Oldal 1/4
Practicing with the Metronome
1
2
Specify a beat value.
C2 C3E1 C5 C6 C7 G7C4
CT-S1-76
CT-S1
− +
off, 1 - 16
While holding down...
3
Specify the tempo.
Example: To set a tempo of 80, press 8 (D5) and then 0 (C4), and then release METRONOME.
C2 C3E1 C5 C6 C7 G7C4 D4 E4 F4 G4 A4 B4 D5 E5
CT-S1-76
CT-S1
0 1 2 3 4 5 6 7 8 9
20 - 255
While holding down...
Quick Start Guide
After reading this document, keep it in a safe place along with the warranty
certificate. Be sure to read the “Safety Precautions” in the separate “READ THIS!”
sheet, and use the product correctly.
EN
Preparation
Basic Operation
Useful Functions
For details about operations, refer to the User’s Guide on the CASIO Website.
My Setup
Save the current setup (tone, etc.) for later recall.
Reverb
Output sounds using room, hall, and other acoustic effects.
Octave Shift
Raise or lower the pitch of the keyboard in octave units.
Transpose
Raise or lower the overall pitch in semitone steps.
Scale Tuning (Temperament)
You can set the scale tuning of the keyboard for music that uses a scale tuning other than
equal temperament.
Selecting a Tone
To use the main tones to select an instrument
1
2
Select a variation.
Press to cycle through
available variations.
See the procedure below for information
about using Tone Memory.
To select a tone using the keyboard keys
C2 C3E1 C5 C6 C7 G7C4
CT-S1-76
CT-S1
While holding down...
PIANO E.PIANO ORGAN KEYBOARD SYNTH/OTHERS CASIO CLASSIC TONES
Registering the Current Main Tone Setup to a Button (Tone Memory)
While holding down...
Press the button of the tone you want to register.
Preparing a Power Supply
Using the AC Adaptor
1
Connect the AC adaptor as shown in the right illustration.
●Make sure that you use only the AC adaptor specified
for this Digital Keyboard.
Using Batteries
1
Open
Bottom of console
2
Insert AA-size batteries into the battery case (CT-S1-76:
8 batteries/CT-S1: 6 batteries).
3
Tabs
Close
4
Specify the battery type.
See “Specifying the Battery Type” on the reverse side of
this sheet.
Auto Power Off
Automatically turns off power after 20 minutes
* of non-
use. (On, Off switchable)
*
30 minutes for the CT-S1
Pedal
Sustains notes played while the pedal is depressed.
Even if the keys played are released, notes are
sustained as if the keys remain pressed, until the pedal
is released.
Touch Response
Pressing a key harder produces louder sound, while a
softer key press produces softer sound.
P(Power) button
Press to turn on power.
Long-press to turn off
power.
METRONOME
button
Press to sound the
metronome.
Main tone buttons
Press a button to select
its tone.
TONE VARIATION
button
Press to change to a
different variation of the
currently selected tone.
SURROUND button
Press for a more
expanded sound.
(Disabled while
headphones are
connected.)
VOLUME knob
Rotate to adjust overall
volume.
CT-S1-76/CT-S1
Please refer to the website below for more detailed operating instructions
and product information, including the USERʼS GUIDE, Dedicated App
(CASIO MUSIC SPACE) download, Operating Precautions, etc.
https://support.casio.com/global/en/emi/manual/CT-S1-76/ https://support.casio.com/global/en/emi/manual/CT-S1/
CT-S1-76 CT-S1
Included Accessories
●AC adaptor
xAD-A12150LW (CT-S1-76)
xAD-E95100L (CT-S1)
●Power cord (CT-S1-76 only)
●Music Stand
●Strap Lock (CT-S1 only)
●Leaflets
xREAD THIS! Sheet
xOther (Warranty, etc.)
Items included as accessories are subject to change without notice.
Separately Available Accessories
You can get information about accessories that are separately available for this product from your retailer
or from the CASIO website.
Computer, smartphone, etc. (commercially available)
• Connect using a USB cable that is no more than
two meters long.
AC adaptor *
Headphones (sold separately)
Portable audio player, etc. (commercially available)
Pedal (sold separately)
Back
To install the music stand
Insert the stand into the holes on
the back of the console.
Wireless MIDI & audio adaptor
(sold separately: WU-BT10)
*For the CT-S1-76, connect the power cord to the AC adaptor.
●The illustration shows the CT-S1. The CT-S1 has 61 keys; the CT-S1-76 has 76 keys.
Playing with Two Layered Tones
1
C2
C3
E1 C5 C6 C7 G7C4
CT-S1-76
CT-S1
While holding down...
Off/On
Layers the tones.
Low tone: Off
High tone: On
2
C2 C3E1 C5
C6
C7 G7C4
CT-S1-76
CT-S1
C2 C3E1 C5 C6 C7 G7C4
CT-S1-76
CT-S1
While holding down...
Select the tone to layer.
