Please read the manual before using the product
USER´S
MANUAL
202 Go
Proffesional Mixer
202 Go
10
8 Protecting the environment
Disposal of the packaging material
For the transport and protective packaging, environmentally
friendly materials have been chosen that can be supplied to
normal recycling.
Ensure that plastic bags, packaging, etc. are properly
disposed of.
Do not just dispose of these materials with your normal
household waste, but make sure that they are collected for
recycling. Please follow the notes and markings on the
packaging.
Disposal of your old device
This product is subject to the European Waste Electrical
and Electronic Equipment Directive (WEEE) in its currently
valid version. Do not dispose with your normal household
waste.
Dispose of this device through an approved waste disposal
firm or through your local waste facility. When discarding
the device, comply with the rules and regulations that apply
in your country. If in doubt, consult your local waste disposal
facility.
USER´S
MANUAL 9
202 Go
Table of contents
1 General information ...................................................................................... 1
1.1 Further information................................................................................... 1
1.2 Notational conventions............................................................................. 1
1.3 Symbols and signal words ....................................................................... 2
2 Safety instructions........................................................................................ 2
3 Features ........................................................................................................ 4
4 Installation and starting up ......................................................................... 4
5 Connections and controls .......................................................................... 5
6 Technical specifications ............................................................................. 7
7 Plug and connection assignment .............................................................. 7
8 Protecting the environment ....................................................................... 10
XLR plug (unbalanced)
1
Ground, shielding
2
Signal
3
Bridged to pin 1
Three-pole 1/8" mini phone jack (stereo, unbalanced)
1
Signal (left)
2
Signal (right)
3
Ground, shielding
RCA connection
1
Signal
2
Ground, shielding
Drawing and table indicate the pin assignment of an RCA plug.
8 1
202 Go USER´S
MANUAL
1 General information
This manual contains important instructions for the safe operation of the unit.
Read and follow the safety instructions and all other instructions. Keep the
manual for future reference. Make sure that it is available to all those using the
device. If you sell the unit please make sure that the buyer also receives this
manual.
Our products are subject to a process of continuous development. Thus, t hey
are subject to change.
1.1 Further information
On our website () you will find lots of further information and details on the
following points:
Download
Keyword search
Online guides
Personal consultation
Service
1.2 Notational conventions
This manual uses the following notational conventions:
Letterings
The letterings for connectors and controls are marked by square brackets
and italics.
Examples: control, button. [VOLUME] [Mono]
In a professional environment, therefore, the balanced transmission is
p
referred, because this enables an undisturbed transmission of signals over
l
ong distances. In addition to the conductors ‘Ground’ and ‘Signal’, in a
b
alanced transmission a second core is added. This also transfers the signal,
b
ut phase-shifted by 180°.
S
ince the interference affects both cores equally, by subtracting the phase-
s
hifted signals, the interfering signal is completely neutralized. The result is a
p
ure signal without any noise interference.
1
/4" TS phone plug (mono, unbalanced)
1/4" TRS phone plug (mono, balanced)
XLR plug (balanced)
1
Signal
2
Ground, shielding
1
Signal (in phase, +)
2
Signal (out of phase, –)
3
Ground
1
Ground, shielding
2
Signal (in phase, +)
3
Signal (out of phase, –)
