MB240/ MB340/ MB240T/ MB340T Series
Print Engine User’s Setup Guide
Opon items for print module:
Specicaon
Product option feature
Print Module
Resoluon
8 dots/mm (203 dpi)
12 dots/mm (300 dpi)
Max. print speed
254 mm (10")/second
177 mm (7”)/second
Max. print width
108 mm (4.25”)
105.7mm (4.16”)
Physical dimension
241.0 mm (W) x 168.0 mm (L) x 190.0 mm (H)
(9.49” (W) x 6.61” (L) x 7.48” (H))
Weight
2.5 kg (5.51 lbs)
Plaorm
Memory
128 MB Flash memory, 128 MB SDRAM
Interface
USB2.0, RS-232, Internal Ethernet 10/100 Mbps, USB Host
Real me clock
Opon
Buzzer
Standard
Power Supply
Input
AC 100-240V, 2A, 50-60Hz
Output
DC 24V, 3.75A, 90W
Supported Media
Media type
Connuous, die-cut, black mark, fan-fold, notch
Media wound type
Outside wound
Media width
20 ~ 120 mm (0.8” ~ 4.7”)
Min. media length
5 mm (0.2”)
Media thickness
0.06 ~ 0.28 mm (2.36 ~ 11 mil)
Support Ribbon
Ribbon type
WAX, RESIN, WAX-RESIN
Wound type
Ink coated outside or inside
Ribbon width
40 mm ~ 110 mm (1.6” ~ 4.3”)
Ribbon capacity
450 m long, max. OD 81.3 mm, 1” core
Accessory
GPIO board (DB15F)
Peel o kit
Cuer
No.
Descripon
Remark
1
Print module (203 dpi) without
main board, power supply unit
and power cord
1 pc
Print module (300 dpi) without
main board, power supply unit
and power cord
1 pc
2
Power supply
1 pc
3
Power cord / US
1 pc
Power cord / EU
1 pc
Power cord / UK
1 pc
Power cord / AU
1 pc
Power cord / JP
1 pc
Power cord / IN
1 pc
Power cord / KR
1 pc
Power cord / CN
1 pc
Power cord / TW
1 pc
4
USB cable (1500 mm)
1 pc
5
Main board assembly
1 pc
6
GPIO interface assembly (Factory
opon)
1 pc
7
Peel-off module panel (with
cable)
1 pc
P/N: -0680010-00LF 39
❶
❷
❸
❹
❺
❻
❼
Dimension (unit: mm)
Appearance
Front view
Side view
Located screw thread posion
PCBA Dimension
