Oldal 1/12
LIT-815780 rev.D
Vest: Steadicam® Fawcett Exovest®
“There’s actually some interesting information on using your vest here.
Please read!” - Chris Fawcett
2
Introduction
Rear rod
length clamp
Waist - VELCRO® brand
hook-and-loop fastener
Socket
block
Rear view
The Steadicam® Fawcett Exovest® is a semi-rigid exoskeletal vest that transfers the
weight and torque of supporting a Steadicam® into anatomically appropriate areas,
without interfering with natural movement.
Primary weight transfer is to the pelvis via four pads ergonomically placed around the
waistband, and primary torque transfer is via a pad system at the upper back. Lower
pads avoid compressing the abdomen in front, and the base of the spine in back. Upper
pads avoid compressing the neck, shoulder joint and spine. Crucially, the absence of
chest straps allows for unrestricted breathing and arm movement.
Pad systems are connected by rigid sliding components, and tightened by double and
triple-purchase straps for precise t under load, so weight-bearing characteristics can
be ne-tuned.
The exemplary rigidity of the outer
structure extends the torque-resisting
lever-arm from mid-back (on existing
vests) to high-shoulder level—halving
the force required to counterbalance a
Steadicam® rig.
Symmetrical twin-rod spars, rising fore
and aft from the waistband, increase
vertical range of the socket block—and
uniquely, permit both front and rear arm
mounting.
Four integral pivots allow the vest to
conform to natural body movements.
The rise and fall of the hips as weight
is shifted from one leg to the other is
accommodated by a lower pivot system,
so the socket block remains level, and at
the same height when walking—resulting
in less muscular strain, and better overall
stability and balance. The upper pivot
system allows free movement of the
shoulders.
The resultant feel is of increased lightness
and control. Between takes, the entire
vest may be relaxed by means of one
over-center lever, as the upper pad system
beds in only under load.
The Exovest® is lightweight and
less constrictive than conventional
vests—allowing for better respiration,
circulation, transpiration, and
movement—and is especially
comfortable for female operators.
The designer, Chris Fawcett,
operates and teaches Steadicam®
use worldwide and has extensively
studied the physiology of human
weight-bearing appliances. He is
the author of Steadicam® Posture.
3
Shoulder straps
Shoulder latch
Waist latch Over-center lever
Waist -
VELCRO® brand
hook-and-loop
fastener
Front rod
length
clamp
Socket
block
Bridge plate
Rear rods
Front view
