assistance, or contact us directly.
Phase Technology Corporation
8005 W. 110th St., Suite 208
Overland Park, KS 66210
855.663.5600 (Domestic)
+1.913.663.5600 (International)
Fax: 913.663.3200
1. TEATRO TFS1.0 OR TCE1.5
[INCLUDED IN THE BOX:] THE TCE1.5 IS SUPPLIED WITH A TABLE TOP PLEXIGLASS
STAND; THIS STAND IS OPTIONAL FOR THE TFS1.0.
2. Mounting Bracket x2
3. Mounting Pin x2
4. Leveling Screw x2
5. Table Top Mounting Feet
(x2 TFS1.0 ONLY)
6. Table Top Mounting Feet Screws
(x4 TFS1.0 ONLY)
7. Table Top Mounting Screws
(x2 TFS.0 ONLY)
8. Euroblock Connectors
(TFS1.0 x1)
(TCE1.5 x2)
3
1. Read Instructions - All the safety and operating instructions
should be read before the appliance is operated.
2. Retain Instructions - The safety and operating instructions
should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions - All operating and other instructions
should be followed.
5. Water and Moisture - The appliance should not be used near
water - for example, near a bathtub, washbowl, kitchen sink,
laundry tub, in a wet basement, or near a swimming pool, etc.
6. Carts and Stands - The appliance should be used only with a
cart or stand that is recommended by the manufacturer.
PORTABLE CART WARNING
7. Wall or Ceiling Mounting - The appliance should be mounted
to a wall or ceiling only as recommended by the manufacturer.
8. Ventilation - The appliance should be situated so that its
location or position does not interfere with its proper ventilation.
For example, the appliance should not be situated on a bed, sofa,
rug, or similar surface that may block the ventilation openings;
or placed in a built-in installation, such as a bookcase or cabinet
that may impede the ow of air through the ventilation openings.
[SAFETY INSTRUCTIONS] 9. Heat - The appliance should be situated away from heat sources
such as radiators, stoves, or other appliances that produce heat.
10. Power Source - The appliance should be connected to
a power supply only of the type described in the operating
instructions or as marked on the appliance.
11. Power Cord Protection - Power supply cords should be
routed so that they are not likely to be walked on or pinched by
items placed up or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where they
exit from the appliance.
12. Cleaning - The appliance should be cleaned only as
recommended by the manufacturer.
13. Nonuse Periods - The power cord of the appliance should
be unplugged from the outlet when left unused for a long period
of time.
14. Object and Liquid Entry - Care should be taken so that
neither objects fall nor liquids spill into the inside of the appliance.
15. Damage Requiring Service - The application should be
serviced by qualied service personnel when:
a. the power supply cord or the plug has been damaged,
b. objects have fallen onto or liquid has been spilled into the
appliance,
c. the appliance has been exposed to rain,
d. the appliance does not appear to operate normally or exhibits a
marked change in performance, or
e. the appliance has been dropped or the cabinet damaged.
16. Servicing - The user should not attempt to service the
appliance beyond those means described in the operating
instructions. All other servicing should be referred to qualied
service personnel.
17. Grounding or Polarization - Precautions should be taken so
that the grounding or polarization means of an appliance is not
defeated.
Explanation of Graphical Symbols
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert you to the presence
of un-insulated “dangerous voltage: within the products
enclosure that may be off sufcient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert you to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
APPLICABLE FOR USA, CANADA OR WHERE APPROVED FOR
USAGE
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
PLUG TO WIDE SLOT, INSERT FULLY.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE
LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRESE ET POUSSER JUSQU AU FOND.
CAUTION: To reduce the risk of electric shock, do not remove cover
(or back). No user-serviceable parts inside. Refer servicing to qualied
service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Using a 1/16” drill bit, drill a pilot hole at each of your two marks above.
Place one of the wall brackets on the wall and align the pilot hole with the
bottom slot on the bracket and drill a second pilot hole in the center of the
upper slot on the bracket (See Figure 4). This hole will be 7/8” above the
rst pilot hole. Repeat this process for the bracket on the other side. These
pilot holes will let you know if your mounting bracket location is over a wall
stud or not. If it is over a stud then that bracket can be installed with a
suitable screw (for mounting on sheetrock walls, we recommend at least a
#10 x 1.5” pan head screw and a at washer between the screw and the
bracket). If the location for the bracket is not over a wall stud, then suitable
drywall anchors that can support 15 lbs. each must be used.
Following the guidelines above, mount the two brackets to the wall. Once
