Oldal 1/8
[TEATRO® TFS1.0 & TCE1.5 FEATURES]
• Wall Mount or Table Top Options Available
• Brushed Black Aluminum Cabinet
• Pressure-Fitted Powder-Coated Aluminum Grille
• 1.5” Deep; Modeled Afer the TSB3.0
INCLUDED IN THE BOX 2
SAFETY INSTRUCTIONS 3
WALL MOUNTING INSTRUCTIONS 4
HOOK UP DIAGRAM FOR THE TCE1.5 SPEAKER 6
CARING FOR YOUR SPEAKERS 6
MAINTENANCE AND SERVICE 7
TROUBLESHOOTING 7
WARRANTY 7
SPECIFICATIONS 8
TEATRO® ULTRA-THIN
OWNER’S MANUAL: TFS1.0 • TCE1.5
2
Thank you for purchasing the Phase Technology TEATRO
® Ultra-Thin
Speakers. These high-denition slim line speakers are the perfect
complement to today’s thin prole at panel TVs. These speakers
incorporate unique technologies to provide you with outstanding
dialogue clarity along with wide open sound stage imaging for a great
home theater experience.
The TEATRO® TSF1.0 or TCE1.5 speaker designs are made to t
seamlessly next to a at panel TV. Both tabletop and wall mounting
options are included with the product. For on-wall applications, the
mounting brackets are adjustable for lining up and vertically leveling
the speaker with the TV. The speaker cabinets also have threaded
inserts for mounting the TEATRO
® speakers to a display wall bracket
mechanism.
The TEATRO® TCE1.5 speakers are designed to be the main front
sound stage in a home theater system by providing 3 channels
from 2 speaker systems. The center channel acoustic information is
created by independent speaker elements located in each speaker
enclosure. This eliminates the need for a center speaker that needs
to be located either under or over the display monitor. The TCE1.5 is
made from an extruded aluminum enclosure that provides several
mounting options. There are threaded brass inserts in the rear of
the cabinet for use with the included wall hanging bracket or smoked
Plexiglass table top stand.
The Teatro TFS1.0 speaker system offers the same audio performance
and utilizes the same extruded aluminum construction as the TCE1.5
speaker system. It is designed to complement the TCE1.5 LCR or
the TSB3.0 Sound Bar speakers as rear channel surround speakers.
In addition the TFS1.0 may be used as main separate front and
surround speakers for a complete 5.1 to 7.2 surround home theater
system. The TFS1.0 may either be hung on the wall with the provided
brackets or placed horizontally on a shelf with the provided feet. The
speaker can also use the optional TPB-1 Plexiglas display stand for
vertical table top placement.
Regardless of application, serious audiophile listening or home
theater, we recommend that you take the time to read this manual
thoroughly before connecting speakers to your amplier or receiver.
In the highly unlikely event that you should experience a problem with
set-up or operation, please contact one of our authorized dealers for
assistance, or contact us directly.
Phase Technology Corporation
8005 W. 110th St., Suite 208
Overland Park, KS 66210
855.663.5600 (Domestic)
+1.913.663.5600 (International)
Fax: 913.663.3200
1. TEATRO TFS1.0 OR TCE1.5
[INCLUDED IN THE BOX:] THE TCE1.5 IS SUPPLIED WITH A TABLE TOP PLEXIGLASS
STAND; THIS STAND IS OPTIONAL FOR THE TFS1.0.
2. Mounting Bracket x2
3. Mounting Pin x2
4. Leveling Screw x2
5. Table Top Mounting Feet
(x2 TFS1.0 ONLY)
6. Table Top Mounting Feet Screws
(x4 TFS1.0 ONLY)
7. Table Top Mounting Screws
(x2 TFS.0 ONLY)
8. Euroblock Connectors
(TFS1.0 x1)
(TCE1.5 x2)
3
1. Read Instructions - All the safety and operating instructions
should be read before the appliance is operated.
2. Retain Instructions - The safety and operating instructions
should be retained for future reference.
3. Heed Warnings - All warnings on the appliance and in the
operating instructions should be adhered to.
4. Follow Instructions - All operating and other instructions
should be followed.
5. Water and Moisture - The appliance should not be used near
water - for example, near a bathtub, washbowl, kitchen sink,
laundry tub, in a wet basement, or near a swimming pool, etc.
6. Carts and Stands - The appliance should be used only with a
cart or stand that is recommended by the manufacturer.
PORTABLE CART WARNING
7. Wall or Ceiling Mounting - The appliance should be mounted
to a wall or ceiling only as recommended by the manufacturer.
8. Ventilation - The appliance should be situated so that its
location or position does not interfere with its proper ventilation.
For example, the appliance should not be situated on a bed, sofa,
rug, or similar surface that may block the ventilation openings;
or placed in a built-in installation, such as a bookcase or cabinet
that may impede the ow of air through the ventilation openings.
[SAFETY INSTRUCTIONS] 9. Heat - The appliance should be situated away from heat sources
such as radiators, stoves, or other appliances that produce heat.
10. Power Source - The appliance should be connected to
a power supply only of the type described in the operating
instructions or as marked on the appliance.
11. Power Cord Protection - Power supply cords should be
routed so that they are not likely to be walked on or pinched by
items placed up or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point where they
exit from the appliance.
12. Cleaning - The appliance should be cleaned only as
recommended by the manufacturer.
13. Nonuse Periods - The power cord of the appliance should
be unplugged from the outlet when left unused for a long period
of time.
14. Object and Liquid Entry - Care should be taken so that
neither objects fall nor liquids spill into the inside of the appliance.
15. Damage Requiring Service - The application should be
serviced by qualied service personnel when:
a. the power supply cord or the plug has been damaged,
b. objects have fallen onto or liquid has been spilled into the
appliance,
c. the appliance has been exposed to rain,
d. the appliance does not appear to operate normally or exhibits a
marked change in performance, or
e. the appliance has been dropped or the cabinet damaged.
16. Servicing - The user should not attempt to service the
appliance beyond those means described in the operating
instructions. All other servicing should be referred to qualied
service personnel.
17. Grounding or Polarization - Precautions should be taken so
that the grounding or polarization means of an appliance is not
defeated.
Explanation of Graphical Symbols
The lightning ash with arrowhead symbol, within an
equilateral triangle, is intended to alert you to the presence
of un-insulated “dangerous voltage: within the product’s
enclosure that may be off sufcient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert you to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
APPLICABLE FOR USA, CANADA OR WHERE APPROVED FOR
USAGE
CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
PLUG TO WIDE SLOT, INSERT FULLY.
ATTENTION: POUR EVITER LES CHOCS ELECTRIQUES, INTRODUIRE
LA LAME LA PLUS LARGE DE LA FICHE DANS LA BORNE
CORRESPONDANTE DE LA PRESE ET POUSSER JUSQU AU FOND.
CAUTION: To reduce the risk of electric shock, do not remove cover
(or back). No user-serviceable parts inside. Refer servicing to qualied
service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
