Használati útmutató COLBOR PL5
Olvassa el alább 📖 a magyar nyelvű használati útmutatót COLBOR PL5 (2 oldal) a Vaku kategóriában. Ezt az útmutatót 6 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra
Oldal 1/2
WARRANTY CERTIFICATE
USER
INFORMATION
SALES
INFORMATION
REPAIR RECORD
RESULT
Please register your warranty. Meanwhile, you are welcomed to contact us via Email.
Customer Name:
Phone Number:
Email:
Address:
Service Date:
Technician:
Issue:
Sales Date:
Model:
Product Code:
Dealer:
Solved Unsolved Returned(Replaced)
P L 5 Pocket Fill Light
Thank you for choosing COLBOR product. Please read this manual
carefully before use and follow all instructions mentioned herein.
3.Modications to a product by its user or a third party without prior written
consent of COLBOR, e.g. replacement of element or circuit, label alteration
4.The code on product is inconsistent with that of warranty certicate, or the
code on the product or warranty certicate is altered or torn o
5.All consumable accessory attached to a product, like cable, cover
6.Faults as a result of force majeure, such as re, ood, lightning, etc.
Warranty Claim Procedure
1. If failure or any problem occurs to your product after purchase, please
contact a local agent for assistance, or you can always contact COLBOR’s
customer service through email.
2. Please retain your sales receipt and warranty certicate as proof of
purchase. If any of these documents is missing, only sales return or chargeable
service will be provided.
3. If the COLBOR product is out of the warranty coverage, the service and the
parts cost will be charged.
Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000
support@colborlight.com
www.colborlight.com
Guangzhou Zhiying Technology Co., Ltd
Caring For Your COLBOR Product
Interface Introduction
Specications
Package List
WARRANTY
Operation Instructions
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the product to
prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians if any
malfunctions happened.
Please remove the USB charging cable when the battery is fully charged.
The product might get hot during use, which is normal. Please allow certain
space for heat-sink when using it.
If you do not use the product for a long time, it might not be able to turn on
instantly due to dead battery. Please charge the product and it can resume to
work. Please charge the product every 3 months regularly.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
Warranty Period
Thank you for purchasing COLBOR products.
1. Customers are entitled to free replacement or repair service in case of
quality defect(s) found in the product under normal use within 30 days upon
receipt of the product.
2. Original COLBOR products are entitled to 12-month limited warranty service.
The warranty period begins on the date of purchase of brand new, unused
products by the rst end-user.
Within the warranty period, if product defect or failure is attributable to material
defection or technological problem, the defective product or defective part will
be repaired or replaced without charge (service and materials fee).
Warranty Exclusions and Limitations
1.Faults resulted from inappropriate use of a product without following its
operation specication
2.Articial damage, e.g. crash, squeeze, scratch, soaking, exposing to rain or
damp
In CCT Mode, you can choose to adjust brightness or color temperature by
pressing down the dial.
Increase or decrease the brightness and color temperature by rolling the dial
upwards or downwards.
In CCT Mode, press the mode switch button once to enter EFF Mode.
Press down the dial to switch among subordinate mode, brightness and special
eect, and roll the dial to adjust.
Subordinate Mode: Lightning and Fire
Each mode contains 3 special eects, amount to 6 special eects.
① Power & Mode Switch Button
Long press this button to turn on/o
the product.
When the product is on, short press this
button to switch between 2 light modes,
CCT Mode and EFF Mode.
② Display Screen
③ Dial
Press down the dial to choose the
option to be adjusted.
Roll the dial upwards to increase the
value, and downwards to decrease the
value.
④ Type-C Charging Port
⑤ 1/4” Screw Hole
⑥ Magnetic Back
Used for attaching the light to smartphones with the metal plate.
CCT Mode
EFF Mode
Remaining Runtime Battery Life
Current Brightness
PL5 LED
Video Light p2-x1
Type-C Charging
Cable p2-x1
Packing
Bag x1
Metal Plate x2Cold Shoe
Mount x1
Current Color Temperature
Subordinate Mode Brightness
Special Eect Current Option
Remaining Runtime Battery Life
Body Material: ABS
Dimension (mm): 110*65*15 (L*W*H)
Color Rendering Index: Ra ≥ 95
Charging Port: Type-C
Power: 5W
Number of bead: 48 pieces
Runtime: 100% brightness for about 90 minutes
Color Temperature Range: 2700K-6500K (±100K)
Weight: 110g
Illumination: 1500Lux (at 30cm 6500K)
Battery Capacity: 2100mAh
Charging Time: 2.5H
Input Voltage: 5V/1A
