Oldal 1/4
08/51232/0 Issue 7
OCN:11640
MINICUBE
AUS/NZ
1
2
205
330
370
1
23
I
I
I
I
I
II
II
II
II
II
IMPORTANT : THESE INSTRUCTIONS SHOULD BE READ CAREFULLY AND RETAINED FOR FUTURE REFERENCE
Important Safety Advice
When using electrical appliances, basic
precautions should be followed to reduce
the risk of re, electric shock, and injury to
persons, including the following:
Do not use it there are visible signs of damage,
check immediately with the supplier before
installation and operation.
Do not use this appliance in the immediate
surroundings of a bath, shower or swimming
pool.
Do not use outdoors.
Do not use this heater if it has been dropped.
This appliance must not be located immediately
above or below a fixed socket outlet or
connection box.
WARNING : The appliance carries
the Warning Symbol indicating that it
must not be covered or has a Do not
cover label. Do not cover or obstruct in
any way the heat outlet grille located
underneath the appliance, overheating
will result if the appliance is accidentally
covered. Do not place material or garments
on the appliance, or obstruct the air circulation
around the appliance, for instance by curtains
or furniture, as this could cause overheating
and a re risk.
In the event of a fault unplug the heater.
Unplug the appliance when not required for
long periods.The supply cord must be placed
on the right hand side of the heater away from
the heat outlet underneath the appliance.
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
Children should be supervised to ensure that
they do not play with the appliance.
Cleaning and user maintenance shall not be
made by Children.
The appliance must be positioned so that the
plug is accessible.
If the supply cord is damaged it must be
replaced by the manufacturer or service agent
or similarly qualied person in order to avoid
a hazard.
Use this applaince on a horizontal and stable
surface, or x to the wall, as applicable.
Although this heater complies with safety
standards, we do not recommend its use on
deep pile carpets or on long hair type of rugs.
Warning: Do not use the heater in small
rooms when they are occupied by persons
not capable of leaving the room on their own,
unless constant supervision is provided.
CAUTION: In order to avoid a hazard due to
inadvertent resetting of the thermal cut-out,
this appliance must not be supplied through an
external switching device, such as a timer, or
connected to a circuit that is regularly switched
on and o󰀨 by the utility.
Warning: To reduce the risk of fire, keep
textiles,curtains, or other ammable material
a minimum distance of 1m from the air outlet.
CAUTION - Some parts of this product can
become very hot and cause burns. Particular
attention has to be given where children and
vulnerable people are present.
This instruction can be found at
www.dimplex.com.au &
www.dimplex.co.nz
Technical Information
General
Unpack the heater carefully and retain the packaging for possible future use,
in the event of moving or returning the re to your supplier.
The re incorporates a ame e󰀨ect, which can be used with or without heating,
so that the comforting e󰀨ect may be enjoyed at any time of the year. Using
the ame e󰀨ect on its own requires very little electricity.
These models are designed to be free standing and are normally positioned
against a wall.
Before connecting the heater check that the supply voltage is the same as
that stated on the heater.
Please note: Used in an environment where background noise is very low,
it may be possible to hear a sound which is related to the operation of the
ame e󰀨ect.
This is normal and should not be a cause for concern.
Electrical connection
WARNING – THIS APPLIANCE MUST BE EARTHED.
This heater must be used on an AC ~ supply only and the voltage marked on
the heater must correspond to the supply voltage.
Before switching on, please read the safety warnings and operating
Instructions.
Model No: MCF15, MINICUBE
Heat Output 230V 240V
Nominal Heat Output P Nom 1.3 - 1.4 kW
Minimum Heat Output P min 0.7 - 0.7 kW
Maximum Continous Heat Output P max,c 1.3 - 1.4 kW
Auxiliary Electricity Consumption
In Standby mode el SB 0.86 - 0.90 W
