Important Information
RISK OF ELECTRIC SHOCK.
DO NOT OPEN.
CAUTION Caution: To reduce the risk of electric shock, do not remove cover (or back). No
user serviceable parts inside. Refer servicing to qualifi ed service personnel.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the
serial and model numbers in case you need them. These num bers are located on the product.
Model No.: _____________________________________________________________________________________________
Purchase Date: _________________________________________________________________________________________
Dealer/Address/Phone: __________________________________________________________________________________
Important Safety Instructions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Clean only with dry cloth.
6. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
7. D o not i n s t all n e a r an y h e a t s ou r c e s s u c h as r a d i a t o r s ,
heat registers, stoves, or other apparatus (including
amplifi ers) that produce heat.
8. Protect the power cord from being walked on or pinched
particularly at plugs, con ve nience re cep ta cles, and the
point where they exit from the apparatus.
9. Unplug this apparatus during lightning storms or when
unused for long periods of time.
10. Refer all servicing to qualifi ed service personnel.
Servicing is required when the apparatus has been
dam aged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the ap pa ra tus has been exposed to
rain or moisture, does not op er ate normally, or has been
dropped.
Care and Maintenance
• Always use a soft cloth to clean the speaker and transmitter. Never use any product containing alcohol or other
solvents as they may damage the surface.
• Use caution when plugging the power transformers in an AC outlet to avoid the risk of electric shock.
• If the speaker are used outside on a deck or patio, make sure you take them indoors in the event of a rainstorm to
prevent possible damage.
• Do not operate or store the system in extreme temperatures (below 32ºF/0ºC and above 122ºF/50ºC).
Model AWSBT8
Installation and Operation Manual
Portable
Wireless
Speaker
For PLUGGABLE EQUIPMENT, the socket-outlet shall
be installed near the equipment and shall be easily
accessible.
The apparatus shall not be exposed to dripping or
splashing or placed near objects fi lled with liquids.
Introduction
The Acoustic Research AWSBT8 portable wireless speaker makes it easy to take your music
wherever you go and share it whenever you want, with Bluetooth® wireless connectivity and
a built-in auxiliary input.
This manual covers various connection options and detailed operating instructions for
making the Acoustic Research Portable Wireless Speaker a valued part of your lifestyle. If,
after having reviewed the instructions, you have any questions, please call
toll-free 1-800-732-6866 or visit www.acoustic-research.com.
Tour of the Speaker
Powering the Speaker System
Front panel
Power and Pairing indicator shows the
status of the speaker.
Blue, slow blinking: The speaker is on but not
paired or connected (like when you turn the
speaker on for the first time).
Blue, fast blinking: The speaker is in Bluetooth
pairing mode. See the Bluetooth Setup section
for more information.
Solid blue: The speaker is paired with a
Bluetooth-enabled device and ready to play
audio.
Back panel
Bass Boost button turns the speaker’s bass
enhancement on and off
On-Off button turns the speaker on and off.
Pair-Press and hold (3 sec) puts the
speaker in pairing mode for setup Bluetooth
(press and hold for 3 seconds). See the
Bluetooth setup section for more information.
Volume +/– buttons adjust the speaker’s
volume level.
Bottom panel
Audio Input connects directly to your
MP3 player, smartphone, or other portable
audio device, using the 3.5mm audio in cable
provided.
DC IN receives the small round end of the
included 10V 1500mA AC power adapter;
remove the protective cover to insert the
adapter.
Battery Compartment Cover
remove to install 6 AA batteries.
Powering the Speaker
There are two options to power your wireless speaker: using the included AC power adapter
or using 6 AA batteries (not included).
AC Power Adapter
1. Insert the small, round plug from the speaker AC
power adapter into the DC IN jack on the bottom
panel of the speaker.
2. Plug the other end of the speaker AC power
adapter into any standard 120V AC wall outlet.
Notes: Be sure to use the speaker AC power adapter
rated 10V DC 1500 mA.
The power unit should be plugged in so that it stays
vertical or lies fl at.
AA Batteries
1. Remove the battery compartment cover on the bottom of the speaker.
2. Insert six (6) AA batteries (not included) into the speaker following the polarity
(”+” and “-”) as diagrammed inside the battery compartment.
3. Replace the battery compartment cover on the bottom of the speaker.
Note: Place the rubber cap in the speaker power input jack when using batteries.
DO NOT mix batteries with different chemistry types (for example, a zinc battery with an alkaline
battery). DO NOT mix new and used batteries. DO NOT leave batteries installed in the product
when not in use for long periods. Always remove old, weak or worn-out batteries promptly and
recycle or dispose of them in accordance with local and national regulations.
Powering the Speaker System
Setting Up Bluetooth Wireless
Pairing
The Bluetooth-enabled device that you wish to stream audio to your speaker system must
fi rst be paired to the speaker. The process is simple, and in most cases the pairing process
needs to be done only once.
To pair your Bluetooth-enabled device with the speaker:
1. Make sure your device’s is turned on. See the wireless and/or network settings Bluetooth
menu on your device to check.
2. If the speaker isn’t already on, press the On-Off button to turn it on. You will hear a beep
to indicate the speaker is turned on. The indicator light on the front of the speaker starts
fl ashing blue.
3. Press and hold for 3 seconds the Pair button to enter pairing mode. You will hear 2 beeps
to indicate pairing mode is entered. The indicator on the front of the speaker starts
blinking faster.
4. Open the Bluetooth settings menu on your device. Select “AR SPEAKER” from the list of
devices available (you might have to scan for devices). If your device asks for a password,
enter “0000”.
5. A confi rmation screen will appear on your device once the speaker and the device are
successfully paired. The blue indicator turns solid blue to indicate ful connection. success
The speaker is now ready for you to stream audio from your device.
6. Turn the volume on your device to at least 3/4 max, then start playing something on the
device. Control the speaker volume on the speaker itself, using the Volume +/– buttons on
the back of the speaker.
Note:
• If you notice the sound from the speaker is distorted, turn down your device’s volume.
