Oldal 1/2
100% 6500K
CCT
Wireless Connection
Status Icon
Battery Life
Color Temperature
Brightness
① Power & Mode Switch Button
Long press for 3 seconds to turn on/o the product.
When the product is on, short press to switch between 2 light modes,
CCT and EFF mode.
② Dial
Long press down to make a wireless connection.
Roll upwards to increase value, and downwards to decrease value.
③ Brightness Control
For 0%~100% brightness adjustment.
④ Type-C DC Input
Used to charge this product and supports 5V 2A input at maximum.
Charging time varies depending on the power of the charger.
⑤ Type-A DC Output
Supports maximum output 5V 2A to power other devices. External power
supply will aect the runtime of the product itself.
Please prepare the corresponding charging cable by yourself to charge
① Color Temperature Control (2700K-6500K):
Roll the Dial upwards or downwards
CCT Mode
Bi-Color LED Light User Manual
Thank you for choosing COLBOR product. Please read this manual
carefully before use and follow all instructions mentioned herein.
PL8B
Caring For Your COLBOR Product Operation Instructions
Interface Introduction
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the
product to prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians
if any malfunctions happened.
Please remove the USB charging cable when the battery is fully charged.
The product might get hot during use, which is normal. Please allow
certain space for heat-sink when using it.
If you do not use the product for a long time, it might not be able to
turn on instantly due to dead battery. Please charge the product and
it can resume to work. Please charge the product every 3 months
regularly.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
other devices. The power management of dierent devices will control the
output voltage and current.
⑥ 1/4” Screw Hole
⑦ Cold Shoe
⑧ Display Screen
Wireless Connection:
1. Download COLBOR Studio APP from our website
2. Long press down the Dial on the light to make a wireless connection
with APP
Long press
Specications
Package List
Color Rendering Index (CRI)
Color Temperature Range
Number of bead
Display Screen
Power
＞95
2700K-6500K
60
OLED 23*13mm
8W
PL8B LED Light x1
Packing
Bag x1
User
Manual x1
Cold Shoe
Mount x1
Type-C Charging
Cable x1
Magnetic
Metal Plate x1
Light Diuser x1
WARRANTY
Warranty Period
Thank you for purchasing COLBOR products.
1. Customers are entitled to free replacement or repair service in case of quality
defect(s) found in the product under normal use within 30 days upon receipt of
the product.
2. Original COLBOR products are entitled to 12-month limited warranty service.
The warranty period begins on the date of purchase of brand new, unused
products by the rst end-user.
Within the warranty period, if product defect or failure is attributable to material
defection or technological problem, the defective product or defective part will
be repaired or replaced without charge (service and materials fee).
Warranty Exclusions and Limitations
1. Faults resulted from inappropriate use of a product without following its
operation specication
2. Articial damage, e.g. crash, squeeze, scratch, or soaking
3. Modications to a product by its user or a third party without prior written
consent of COLBOR, e.g. replacement of element or circuit, label alteration
4. The code on product is inconsistent with that of warranty certicate, or the
code on the product or warranty certicate is altered or torn o
5. All consumable accessory attached to a product, like cable, wind mu, battery
6. Faults as a result of force majeure, such as re, ood, lightning, etc.
Warranty Claim Procedure
1. If failure or any problem occurs to your product after purchase, please contact
a local agent for assistance, or you can always contact COLBOR’s customer
service through email.
2. Please retain your sales receipt and warranty certicate as proof of purchase.
If any of these documents is missing, only sales return or chargeable service will
be provided.
3. If the COLBOR product is out of the warranty coverage, the service and the
parts cost will be charged.
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to contact us via
Email.
Customer Name:
Phone Number:
Email:
Address:
Service Date:
Technician:
Issue:
Sales Date:
Model:
Product Code:
Dealer:
Solved Unsolved Returned(Replaced)
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000
support@colborlight.com
www.colborlight.com
Guangzhou Zhiying Technology Co., Ltd
100% 123
EFF
Wireless Connection
Status Icon
Battery Life
Frequency
Brightness
Special Eect
① In CCT mode, press the Mode Switch Button once to enter EFF
mode.
② Special eect switch
Short press down the Dial.
Special Eect: Fire → CCT Chase → Pulsing → TV → Explosion →
Faulty Bulb → Welding → Strobe → Lightning → SOS
③ Frequency Control:
Roll the Dial upwards or downwards
(Note: In SOS eect, frequency control is unavailable.)
④ Brightness Control (0%~100%):
Roll the Brightness Control upwards or downwards.
EFF Mode
Battery Capacity
Runtime
Cooling Mode
Power Input
Power Output
Input&Output Voltage/Current
Battery Charging Time
Working Voltage
Power Requirement
Housing Material
Dimension
Net Weight
Operating Temperature
5000mAh
About 125 minutes at 100% brightness
Passive
Type-C
Type-A
5V/2A (Max)
About 3 Hours
3.7V
Built-in Lithium Battery /DC Power Supply
ABS
125x75x17mm
187g
-10-50℃
② Brightness Control (0%~100%):