PIANO E.PIANO ORGAN KEYBOARD SYNTH/OTHERS CASIO CLASSIC TONES
Keeping FUNCTION depressed, press the tone you want to layer.
Playing with Touch Response
C2 C3E1 C5 C6 C7 G7C4
CT-S1-76
CT-S1
While holding down...
Off, 1 (Light), 2 (Normal), 3 (Heavy)
One low tone: Off
One high tone: Light
Two high tones: Normal
Three high tones: Heavy
Off: No Touch Response.
Light: Louder notes with lighter touch than Normal.
Normal: Normal Touch Response.
Heavy: Louder notes require a heavier touch than Normal.
Using the Dedicated App (CASIO MUSIC SPACE)
Enjoy a range of fun functions using the Digital Keyboard together with the
CASIO MUSIC SPACE app. Please visit the “Downloads” section of our website.
Only the CT-S1-76 is compatible with the Remote Controller, which allows remote control of
functions and settings on the Digital Keyboard via an app.
●The WU-BT10 (sold separately) or a commercially available USB cable is required to
connect the Digital Keyboard to a smart device.
Reference
Product Specifications
Model: CT-S1-76BK/CT-S1-76WE
Keyboard: 76 keys
Acoustics: Amp output: 6.5W + 6.5W
Speakers: 13cm × 6cm (oval) × 2
Power Supply: 2-way power supply
Batteries: 8 AA-size alkaline batteries or AA-size rechargeable nickel metal hydride
batteries
AC Adaptor: AD-A12150LW
Power consumption: 12V = 10W
Dimensions: 114.0(W) × 25.8(D) × 8.3(H) cm (44 7/8 × 10 3/16 × 3 1/4 inch)
Weight: Approximately 5.3 kg (11.7 lbs) (Excluding batteries)
Model: CT-S1BK/CT-S1WE/CT-S1RD
Keyboard: 61 keys
Acoustics: Amp output: 2.5W + 2.5W
Speakers: 13cm × 6cm (oval) × 2
Power Supply: 2-way power supply
Batteries: 6 AA-size alkaline batteries or AA-size rechargeable nickel metal hydride
batteries
AC Adaptor: AD-E95100L
Power consumption: 9.5V = 7.5W
Dimensions: 93.0(W) × × 8.3(H) cm (36 5/8 × × 3 1/4 inch)25.8(D) 10 3/16
Weight: Approximately 4.5 kg (9.9 lbs) (Excluding batteries)
Specifications and designs are subject to change without notice.
0Any reproduction of the contents of this manual, either in part or its entirety, is prohibited.
Except for your own, personal use, any other use of the contents of this manual without
the consent of CASIO is prohibited under copyright laws.
0IN NO EVENT SHALL CASIO BE LIABLE FOR ANY DAMAGES WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS,
BUSINESS INTERRUPTION, LOSS OF INFORMATION) ARISING OUT OF THE USE
OF OR INABILITY TO USE THIS MANUAL OR PRODUCT, EVEN IF CASIO HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
0The contents of this manual are subject to change without notice.
0Company and product names used in this manual may be registered trademarks of others.
Declaration of Conformity
Model Number: CT-S1-76/CT-S1
Trade Name: CASIO COMPUTER CO., LTD.
Responsible party: CASIO AMERICA, INC.
Address: 570 MT. PLEASANT AVENUE, DOVER, NEW JERSEY 07801
Telephone number: 973-361-5400
CFR 47 §2.938 (b)(2) Attestation
As of the date of first importation or marketing of this device, the device is not produced
by any entity identified on the Covered List, established pursuant to 47 CFR § 1.50002 ,
as producing covered communications equipment.
This device complies with Part 15 of the FCC Rules, Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
A labels rating is affixed to the bottom of the product.
*WARNING
If Auto Power Off is set to [Off], the Digital Keyboard does not automatically turn off and
continues to use power.
Specifying the Battery Type
C2 C3E1 C5 C6 C7 G7C4
CT-S1-76
CT-S1
While holding down...
Alkaline/Nickel metal hydride
One tone: Alkaline batteries
Two tones: Rechargeable nickel metal hydride batteries
Playing with Sustain
C2 C3E1 C5
C6
C7 G7C4
CT-S1-76
CT-S1
Low tone: Off
High tone: On
While holding down...
Off/On
Recording Your Performance
1
Flashing
2
Play what you want to record.
3
Stop recording.
4
Play back again.
This starts recording. This automatically starts playback.
Press multiple times until playback
starts.
Returning Settings to Their Initial Factory Defaults (Initialization)
C2 C3E1 C5 C6 C7 G7C4
CT-S1-76
CT-S1
C2 C3E1 C5 C6 C7 G7C4
CT-S1-76
CT-S1
This causes a re-start.
While holding down...
Long-press. (To get ready)
Press again. (To execute)
Keeping FUNCTION depressed, press again.
C MA2402-A Printed in China
Published: 2/2024
