Quick Start Guide
Charging the TRACPOINT
To charge your TRACPOINT mouse:
1.
Plug the USB charger into a USB
port on your computer or into
a USB charging accessory.
2.
Place the mouse onto the Charger.
The battery LED will flash green while charging and turns off
once fully charged. The first 60 seconds of charging will give
up to one hour of use. A full charge can take up to 90
minutes, giving up to 2 weeks of use. To begin using the mouse,
move the switch on the underside to the positionON
Connecting the TRACPOINT via Bluetooth 4.0
Once the mouse is charged, you can pair it to your
computer via Bluetooth 4.0.
Leave the mouse for the first three steps. OFF
1.
2.
3.
Remove any existing “ ” entriesTRACPOINT
in the list by selecting it, then select Remove
4.
5.
When “ ” appears in the list of searched TRACPOINT
devices, click on the it to pair your mouse.
If “ ”does not appear, make sure your systemTRACPOINT
supports Bluetooth 4 and Bluetooth is switched on.
Please note that Windows 7 does not support Bluetooth 4.0,
however you can purchase a USB Receiver which will work on
Windows 7. Accessories can be purchased from the Swiftpoint
Webpage, www.swiftpoint.com, and at other approved outlets.
USB Charger
Ensure Bluetooth is switched on, on your device.
Go to Bluetooth device menu in your system settings
- Windows: Settings > Devices > Add Bluetooth device
- MacOS: System Preferences/Settings > Bluetooth
Configuring TRACPOINT on PC and Mac
Open browser, click in URL box and type:
www.swiftpoint.com/download-tracpoint-driver
Follow the on-line instructions
1.
2.
L clic ont)eft- k (fr
Righ cl k t- ic (rear)
Thumb grip
LED
Middle finger
grip
Scroll-wheel Docking
point
Switch
6.
If you have a problem, switch the mouse Off then On,
and try again from step 1.
TRACPOINT Features
Connecting to more than one Bluetooth device
TRACPOINT can store pairings with up to 3 Bluetooth
devices.
When switched on, the mouse will first try to reconnect with
the most recently used device. If this cannot be found it will
try to connect to the next device in the list.
If two or more of the TRACPOINT's current Bluetooth
connections are available nearby, you can swap between
them by holding the rear button while switching OFF
then again using the On/Off switch. ON
While holding down the front button on the mouse, move the
switch on the underside of the mouse to . Then release ON
the front button as soon as the LED starts to flash orange.
Note: If you hold the front button for more than 5 seconds,
the mouse will change out of Bluetooth pairing mode,
flash green and not initiate a Bluetooth pairing process.
When not using the mouse for brief periods, dock the mouse
on the USB charger so it maintains a charge.
The mouse should be fully charged periodically.
When not using the mouse for extended periods, move the
switch on the underside of the mouse to OFF.
IMPORTANT
Install the SWIFTPOINT CONTROL PANEL to configure
the TRACPOINT mouse to perform exactly as you want it to.
Set the cursor speed, the scroll speed and direction, assign
button functionality and much more.
The driver will be updated periodically to give even more
functions later on, to make the TRACPOINT the best mousing
experience you can have.
Using the TRACPOINT
Hold the mouse with your thumb on the thumb grip and your
middle finger on the finger grip. Rest your index finger on the
front button.
To right-click, move your index
finger to the rear button
Move mouse forward
Move mouse backward
Swipe mouse left
Swipe mouse right
- Scroll down
- Scroll up
- Left pan
- Right pan
All tilt gestures can be reassigned using the CONTROL PANEL
and assign different functions.
Zoom In
Zoom Out
Next
Applic ionat
Previous
Application
PRESS Rear ButtonTILT Mouse
Tilt
Tilt + Move Gestures Functions
Tilt Rear Button Gesture Functions
Presentation Mode
Presentation Mode - Functions
Quick Start Guide V3B En © 2018 Swiftpoint Limited. All rights reserved.
Move the switch on the underside
of the mouse to PRESENT
Presentation mode operates with Microsoft PowerPoint and
some other presentation applications.
Open your presentation and start the show.
Advance Slides/Left Click
Move cursor
Previous Slide
Virtual Laser Pointer
Application switcher
- Tap front buttons
- Press and hold front button
- Tap rear button
- Press and hold rear button
- Press and hold rear then
front buttons
Hold the mouse
in the palm
of your hand
and use your
thumb to operate.
Move the switch on the underside of the mouse to ON to
retutn to standard mouse functionality.
Use your index finger to roll
the scroll wheel
Specifications
Windows 8 & 10 or higher
MacOS 10.4 or higher
Android 4.4 or higher
Operating Systems
Communications
Power
Right click
(rear)
Left click
(front)
To perform tilt gestures:
Tilt the mouse to the right
to engage the tilt gestures
and move the mouse
sideways, backwards,
or forwards.
USB Wireless (2.4GHz) , for Windows 7 PCs
(with USB Charger/Receiver purchased separately)
Bluetooth 4.0
Li-Ion Battery 3.7V, 120mAh
Charging: USB Outlet, 5V , 130mA
Install the at SWIFTPOINT CONTROL PANEL
www.swiftpoint.com/download-tracpoint-drivers
For more tips and videos for TRACPOINT , visit
www.swiftpoint.com/tracpoint-support
The directions may different depending on the appplication and
system setup.
Termékspecifikációk
| Márka: | Swiftpoint |
| Kategória: | egér |
| Modell: | TRACPOINT |
