©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective holders. Software and
specifications subject to change without notice. DSA-3100P 09052003
If any of the above items are missing, please contact your reseller.
Before You Begin
DSA-3100P Ticket Printer
with Paper Roll
Check Your Package Contents
DSA-3100P
Ticket Printer for DSA-3100
RS-232 Serial Communication Cable
Using a power
supply with a
different voltage rating
will damage this
product and void its
warranty.
This product can be setup using
any current web browser, i.e.,
Internet Explorer 6 or Netscape
Navigator 7.0
You will need a DSA-3100 Public/Private Gateway with a wireless access point
pre-installed.
Important: TURN OFF the power to the DSA-3100 before
installing the DSA-3100P. The DSA-3100P can only work with
the D-Link DSA-3100 Public/Private Gateway
24V DC, 1.7A Power Adapter
2
Pull down on the green
handle to release the
cover.
Insert the roll of paper
Preparing the DSA-3100P
3
Pull some of the paper
out and close the cover.
Connect to the DSA-3100 with the provided RS-232 serial cable. On
the other side of the RS-232 cable, plug in the RJ-11 connector into
the DSA-3100P Ticket Printer.
Attach the power adapter and turn the DSA-3100P on. Then power
on the DSA-3100 and all wireless access points. Wait 1~2 minutes
until the status LED on the DSA-3100 becomes stable.
RJ-11 Connector
Power Connector
P/S2 Connector
Preparing the DSA-3100P(cont.)
