Oldal 1/21
Model: MCT-70QDS, MCT-70QDS-POE, MCT-70HPQ, MCT-70HPQ-POE
Please keep this manual for future reference.
TABLE OF CONTENTS
PAGE
DECLARATION……………....…………………..............……………............…....1
PRODUCT INSTRUCTIONS……….......……..............…………………....………………1
POWERING ON THE PRODUCT………...........………………………...….....….……….2
INSERTING THE SD CARD.....………………….................………………………………3
INSERTING USB DEVICES……………..................……………......…………….……….3
HOME SCREEN.......………..…………….....................………….…......................……4
COMBINED SYSTEM BAR…....................................................................................8
USE APPS............................................................................................................…11
LANGUAGE………………......…............................................................……12
DATE & TIME……………….....….......….............................…...................................13
VOLUME………………......….......….............................…...................................14
WI-FI....................………………......….......….............................................19
ETHERNET....................………………......….......….............................................20
VIRTUAL KEYBOARD....................…....……………......…........................................23
SWITCH INPUT METHODS......................………......….......…................................24
SURF ONLINE................………………......….......….................................................29
BROWSE FILES................………………......….......…...............................................30
PLAY MEDIA................………………......….......…...................................................31
RESET TO FACTORY DEFAULT................………....................................................36
Adapt-IQ 7” User’s Manual
Mimo Monitors
info@mimomonitors.com
Sales: 1-855-YES-MIMO (937-6466)
1
Declaration
Please read the instructions carefully before equipment installation and
using the device.
Do not put the product in high temperature, humid or dusty environment.
Do not drop, crash or break down this product.
Do not power off the device when it’s formatting or upgrading, otherwise it
will cause operation system error.
This product is not waterproof.
Use only approved add- enhancements. on
1. Camera (optional): 2M pixel camera
2. LED Indicator:
Red System is booting.
Green System is working properly.
Light Off Power supply is off.
3. SD Card Slot / Cover: support external SD card
4. Escape Button: return to the previous page
5. Function Keys (Up / Down): select the up/down item
6. Function Keys (Vol+ / Vol-): adjust the system volume
7. Speaker: audio output
8. VESA Mount Holes : for installing the bracket
9. JackDC In : powered by 12V/2A DC input
10. Ethernet RJ45 Port: support Ethernet connection (10/100Mbps LAN)
11. USB Port: support USB 2.0 high speed 480Mbps
12. Micro-USB Port: support USB 2.0 high speed 480Mbps
13. Power Switch: switch power ON/OFF
14. -on module slot:Add to put optional - add on module
15. Headset + Microphone Jack
16. WIFI: 802.11b/g/n/ac 2.4G
17. Temperature：
：
：
：
：
Operation: 0 ( 32F ~104F) ℃~ 40℃
Storage: -10°C ~ 55°C (14°F ~ 131°F)
Product Instruction
Mimo Monitors
info@mimomonitors.com
Sales: 1-855-YES-MIMO (937-6466)
2
Mechanical Design
1. Wi-Fi Antenna
2. Speakers x 2 (8-ohm, 2W)
3. COM2 (RS-232)
4. COM1 (RS-232)
5. Power Switch
6. VESA mount (75mm x 50mm)
7. LAN
8. Micro USB
9. GPIO
10. Mini HDMI
11. USB Type-A
12. DC Power IN
13. COM1 (RS-232)
14. COM2 (RS-232)
15. Power LED
16. USB Type-A
1
22
3
4
5
6
7 8 9 10 11 12
13 14
15 16
