Használati útmutató Bauhn AFTC3-0424-B

Bauhn Töltő mobil eszközhöz AFTC3-0424-B

Olvassa el alább 📖 a magyar nyelvű használati útmutatót Bauhn AFTC3-0424-B (2 oldal) a Töltő mobil eszközhöz kategóriában. Ezt az útmutatót 7 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra

Letöltés PDF
Oldal 1/2
Product Overview
Have you got everything?
A
B. 1 x USB-C Charging Cable
C. User Guide
D. Warranty Certicate
User Guide
Model: AFTC3-0424
3 in 1 Foldable Wireless Charger
Operation
Connect to power source
Plug in the supplied USB C cable into a power source
and plug in the other end into the 3 in 1 foldable wireless
charger’s USB C port and make sure the power source is
switched on and working. The charging indicator will ash for
5s and then the charger will enter standby mode.
Charging your devices
1. Wireless charging pad for compatible mobile phones.
Place your mobile phone on the centre of the charging pad,
display screen facing up to charge.
2. Wireless charging pad for smart watches that supports
wireless charging. Place the back of the smart watch against
the charging pad to charge. The charging pad can be lifted
for a different charging position.
3. Wireless charging pad for compatible earphones or
earbuds devices.
4. Charging LED indicator for mobile phone charging pad.
Solid green light indicates charging is in progress.
5. Charging LED indicator for smart watch charging pad.
Solid green light indicates charging is in progress.
6. Charging LED indicator for earbuds charging pad.
Solid green light indicates charging is in progress.
Charging Layout Method
The 3-in-1 foldable wireless charger can be set up in various
ways for charging depending on your preference.
C D
A. Mobile phone charging pad
B. Smart Watch charging pad
C. Earbuds charging pad
D. Charging LED indicator for mobile phones
E. Charging LED indicator for smart watches
F. Charging LED indicator for earbuds
G. USB-C port
AB C
D E F
G
1 2 3
64 5
USB-C Port
Open Layout
Folded Layout
• Full layout for charging the mobile phone, smart watch, and earbuds at the same time.
• Folded layout for charging the mobile phone only and minimize the required space for operation.
Pyramid Layout
• Pyramid layout for charging the mobile phone and can use as a phone stand.
Either black or white.
Mobile Phone is not
charging
• Check that your smart phone supports wireless charging.
• If you have a smart phone case, you must remove it when charging.
• Ensure the smart phone is facing up, making sure the centre of the smart
phone is aligned to the centre of the wireless charging pad.
• Check and remove any metal or other objects between the smart phone and
the wireless charging pad.
Smart Watch is not
charging
• Check that your smart watch supports wireless charging.
• Ensure the back of the smart watch is aligned to the centre of the wireless
charging pad.
• Check and remove any metal or other objects between the smart watch and
the wireless charging pad.
Earbuds not charging
• Check that your earbuds case supports wireless charging.
• Ensure the earbuds case is facing up, making sure the centre of the case is
aligned to the centre of the wireless charging pad.
• Check and remove any metal or other objects between the earbuds case and
the wireless charging pad.
Charging LED indicator
does not light up
• Ensure that the USB-C cable is connected to the USB-C port securely.
• Check that the power source is switched on.
Charging LED indicator
ashing
• If the wireless charging pad encounters interference (metal objects etc.) or the
input power is too high, it will enter protection mode and the LED will ash
green.
Specications
Input USB-C 5V 3.5A, 9V 3A ⎓ ⎓
Output
Magnetic Phone Charger: 5W, 7.5W, 10W, 15W
Watch Charger: 2.5W Max.
Earbuds Charger 5W Max.
Total Output 20W Max.
Dimensions 101 x 76 x 30mm
Weight 150g
General Safety Warnings
For the safety of yourself and others, follow all instructions and take notice of all the warnings. When
adhered to, these safety precautions can reduce the risk of fire, electric shock and injury.
This product complies with Australian Safety standard AS/NZS 62368.1 to ensure the safety of the product.
The RCM is a visible indication of a product’s compliance with all applicable ACMA
regulatory arrangements, including all technical and record-keeping requirements.
IMPORTANT
Plastic wrapping can be a suffocation hazard for
babies and young children, so ensure all packaging
materials are out of their reach.
To prevent environmental factors (dampness, dust,
food, liquid etc.) harming the power bank, only use it
in a well-ventilated, clean and dry environment, away
from excessive heat or moisture.
Keep the product away from direct sunlight or heat
sources.
In case of damage, do not disassemble, repair or
modify the product yourself. Contact After Sales
Support for advice on repair or replacement, or refer
servicing to qualified personnel only.
Children should be supervised to ensure they do not
play with the product.
Do not put any object on top of the product.
Do not place or store appliance where it can fall or
be pulled into a bath or sink.
This product is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the product by a
person responsible for their safety.
Do not expose the product to microwaves.
Clean using a dry cloth only.
Do not use water or chemicals.
Keep the product away from oils, chemicals or any
other organic liquids.
Use this appliance only for its intended purpose as
described in this guide.
Responsible disposal of the packaging
The packaging of your product has been selected
from environmentally friendly materials and can
usually be recycled. Please ensure these are disposed
of correctly. Plastic wrapping can be a suffocation
hazard for babies and young children, please ensure
all packaging materials are out of reach and are
safely disposed of. Please recycle these materials
rather than throwing them away.
Responsible disposal of the product
At the end of its working life, do not throw this
product out with your household rubbish. An
environmentally friendly method of disposal will
ensure that valuable raw materials can be recycled.
Electrical and electronic items contain materials
and substances which, if handled or disposed of
incorrectly, could potentially be hazardous to the
environment and human health.
Enjoy using your product!
Well done, you made it.
Now sit back and relax... your product is automatically covered by a 1-year warranty.
How nice!
Give us a call
What? You mean this User Guide didn’t have ALL the answers? Speak to us!
We’d love to help you get up and running as quickly as possible.
Call our on . After Sales Support 1300 002 534
Operating hours: Monday-Friday, 8:30am-6pm; Saturday, 9am-6pm AEST
Troubleshooting
3 in 1 Foldable Wireless Charger
* Output is dependent on input power
** Only supported on some devices compatible with 15W wireless charging.
*** Compatible with Apple watches from series 2 onwards.
