SPM9747 REMOTE RECEIVER

SPM9747 DSMX SATELLITENEMPFÄNGER

BEDIENUNGSANLEITUNG

GUIDE DE L’UTILISATEUR -

SPM9747 6 DSMX SATELLITE

SPM9747 DSMX RICEVITORI AUSILIARI

GUIDA DELL’UTENTE

NOTICE

All instructions, warranties and other collateral documents are subject to

change at the sole discretion of Horizon Hobby, LLC. For up-to-date product

literature, visit horizonhobby.com or towerhobbies.com and click on the

support or resources tab for this product.

Meaning of Special Language

The following terms are used throughout the product literature to indicate

various levels of potential harm when operating this product:

WARNING: Procedures, which if not properly followed, create the probability

of property damage, collateral damage, and serious injury OR create a high

probability of super cial injury.

CAUTION: Procedures, which if not properly followed, create the probability

of physical property damage AND a possibility of serious injury.

NOTICE: Procedures, which if not properly followed, create a possibility of

physical property damage AND a little or no possibility of injury.

WARNING: Read the ENTIRE instruction manual to become familiar

with the features of the product before operating. Failure to operate

the product correctly can result in damage to the product, personal property

and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution

and common sense and requires some basic mechanical ability. Failure to

operate this Product in a safe and responsible manner could result in injury

or damage to the product or other property. This product is not intended for

use by children without direct adult supervision. Do not attempt disassembly,

use with incompatible components or augment product in any way without

the approval of Horizon Hobby, LLC. This manual contains instructions for

safety, operation and maintenance. It is essential to read and follow all the

instructions and warnings in the manual, prior to assembly, setup or use, in

order to operate correctly and avoid damage or serious injury.

Age Recommendation: Not for children under 14 years. This is not a toy.

WARNING AGAINST COUNTERFEIT PRODUCTS: Always purchase

from a Horizon Hobby, LLC authorized dealer to ensure authentic high-

quality Spektrum product. Horizon Hobby, LLC disclaims all support and warranty

with regards, but not limited to, compatibility and performance of counterfeit

products or products claiming compatibility with DSM or Spektrum technology.

NOTICE: This product is only intended for use with unmanned, hobby-grade,

remote-controlled vehicles and aircraft. Horizon Hobby disclaims all liability outside

of the intended purpose and will not provide warranty service related thereto.

SPM9747

Type DSMX SRXL2 Serial “Fly By”Telemetry Receiver

Dimensions (L × W × H) 25.5 × 18.2 × 7.5 mm (1. × 0.71 × 0.29 in)

Weight 3.0g

Band 2.4 GHz

Voltage Range 3.3–8.4V

Spektrum SRXL2

The SPM9747 uses SRXL2 to communicate with receivers. SRXL2 is a serial

communication protocol using a bi-directional data link in which one wire can

communicate all control data. Previous Spektrum serial receivers were based

on the Spektrum remote receiver protocol, which is not compatible with SRXL2.

The SPM9747 is only compatable with SRXL2 receivers such as the AR637T

and AR6610T.

To learn more about the features and bene ts of SRXL2 visit www.SRXL2.com

Binding

1. Press and hold the bind button on the receiver.

Note: The bind button (or plug) on the main recevier, or the bind button on the

SPM9747 SRXL2 remote receiver can be used to initiate bind.

2. Power on the aircraft. The orange LED will begin  ashing.

3. Put the transmitter into bind mode. The bind process is complete when the

orange LED on the receiver is solid.

Installation Instructions

Always use DSMX® SRXL2 remote receivers with DSMX SRXL2 main receivers.

Connecting New Remote Receivers

1. Connect a Remote Receiver Extension to the main receiver and

remote receiver.

2. Install the receiver in a location as far as possible from the main

receiver antenna.

3. Install the Remote Receiver as far as possible from metal, carbon  ber,

and wiring.

4. Follow the receiver binding instructions to bind the main receiver and

remote receiver(s).

The transmitter and receiver will need to be re-bound any time a new remote

receiver is added to the system.
