Portable
Solar Generator
User Manual
Car Socket
AC Power Outputs x2
AC Output Switch
AC Power Indicator
DC Outputs x3
1.Get To Know Your Gear
3.Charging Your Generator
2. Tech Speci cation
4.Powering on and o
1
2
3
4
5
6
7
8
9
10
11
12
13
Main Power Button
USB 5V/2.4A Outputs x2
Type-C PD Output
LED Light Panel Switch
DC Input Port
Wireless Speaker
Wireless Speaker Working LED Indicator
Main Power LED Indicator
LED Light Panel
USB QC3.0 Output
Remaining Power Level LED Indicator
Wireless Speaker AUX-IN
Wireless Speaker Play Control Button
1
2
3
4
5
6
7
8
9
10
11
12
13
A
A:
14
15
16
17
14
15
16
17
18
18
B
B:
1. Long press the Power Button for 2 seconds until the green LED light
comes on.
2. When not in use, long press the Power Button for 2 seconds until the
green LED light turns off.
Please make sure the green light is on before using.The Solar Generator
will stay on even without any power drawing.Make sure you turn it off
when not in use to prevent the battery from draining.
515.04Wh (3.7V/139,200mAh)
462Wh (3.7V/124,800mAh)
Lithium-ion Cell
DC 19V/4.5A by Adapter
100-120V~/ 60Hz ( for Generator1 Version)
220-240V~/ 50Hz ( for Generator2 Version)
USB-A Outputs: 5V/2.4A x2
USB-A QC3.0 p1-x1 (5V/3A,9V/2A)
USB-C PD 60W x1
DC 9-12.6V/10A Cigarette Lighter Socket p1-x1
DC 9-12.6V, 5A Max Output p1-x3
AC Output Power: Rated Output Power: 500W
Inverter Waveform: Pure Sine Wave
5W
10W
Net Weight: 5.5Kg
Dimension: 290x155x190mm
Warranty: 12 months
Capacity:
Battery Type:
DC Input:
MPPT Solar Input:
AC Output:
DC Output:
LED Lighting Function
Wireless Speaker
14-25V by Solar Panel (Max 120W)
Option
Option
Total Share 10A Max
3OHDVHVZLWFKR΍ZKHQQRWLQXVHWRVDYHWKHHQHUJ\
5. When the power inverter is not working as intended, the LED light will
be red.
1.Turn on main power.
2.Long press the button for 2 seconds to turn on speaker.You will hear
a power up sound and see a blue LED light.
PS-Speaker
:KHQLQSDLULQJPRGHWKHEOXHOLJKWZLOOEHȵDVKLQJ6HDUFKIRU
“PS-Speaker” in your Bluetooth settings and pair it with your cell phone.
- Long press to previous song
+ Long press to next song
+Short click increase volume
- Short click to descrease volume
2.Open the cover.
1.Turn on main power.
3.Plug into car socket.
4.Output voltage: 9-12.6V
5.Output current: 10A(max)
2.Plug in DC output port.
3.DC output voltage: 9-12.6V
4.DC output current: 5A max per port
2.Long press the far right button to turn on LED light panel on
half brightness mode.
4.Click again for SOS mode.
5.Click again for strobe mode.
ΖQDQ\PRGHORQJSUHVVVHFRQGVWRVZLWFKR΍WKHOLJKWSDQHO
You can also just press one more time in strobe mode.
4.
5.How to Use AC Output Port
6.USB Output
7.Speaker
9.DC 12V
8.Car Socket
10.LED light panel
Short press play/pause /RQJSUHVVVWRWXUQRQR΍
speaker
3.Click the button again to be on max brightness mode.
1.Turn on main power.
1.Turn on main power.
1.Turn on main power.
2.Plug your device into a USB output socket.
1. Long press the Power Button for
2 seconds to turn on the Solar
Generator.
2. Flip the switch between the 2 AC
outlets to the ON position.
3. Plug your device into the AC
outlet.
1.Do not cover the Generator with anything that would prevent heat from
escaping.
2.The Generator does not have an IP waterproof rating. Do not use in
rain or in any other situations can get wet.
3.Please keep away from fire and children.
●Low Battery: When the battery is lower than 10%, the 1st LED will be
blinking.
●AC Power LED indicator: When it is green, AC output is on, when it is
red, AC output is not working as intended.
4.Please do not disassemble the product.
5.Fully charge the Solar Generator before long time storage.
Check the battery percentage every 3 months.
6. When not in use, make sure to turn off the Solar Generator to
conserve battery power.
7. Please do not leave the Solar Generator in situations where it
can reach extreme temperatures exceeding 50 such as inside℃
a vehicle or outside direct sunlight.
12.Caution
2.When you want to check the remaining power level under standby or
while working, short press the main power button to check as below:
100% - 75% 75% - 50% 50% - 25% 25% - 10% ≤10%
0% - 25%26% - 50%
51% - 75%
76% - 99%100%
1.It has four LEDs to display the remaining battery capacity. When being
re-charged, the LED will flash based on the current battery level:
11.Power Indicator
Charging: ( :LED flash / : LED is off / : LED is on)
Add:4120 Valley Blvd. Walnut, CA 91789.USA
Tel: 1.626.575.8822 Email:sales@acopower.com
