Table of Contents
Parts List 3
Features and Specifications 3
Control Functions 4
Control functions (cont.) 5
Mechanical Functions 6
Recessed RCA inputs 6
Control cover removal & reinstallation 6
Multi-position mounting feet 6
Vents (side & rear) 6
Mechanical functions (cont.) 7
Amplifier linking 7
Wire connection 7
Fuses 7
General Installation Precautions 8
Before you install 8
Battery & charging system 8
Wire routing 8
Installation—Amplifier Mounting 9
Choose the mounting location 9
Height, width, and depth diagrams 9
Installation—amplifier mounting (cont.) 10
Passenger & trunk compartment mounting 10
Installation—Fuses & Wiring 10
Amplifier fuses 10
Wire gauge 10
Installation—fuses & wiring (cont.) 11
Power/B+ & power/ground (GND) connection 11
Remote input connection 11
Speaker output connection 11
Installation—fuses & wiring (cont.) 12
Mono subwoofer operation 12
Setup Tuning—Full-range Speakers 12
Music 12
Sensitivity controls 12
Highpass & lowpass crossover controls 12
Setup tuning—full-range speakers (cont.) 13
Head unit 13
Volume 13
Input sensitivity control 13
Crossover controls 13
Setup tuning—full-range speakers (cont.) 14
“Q” control 14
Setup Tuning—Rear Fill Speakers 14
Setup Tuning—Subwoofers 14
Input switch 14
Setup tuning—subwoofers (cont.) 15
Head unit 15
Volume 15
Input sensitivity control 15
Lowpass crossover control 15
Phase 15
System Examples 16,17
Amplifier Troubleshooting Guide 18
Contact and Warranty Information 19
Downloaded from www.Manualslib.com manuals search engine
Included Hardware: GT-20 & GT-22
(1) owner’s manual
(1) female quick-connect terminal
(1) 2mm hex wrench (for speaker input)
(1) 3mm hex wrench (for power input)
(4) mounting screws
3
Parts List
Technical Specifications
GT-20 GT-22
14.4VDC Power
@ 4 Ohms 2x55W 2x100W
@ 2 Ohms 2x100W 2x175W
@ 4 Ohms (mono) 1x200W 1x350W
@ 2 Ohms (mono) 1x250W 1x500W
12.6VDC Power
@ 4 Ohms 4x45W 2x75W
@ 2 Ohms 2x80W 2x135W
@ 4 Ohms (mono) 1x165W 1x275W
@ 2 Ohms (mono) 1x220W 1x375W
Frequency Response (-3dB) 10Hz–95kHz 10Hz–95kHz
Signal-to-Noise Ratio (A Weighted) >100dB >100dB
Dimensions (HxWxD) 21/4x77/8x87/8” (57x200x225mm) 21/4x121/8x87/8”(57x308x225mm)
GT-20 & GT-22 Features
2-Channel, High-Current Amplifier
2ΩMono Operation
Power Increase with Input Voltage Rise
Advanced Cooling Allows Varied Mounting Positions
Adjustable Feet for Varied Mounting Surfaces
Continuously Variable Crossover and Q-factor Settings
Selectable Highpass, Lowpass, and Bandpass Settings
Bandpass Configurable for Midbass or Subwoofer
Terminals Accept Bare, Heavy-Gauge Wire
Screw-Down Security Cover Protects Tuning Controls
Features and Specifications
Downloaded from www.Manualslib.com manuals search engine
