Oldal 1/4
60Kgs
Weight capacity
Fitting instructions
Halfords Exodus 360, 470, 580 roof boxes
3DF/4.W51.2011.1800350200
x4 x4 x4 x1 x2
Ensure that the
roof box you have
purchased will t your
car and that your roof
bars are of a suitable
size to t the tting kit
supplied with this roof
box.
Which roof box will t your vehicle?
See table for
dimensions
A, B & C for
your roof box
Exodus
boxes
Min ’A’
Max ‘B’
Min ’C’
Dimension A Dimension B Dimension C
Exodus 360 550mm 980mm 465mm
Exodus 470 550mm 980mm 700mm
Exodus 580 550mm 980mm 750mm
Roof bar types
Max 80 mm
Min 18 mm
Max 35 mm
Min 18 mm
Max 35 mm
Max 80 mm
Always secure the load by use of
the internal straps
Mounting instructions for the quick t system supplied with the Exodus roof boxes.
1 3
2 4
5
