Adventure Bike FAQ Reference
720 (Fast touring, light loads)
Rack Details
Front rack max payload: 6.5lbs. each (3kg.)
Front rack mount eye- -eye: 165mm (the standard low-rider mount to fender eyelet distance) to
Rack mount bolt torque: 5.2 Nm
Bag Spec
75D Nylon with 840D Hypalon bottom & roll top strap
Waterproof coating with welded seams
Dimensions: 28cm Wide x 44cm Tall x 17.5cm Round
Capacity 488 cu-in (8L) :
Tire/Fender Clearance
Designed for 700x32 tires with fenders*
Can fit up to a 700x34 tire without fenders*
* Due to variations in tire tread design and manufacturing, not all tires of a given size will be the same. While
it may be possible to fit a slightly larger tire, you should always test fit the tire first to ensure a minimum of
6mm clearance at all points between the tire and the frame, fork or fender.
920 (All-road self-supported adventure touring) ,
Rack Details
Max payload for front rack: 50lbs (22.7kgs)
Max payload for rear rack: 55lbs (25kgs)
Front rack mount eye- -eye: 157mm to
Rack mount bolt torque: 5-6 Nm
Pannier tubing/clamp diameter: 10mm
Tire/Fender Clearance
Designed for 29x2.0 tires with fenders*
Can fit up to 29x2.2 tires with fenders*
Max tire size without fenders is 29x2.3*
*Due to variations in tire tread design and manufacturing, not all tires of a given size will be the same. While
it may be possible to fit a slightly larger tire, you should always test fit the tire first to ensure a minimum of
6mm clearance at all points between the tire and the frame, fork or fender.
520 (Classic, self-supported touring)
Rack Details
Max payload for rear rack: 55lbs (25kgs)
Rack mount bolt torque: 5-6 Nm
Pannier tubing/clamp diameter: 10mm
Tire/Fender Clearance
Designed for 700x32 tires with fenders*
Can fit up to 700x38 tires with fenders*
Max tire size without fenders is 700x42*
*Due to variations in tire tread design and manufacturing, not all tires of a given size will be the same. While
it may be possible to fit a slightly larger tire, you should always test fit the tire first to ensure a minimum of
6mm clearance at all points between the tire and the frame, fork or fender.
