The card reader in now ready
for use
Connect th Ue SB c le fr cab om ard
reader to motherboard
Align the screws holes and secure
with screws
Install the card reader into an
open 3.5” drive bay
Install into any open 5.25” drive
bay and secure with screws
Ali gn the screws holes w thi moun g tin
bracket and secure with screws
Slide the card reader into the
5.25” mounting bracket
5.25” Drive Bay Installation:
3.5” Drive Bay Installation:
Installation (USB Cable):
。
。
。
。
Memory Cards Support:
*card adapter required
CF-Type I, CF-Type II , CF-Ultra II, Micro Drive , CF-Pro , CF-Pro II, CF-Extreme, CF-Extreme
III , CF-PSP II, CF-Super, CF-Ultra X
MS, MS-Magic Gate, MS-PRO Magic Gate, HS-MS-PRO Magic Gate, MS-DUO, MS-DUO Magic
Gate, MS-PRO Duo, HS-MS-PRO Duo, MS-PRO Duo-PSP, MS-PRO Duo-Gaming, *M2
SD, SDHC, SD-Pro, SD-Pleomax, SD-Pro C, SD-Ultra, SD-Ultra II, *SD-Ultra II Plus, SD-Extreme
III, SD-Ultra X, SD-Turbo, SD-Super, SD-Max, *Mini SD, *Mini SD-Pro,*Mini SD-Pleomax,MMC,
MMC-Pleomax, MMC Pro, HS-MMC,MMC Plus, MMC-Plus Turbo, *RS MMC, RS MMC-Pleomax,
RS MMC-Speed, RS MMC-Max, MMC Mobile, MMC Mobile-ProC, MMC Mobile-Pocketnet.
*T-Flash, *Micro SD. *MMC Micro
XD, XD (M), XD (H),Smart Media.
System Requirements:
Intel Pentium II 350 MHz-compatible or Mac G3 processor & greater
Microsoft Windows 2000/XP/Vista or Mac OS 8.6 & greater
For USB 2.0 speeds, the system must support USB 2.0 specifications.
CD Rom drive (if drivers are needed)
MS
SD/MMC SM/XD
CF/MD USB HUB 1. Open Case
4.
2.
2. 3.
3.
4.
5.
1.
6.
5.
Feature:
。Read/Write to 58 Types of Memory Cards
。Built-In USB 2.0 Port
。Hi-Speed USB 2.0 Transfer Rate Up to 480 Mbps
。Fits in Any Standard 3.5” or 5.25” Drive Bay
。Simultaneously Transfer Data Between Memory Cards
。Power and Activity LED Indicator
Package Contents:
。3.5” Internal Card Reader x 1
。5.25” Mounting Bracket x 1
。Driver CD x 1
。Installation Screws x 1
Connect the USB cable from card
reader to motherboard
The card reader is now ready
for use
Open case
14 133( L)x9 41 mm 101.3 5 4(W)x( H) (L) x94. ( W) x25. (H) mm
Dimension
Bracket dimension
(L)
(H)
(W) (L)
(H)
(W)
Specification:
(Bracket dimension :143x41x139mm )
Dimension: 101.3x25.4x94.5mm
Model: UGT-CR905
Interface: USB 2.0
