INSTALLATION
STRAP
FORCE-48
IN THE BOX COMPONENTS
q No glow ash
wRed LED indicator
ePhoto lens
rDetection lens
tCable lock hole
ySlot for installation strap
uLocking latch
i12 V jack
oScrew-thread for
standard 1⁄4”-20
aLCD screen
sOK button
dSwitch ON/SETUP/OFF
fNavigation buttons
SD card slot
Battery compartment
NOTE
Batteries sold separately.
User Manual, software updates & FAQs available at:
www.spypoint.com/support.
PREPARATION
SELECT A POWER SOURCE
You can use any combination of the above power sources
with your FORCE-48. If multiple power sources are connected,
the camera will use them in the following order: 12V, and then
the AA.
12V
Power Source
8AA alkaline or
lithium batteries
Quick Start Guide
FORCE-48
v1.0
FOR MAXIMUM PERFORMANCE
ND WITHOUT LEAKING BATTERIES
• Use new batteries.
• Use ONLY alkaline or ONLY lithium batteries.
• Do not mix new and old batteries.
• Do not use rechargeable AA batteries, as their lower
voltage may cause operating diculties.
INSTALLING AN SD CARD
The camera was designed to operate with an SD card
between 2 and 32 GB of memory.
INSERT AN SD CARD
• Make sure the camera is turned OFF.
• Locate the SD card slot. It is on the
bottom right corner of the camera
(see diagram).
• Insert an SD card (up to 32 GB) in
the slot and make sure to respect the
direction indicated in the diagram.
• The card is inserted correctly when a click is heard.
FORMAT YOUR SD CARD
After inserting your SD card, you will need to navigate
to the Format option in the settings. Use the onscreen
prompts to format the SD Card.
GENERAL SETTINGS SETUP
Use the buttons to switch to the LCD display or to  
change options, and press OK to select. Several setup pages
will be displayed.
1. To turn the camera ON/OFF,
use the ON/SETUP/OFF switch.
2. The switch must be on SETUP
to make your initial changes.
3. When the switch is on SETUP, press OK to open the MENU:
• Set the language (English, Français, Deutsch)
• Set the date (MM/DD/YY or DD/MM/YY)
• Set the time (12h or 24h)
• Set the temperature (°F/ °C)
OK
ON
OFF
SETTUP
SETUP
ADJUST THE SETTINGS
FOR THE 3 MODES OF OPERATION
PHOTO MODE
Delay: Allows you to select the time elapsed before the
camera can detect again and take the next photo.
If you want to capture multiple photos, use a shorter delay.
Once you have selected the delay, press OK.
Quality: Allows you to select a resolution of 2MP, 8MP, 16MP,
30MP or 48MP. Once you have made your selection, press OK.
Multi: Allows you to select the number of photos to be taken
per shot (from 1 to 5 photos). Once you have made your
selection, press OK.
Detect: Allows you to set motion-detector sensitivity (LOW,
NORMAL, HIGH, AUTO). Once you have made your selection,
press OK.
VIDEO MODE
Delay: Allows you to select the time elapsed before the
camera can detect again and take the next video.
Quality: Allows you to choose between 480P and 720P.
Once you have made your selection, press OK.
Length*: Allows the user to choose the video length (10 to 60 s).
Once you have made your selection, press OK.
Detect: Allows you to set motion-detector sensitivity (LOW,
NORMAL, HIGH, AUTO). Once you have made your selection,
press OK.
TIME-LAPSE
Allows you to take photos at regular predened
intervalswithout necessarily detecting a movement.
OTHER OPTIONS
Night: Choose the BOOST option for maximum brightness at
night, select OPTIMAL to reduce fuzziness at night, and MIN
BLUR to minimize the blurriness of moving objects. Once you
have made your selection, press OK.
Name: Allows to give a name to your camera.
About: Indicates the software version.
Default: Resets all default settings
Format: Allows the camera to format the SD card the next
time it is used. (Reformatting the SD card will delete all photos
and videos on the card. Only format the card if you are sure
you want to delete everything on it. Transfer all data to your
computer beforehand).
OPERATION
Once the setup is complete, turn the button from SETUP
to ON. You may also switch from SETUP to OFF and turn
the device ON later.
RED LIGHT ON THE FRONT OF THE CAMERA
When the switch is in the SETUP position, the red light will
ash to conrm a motion detection once you have adjusted
your settings.
When you move the switch to the ON position, the red light at
the front of the camera will ash for 30 seconds to allow you
to move out of the camera’s eld of view.
When the light turns o, the camera is ready for use.
*When selecting a “Video Length” over 20 seconds, only daytime videos
will be aected . Nighttime videos are limited to 20 seconds to preserve
battery life.
INSTALLATION
Recommended height of installation:
The camera must be installed at the height of the centre line
of the animal’s body.
Ideal setup for high-quality images and videos:
The target animal should be 7.5 m from the camera to get a
better line of sight.
To produce brighter photos at night, there sould be items
reecting the camera’s ash in the background.
Please note that the camera should never be directly pointed
at the sun to avoid back lighting and faulty detections.
Scan for detailed instructions, LED light pattern
descriptions, complete user manual & other
helpful information :
spypoint.com/force48-guide
Need assistance?
Just contact us!
spypoint.com/support
1-888-779-7646
More information available in the certications guide.
2-year limited warranty, visit spypoint.com/garantie
for complete details.
Made in China
More information available
in the certifications guide
FORCE-48
