Oldal 1/21

Instruction Manual • Bedienungsanleitung • Manuel d’utilisation • Manuale di Istruzioni

F4U Corsair S

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product litera-

ture, visit www.horizonhobby.com and click on the support tab for this product.

NOTICE

The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product:

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or no possibility of injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a possibility of serious injury.

WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral damage, and serious injury OR create a high

probability of superﬁ cial injury.

Meaning of Special Language:

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before operating. Failure to operate the product

correctly can result in damage to the product, personal property and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and requires some basic mechanical ability. Failure to operate

this Product in a safe and responsible manner could result in injury or damage to the product or other property. This product is not intended for use by

children without direct adult supervision. Do not use with incompatible components or alter this product in any way outside of the instructions provided

by Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and

warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or serious injury.

Safety Precautions and Warnings

As the user of this product, you are solely responsible for operating in a manner

that does not endanger yourself and others or result in damage to the product

or the property of others.

• Always keep a safe distance in all directions around your model to avoid

collisions or injury. This model is controlled by a radio signal subject to

interference from many sources outside your control. Interference can cause

momentary loss of control.

• Always operate your model in open spaces away from full-size vehicles, traf-

ﬁ c and people.

• Always carefully follow the directions and warnings for this and any optional

support equipment (chargers, rechargeable battery packs, etc.).

• Always keep all chemicals, small parts and anything electrical out of the

reach of children.

• Always avoid water exposure to all equipment not speciﬁ cally designed and

protected for this purpose. Moisture causes damage to electronics.

• Never place any portion of the model in your mouth as it could cause serious

injury or even death.

• Never operate your model with low transmitter batteries.

• Always keep aircraft in sight and under control.

• Always use fully charged batteries.

• Always keep transmitter powered on while aircraft is powered.

• Always remove batteries before disassembly.

• Always keep moving parts clean.

• Always keep parts dry.

• Always let parts cool after use before touching.

• Always remove batteries after use.

• Always ensure failsafe is properly set before ﬂ ying.

• Never operate aircraft with damaged wiring.

• Never touch moving parts.

Charging Warnings

CAUTION: All instructions and warnings must be followed exactly.

Mishandling of Li-Po batteries can result in a ﬁ re, personal injury,

and/or property damage.

• By handling, charging or using the included Li-Po battery, you assume all

risks associated with lithium batteries.

• If at any time the battery begins to balloon or swell, discontinue use im-

mediately. If charging or discharging, discontinue and disconnect. Continuing

to use, charge or discharge a battery that is ballooning or swelling can result

in ﬁ re.

• Always store the battery at room temperature in a dry area for best results.

• Always transport or temporarily store the battery in a temperature range of

40–120º F (5–49º C). Do not store battery or aircraft in a car or direct sun-

light. If stored in a hot car, the battery can be damaged or even catch ﬁ re.

• Always charge batteries away from ﬂ ammable materials.

• Always inspect the battery before charging and never charge dead or dam-

aged batteries.

• Always disconnect the battery after charging, and let the charger cool

between charges.

• Always constantly monitor the temperature of the battery pack while

charging.

• ONLY USE A CHARGER SPECIFICALLY DESIGNED TO CHARGE LI-PO BATTER-

IES. Failure to charge the battery with a compatible charger may cause ﬁ re

resulting in personal injury and/or property damage.

• Never discharge Li-Po cells to below 3V under load.

• Never cover warning labels with hook and loop strips.

• Never leave charging batteries unattended.

• Never charge batteries outside recommended levels.

• Never attempt to dismantle or alter the charger.

• Never allow minors under the age of 14 to charge battery packs.

• Never charge batteries in extremely hot or cold places (recommended

between 40–120° F or 5–49° C) or place in direct sunlight.

14+AGE RECOMMENDATION:

Not for children under 14

years. This is not a toy.

WARNING AGAINST COUNTERFEIT PRODUCTS: If you ever need to replace a Spektrum component found

in a Horizon Hobby product, always purchase from Horizon Hobby, LLC or a Horizon Hobby authorized dealer to

ensure authentic high-quality Spektrum product. Horizon Hobby disclaims all support and warranty with regards,

but not limited to, compatibility and performance of counterfeit products or products claiming compatibility with

DSM or Spektrum.

BNF • RTF

F4U Corsair S EN

Fly in this area

(upwind of pilot)

Stand here

600 feet

(183 m)

For more information and to register your product online, visit www.hobbyzonerc.com

Wind 0–7 mph

(0–11km/h)

• Sensor Assisted Flight Envelope (SAFE™) technology

is designed as ﬂ ight assistance, not an autopilot.

The pilot is always in control and required to ﬂ y the

aircraft at all times.

• Start in Beginner mode (SAFE switch position 0).

As you learn and become more conﬁ dent, change

modes to advance your ﬂ ying skills.

• Always keep your aircraft in plain sight and upwind

from you.

• Do not attempt your ﬁ rst turn at low altitude. Higher

altitudes allow for greater possibility of correction.

• Always make deliberate and steady control stick

movements for smooth control of your aircraft.

Flying Tips

Preﬂ ight Checklist 9

1. Find a safe and open area.

2. Charge ﬂ ight battery.

3. Install ﬂ ight battery in aircraft.

4. Perform Control Direction Test.

5. Plan ﬂ ight for ﬂ ying ﬁ eld conditions.

6. Have fun!

Included in the Box

Includes

Transmitter
