Oldal 1/11
1
Technaxx® * User Manual
HD Outdoor Camera with LED Lamp TX- 106
The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the
device the rst time, read the user manual carefully.
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German xed-line and 42 cent/minute from mobile networks).
Free Email: support@technaxx.de
If you drill a hole in the wall, please make sure that power cables, electrical
cords and/or pipelines are not damaged. When using the supplied mounting
material, we do not take the liability for a professional installation. You are
entirely responsible to ensure that the mounting material is suitable for the
particular masonry, and that the installation is done properly. Also ensure that
the mounting place is strong enough to hold this heavy device. When working
at higher altitudes, there is danger of falling! Therefore, use suitable
safeguards.
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product .
Warranty 2 years
Enjoy your product. Share your experience and opinion on one of the
well-known internet portals.
Features
⚫ Multi functional: video recording with sound, photo, light
⚫ PIR motion detection of ° angle up to ~7m (open areas) 60
⚫ PIR trigger time 1 1.5 seconds –
⚫ Light in high brightness of lumen (2W) up to ~8m distance 150
(open areas) & luminous time ~20 seconds
⚫ Alarm at low battery by LED indicator light
⚫ Stand alone device powered by batteries
⚫ Wall mounting (360° rotation, 180° up/down)
⚫ Many other mounting possibilities e.g. in the garden with the
ground mounting holder
⚫ Protection class IP65 (dust & waterproof)
2
Technical specications
Image sensor
1/4" CMOS 2MP
Video format / Video le
720p, 25fps / MP4
Photo format / Photo le
1280x720 Pixel / JPEG
Camera lens
F=2.0, FOV ° horizontal / ° vertical 92 92
PIR
max. distance ~7m / angle ° / trigger time 1 1.5 60 –
sec.
Light
distance ~8m / power 2W, lum (20W 150 en
incandescent bulb) / Colour: 6000 6500 Kelvin –
Storage
MicroSD* card up to 32GB (Class10)
[*not included]
Power supply
4x D-cell alkaline batteries* 1.5V
[*not included, not rechargeable]
Ø duration
battery life
Video mode 20x at night ~2.5 mon th
Photo mode 20x at night ~7 month
Light mode 20x at night ~2 month
Low battery
4.5V (LED is blinking in red)
Operation temperature
–10° 0°C up to +4 C
Weight / Dimensions
400g / (L) 19.5 x (W) 15.0 (H) 10.5 cm
Package
Contents
HD Outdoor camera with LED lamp TX-106, 1x
Ground mounting holder, 3x Screws with dowels,
User Manual
Security and Disposal Hints for Batteries: Hold children obatteries. When
a child swallowed a battery go to a doctors place or bring the child into a
hospital promptly! Look for the right polarity (+) and ( ) of batteries! Always –
change all batteries. Never use old and new batteries or batteries of different
types together. Never short, open, deform or load up batteries! Risk of injury!
Never throw batteries into re! ! Risk of explosion
Hints for Environment Protection: Packages materials are raw materials
and can be recycled. Do not disposal old devices or batteries into the
domestic waste. Protect the device from contamination and Cleaning:
pollution (use a clean drapery). Avoid using rough, coarse-grained materials
or solvents/aggressive cleaner. Wipe the cleaned device accurately.
Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388
Frankfurt a.M., Germany
3
Product overview
1
PIR (motion detection)
5
LED light
2
Microphone
6
Angle adjustment
3
Camera
7
Mounting base thumb
4
Status LED (red / green)
8
Mounting base
How to use the camera
A.1 A.2
Remove front the
cover by rotating
counter-clockwise
→ picture A.1 and A.2.
B.1 B.2
Open the lock picture B.1. →
Insert 4D-Cell batteries →
picture B.2.
Note: Install batteries with
polarity in correct position.
