MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
Safe Operation Practices • Set-Up • Operation • Maintenance • Troubleshooting • Warranty
WARNING
READ AND FOLLOW ALL SAFETY RULES AND INSTRUCTIONS IN THIS MANUAL
BEFORE ATTEMPTING TO OPERATE THIS MACHINE.
FAILURE TO COMPLY WITH THESE INSTRUCTIONS MAY RESULT IN PERSONAL INJURY.
OperatOr’s Manual
140 cc OHV Vertical Shaft Engine
Form No. 769-17302
(August 17, 2018)
* Model 1T65 Shown
This Operator’s Manual is an important part of your new engine. It will help you prepare and maintain the engine for the best
performance. Please read and understand the contents before operating the engine.
Thank You
M Nodel uMber
S Nerial uMber
Customer Support
Please do NOT return the machine to the retailer or dealer without first contacting the Customer Support Department.
If you have difficulty assembling this product, have questions regarding the controls, operation, or maintenance of this machine, want
to order replacement parts/attachments/accessories, or want to view an online How-To video; you can seek help from the experts. Have
your full model number and serial number ready. Choose from the options below:
◊ Visit us on the web: www.mtdproducts.com
◊ Call a Customer Support Representative at: (800) 800-7310 or (330) 220-4683
◊ Write to: MTD LLC • P.O. Box 361131 • Cleveland, OH • 44136-0019
To The Owner
1
2
Table of Contents
Safe Operation Practices ........................................ 3
Safety Symbols ........................................................ 5
Set-Up ....................................................................... 6
Controls & Features 8 .................................................
Operation ................................................................. 9
Maintenance & Adjustments .................................10
Troubleshooting .....................................................14
Replacement Parts .................................................15
EZ Start Promise† ...................................................16
Spanish ....................................................................17
Record Product Information
Before operating your new engine, please locate the model plate on the engine (shaded area in Figure below) and record the
information in the provided area below. This information will be necessary, should you seek technical support via our web site or with
your local dealer.
† Applicable to MTD Brand Auto-Choke Engines Only
Important Safe Operation Practices
2
3
WARNING! This symbol points out important safety instructions which, if not followed,
could endanger the personal safety and/or property of yourself and others. Read and follow
all instructions in this manual before attempting to operate the equipment. Failure to
comply with these instructions may result in personal injury. When you see this symbol.
HEED ITS WARNING!
DANGER! This engine was built to be operated according to the safe operation practices in
this manual. As with any type of power equipment, carelessness or error on the part of the
operator can result in serious injury. Failure to observe the following safety instructions
could result in serious injury or death.
CALIFORNIA PROPOSITION 65
WARNING! Engine Exhaust, some of its constituents, and certain vehicle components
contain or emit chemicals known to State of California to cause cancer and birth defects
or other reproductive harm.
Training
1. Read, understand and follow all instructions on the engine
and in the manual(s) before attempting to assemble and
operate. Keep this manual in a safe place for future and
regular reference and for ordering replacement parts.
2. Be familiar with all controls and their proper operation.
Know how to stop the engine and disengage them quickly.
3. Never allow children under 14 years of age to operate the
engine. Children 14 and over should read and understand
the instructions and safe operation practices in this manual
and be trained and supervised by an adult.
4. Never allow adults to operate the machine without proper
instruction.
5. Keep the area of operation clear of all persons, particularly
small children and pets. Stop machine if anyone enters the
area.
Preparation
1. Wear sturdy, rough-soled work shoes and close fitting
slacks and shirts. Loose fitting clothes or jewelry can be
caught in the moving parts. Never operate the machine in
bare feet or sandals.
2. Disengage clutch levers and shift (if equipped) into neutral
(“N”) before starting the engine.
3. Never leave the engine running while unattended.
4. Never attempt to make any adjustments while the engine
is running, except where specifically recommended in the
operator’s manual.
Safe Handling of Gasoline:
To avoid personal injury or property damage, use extreme care
in handling gasoline. Gasoline is extremely flammable and the
vapors are explosive. Serious personal injury can occur when
gasoline is spilled on yourself and/or your clothes which can
ignite. Wash your skin and change clothes immediately.
1. When adding fuel, turn engine OFF and let engine cool at
least 2 minutes before removing the gas cap.
2. Fill fuel tank outdoors or in well ventilated area.
3. Use only an approved gasoline container.
4. Never fill containers inside a vehicle or on a truck or trailer
bed with a plastic liner. Always place containers on the
ground away from your vehicle before filling.
5. If possible, remove gas-powered equipment from the truck
or trailer and refuel it on the ground. If this is not possible,
then refuel such equipment on a trailer with a portable
container, rather than from a gasoline dispenser nozzle.
6. Keep the nozzle in contact with the rim of the fuel tank or
container opening at all times until fueling is complete. Do
not use a nozzle lock-open device.
