Oldal 1/29
VIZIO
WHERE
VISION
MEETS
VALUE
Version - 9/23/2004 1
Table of Contents
Chapter 1 - Introduction ................................................................................................................................2
1.1 - Before Use ......................................................................................................................................... 2
1.2 – Specifications .................................................................................................................................... 2
1.3 - Opening the Package......................................................................................................................... 3
1.4 - Installation.......................................................................................................................................... 3
1.5 - Important Safety Guidelines............................................................................................................... 4
1.6 - levision Antenna Te Connection Protection ........................................................................................ 6
1.7 - Package Content ........................................................................................................s ...................... 7
1.8 - Front Panel ........................................................................................................................................ 8
1.9 - Rear Panel Connections .................................................................................................................... 9
1.10 - VIZIO 13e RL emote Contro ..............................................................................................l .............. 10
1.10.1 – Remote Control Description ................................................................................................... 10
1.10.2 - Insertion of Batteries in the Remote Contro .........................................................................l ...1 1
1.10.3 - Remo et Control Rang .................................................................................................e ...........1 1
1.10.4 - Precautions for the VIZIO Remote Contro .............................................................................l .11
Ch t r 2 - Connap e ecting C mpon nt ............................................................................................. o e s ........... 1. 2
2.1 - Which Video Connection Should I Use? ...........................................................................................1 2
2.2 - Connecting Your DVD Pla e ..............................................................................................y r ..............13
2.2.1 - Using Component Video ...........................................................................................................13
2.2.2 - Using S-Video ...........................................................................................................................14
2.2.3 - Using Composite Vide .................................................................................................o ............15
2.3 - Connecting Your VCR or Vid eo Camer .....................................................................................a ......15
2.4 - Connecting Coaxial (RF .................................................................................................) ..................16
2.4.1 - Using Your Antenna or Cable VT ..............................................................................................16
2.4.2 - Using the Antenna through Your VC ....................................................................................R ...16
Chapter 3 - Getting Started ........................................................................................................................ 1. 7
3.1 - Turning your LCD V OnT and Of ..........................................................................................f ............17
3.2 - Installation of Wall Mount (Optional) .................................................................................................17
3.3 - Adjusting Basi c LCD VT Setting .........................................................................................s .............18
3.4 - Using the On- Screen Di lsp ay (OSD ....................................................................................... ) ..........19
3.4.1 - Menu Operation .......................................................................................................s ................19
3.4.2 - OSD Menus and Options ..........................................................................................................20
3.4.3 - Using the Parental Controls ......................................................................................................22
3.4.4 - Setting a Pas rdswo ...................................................................................................................23
Chapter 4 - Maintenance and Tro bu lesh oti ...................................................................................o ng ..... 2. 4
4.1 - Maintenance .....................................................................................................................................24
4.2 - ouble Tr shooting Guid ...................................................................................................e ...................24
4.3 - lephone & e Te T chnical Suppor ...........................................................................................t .............25
4.4 - Complianc ..............................................................................................................e .........................26
4.5 - FCC Cla s B Radio Frequens cy Interfe ence r Statement....................................................................26
Appendix A: Limited Warran y I t nformatio ......................................................................................n ............27
Version - 9/23/2004 2
Chapter 1 - Introduction
1.1 - Before Use
Congratulations on your VIZIO L13e 13” LCD Television purchase. Thank you for your support of
V, Inc. and its LCD Television product line. The L13e is a precise electronic product and you
should read the following instructions carefully to maximize the performance of the product. It has
passed regulatory safety certifications and you can be assured of the highest quality display with
the utmost reliability. After you have finished reading the instructions, put them away in a safe
place for future reference.
1.2 – Specifications
Panel 13” Diagonal, 4:3 Aspect Ratio
Resolution 640 x 480 pixels
Brightness 450 cd/m2 pic l ty a
Contrast Ratio 500:1 typical
Response Time 15mS pical ty
Vie ing Angle 1 0° ( orizontaw 7h l) / 1 ° (v tical) for CR55 er ≥ 5
1x RF (1x F Connector adaptor for internal NTSC Tuner)
1x Composite Video (1x RCA) & 1x S-Video (1x DIN) plus 1x Stereo Audio (2x RCA, Left +
Right)
Inputs
1x Component (3 x RCA, YCbCr) plus 1x Stereo Audio (2 x RCA, Left + Right)
1 x Stereo Audio (2 x RCA, Left + Right)
Outputs
1 x Stereo Headphone (1 x Stereo Mini Jack)
User Controls Vol-, Vol+, Menu, Ch▼ ▲, Ch , Enter, Power On/Off
Speakers Built-in 2 x 2.5 W
Features CC, V-Chip, Comb Filter, Video Scalar, NTSC Video decoding via RF (Antenna, Cable or
Satellite [Set Top Box may be required]) or Video (CVBS, S-Video or Component YCbCr)
Backlight Lamp life 0,000 hours. 6
Input: IEC Connector for direct power line connection
Voltage Range: 100 ~ 240 Vac at 50/60 Hz Power
Power consumption: 50 W
Temperature: 0°C ~ 35°C (32°F ~ 95°F)
Humidity: 20% ~ 90% (no condensation) Operating Conditions
Altitude: to 10,000 feet (3,000 meters)
Temperature: -20°C ~ +60°C (-4°F ~ +140°F)
Humidity: 5% ~ 90% (no condensation) Storage Conditions
Altitude: to 40,000 feet (12,000 meters)
16.6” x 10.2” x 2.5” (426mm x 262mm x 63mm without Stand)
Dimensions (W x H x D) 16.6” x 14.04” x 7.6” (426mm x 360mm x 195mm with Stand)
6.82 lbs (3.1 kg) without stand
Weight 8.58 lbs (3.9) with stand
Agency Approvals UL, C-UL, FCC Class B
Note: In some countries or regions, the shape of the power plug and power outlet may
sometimes differ from that shown in the explanatory drawings. However, the method of
connecting and operating the unit is the same.