they are installed check that the center distance between the vertical
mounting slots on the two brackets is exactly as specied in the reference
table. Adjust the brackets with the horizontal slots until on they are the
specied distance apart.
STEP 2-C – TABLE TOP MOUNTING
The TCE1.5 speaker is supplied with a Plexiglas table top stand for vertical
placement; please refer to the instructions included with the stand for
assembly. This stand is optional for the TFS1.0 speaker.
TFS1.0 TABLE TOP FOOT ASSEMBLY
Place your TFS1.0 speaker face down on a soft clean surface. Orient the
speaker so the input terminal is on the right hand side. Attach the Table Top
Mounting Feet to the bottom of the bracket using the two supplied Phillips
Table Top Mounting Feet Screws. Make sure that you orient the feet so
that the longer side extends under the TFS1.0 . Repeat this for (Figure 5)
the other Mounting Bracket and Table Top Mounting Foot. Once you have
the Table Top Mounting Feet securely fastened to the Mounting Brackets,
it is now time to mount them to the TFS1.0. Align the center of the vertical
slot on the Mounting Bracket with the center of threaded brass inserts on
the rear of the speaker and fasten using the supplied Table Top Mounting
Screws, one for each bracket. .(Figure 5)
STEP 3 – SPEAKER HOOKUP
There are Euroblock connector terminals on the rear of the speaker
cabinets. The terminals are marked for Front Input or Center Input on the
TCE1.5 speaker or just Input on the TFS1.0 and should be connected to
the respective speaker channel outputs on your receiver . Be (Figure 8)
careful to observe proper polarity; + (red) on your receiver to + on the
speaker Euroblock connector. Strip about .25” of insulation from the wires
and separate the wires as necessary. Using a small at blade screwdriver,
connect the signal wires to the 2-pin Euro-block connectors, (+) indicates
positive and (-) indicates negative. Please reference your receiver owner’s
manual for proper speaker connection. Make sure the connections are
tight. Tuck the speaker wires behind the speaker cabinets, using tie wraps
if necessary. .(Figure 6)
5
2” 2”
[Figure 3]
FLAT PANEL DISPLAY
[Figure 4]
FLAT PANEL DISPLAY
CENTER
[Figure 5]
[Figure 6]
6
[Figure 8]
TCE1.5
RIGHT
TCE1.5
LEFT
FRONT CENTER FRONT CENTER
A/V RECEIVER
CENTERRF LF
-+ -+ -+
CONNECT CENTER CHANNEL SPEAKER LEADS
IN PARALLEL AT AMPLIFIER
HOOK UP DIAGRAM FOR THE TCE1.5 SPEAKER
RR
-+
LR
-+
TSF1.0
SURROUND
RIGHT
SURROUND
TSF1.0
SURROUND
LEFT
SURROUND
STEP 5
Since the TCE1.5 speaker performs as the front three speakers in a home theater system they are to be used and set up as you would any normal 5.1 to
7.2 surround sound system for balance and level adjustments. For the best performance, the amplier should be set to the small speaker mode for the left/
center/right front speakers. The subwoofer setting should be set between 80 - 100 Hz. We recommended the use of our Phase Technology subwoofers
and the TFS1.0 as the surround speakers to complement the sound and performance of the TCE1.5 or the TSB3.0 sound bar speakers.
STEP 4 – FINAL WALL MOUNTING PROCEDURE
Locate the two holes on the back of the speaker that have the threaded
brass inserts and install the two brass Mounting Pins in these holes (Figure
7). Your TEATRO® speakers are now ready to be mounted to the wall.
Gently slide the Mounting Pins into the vertical mounting slots on the
Mounting Brackets. If necessary, the Leveling Screws may be inserted
in the bottom of the Mounting Bracket and used to adjust the height.
Tightening the screw will raise the speaker and loosening it will lower it.
NOTE: The PHASE TECHNOLOGY grille logo is a separate item with the
TFS1.0 speaker and may be placed on the speaker grille in the appropriate
position depending on whether the speaker is installed vertical or horizontal.
Simply peel the backing off of the logo and place on the grille in the desired
location.
[Figure 7]
[CARING FOR YOUR PHASE TECHNOLOGY SPEAKER]
All Phase Technology speakers are nished with a high degree of craftsmanship in either hand polished paint or vinyl laminates. We recommend using a
lint-free rag with a small amount of glass cleaner to maintain the long-lasting beauty of the nish. Avoid products containing silicones, oils, oil derivatives,
or solvents. Enclosures nished in vinyl laminates may be cleaned with a damp cloth as necessary.
[MAINTENANCE AND SERVICE]
Because of Phase Technology’s uncompromising quality control programs, it’s unlikely that your speakers will ever need service if connected and used
as outlined in this Owners’ Manual. In the unlikely event that a problem does occur, please contact your Phase Technology dealer. Your dealer has the
necessary factory-authorized parts and trained technicians to quickly restore your speaker to its original performance specications.

Termékspecifikációk

Márka: SoundTube
Kategória: Soundbar
Modell: Teatro TFS1.0

Szüksége van segítségre?

Ha segítségre van szüksége SoundTube Teatro TFS1.0, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek




Útmutatók Soundbar SoundTube

Útmutatók Soundbar

Legújabb útmutatók Soundbar
