Oldal 1/24

Instruction Manual

Bedienungsanleitung

Manuel d’utilisation

Manuale di Istruzioni

S10

Spektrum G2 USB-C 2S Battery Charger

SPMXC0040

General Charging Warnings

WARNING: Failure to exercise caution while

using this product and comply with the

following warnings could result in product

malfunction, electrical issues, excessive heat, FIRE,

and ultimately injury and property damage.

• NEVER LEAVE CHARGING BATTERIES

UNATTENDED DURING USE.

• NEVER CHARGE BATTERIES OVERNIGHT.

• The power supply must deliver power at Safety Extra

Low Voltage (SELV).

• Never attempt to charge dead, damaged or wet

battery packs.

• Never attempt to charge a battery pack containing

different types of batteries.

• Never allow children under 14 years of age to charge

battery packs.

• Never charge batteries in extremely hot or cold places

or place in direct sunlight.

• Never charge a battery if the cable has been pinched

or shorted.

• Never connect the charger if the power cable has

been pinched or shorted.

• Never connect the charger to an automobile 12V

battery while the vehicle is running.

• Never attempt to dismantle the charger or use a

damaged charger.

• Never attach your charger to both an AC and a DC

power source at the same time.

• Never connect the input jack (DC input) to AC power.

• Always use only rechargeable batteries designed

for use with this type of charger in the correct

programming mode.

• Always inspect the battery before charging.

WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product before

operating. Failure to operate the product correctly can result in damage to the product, personal property

and cause serious injury.

This is a sophisticated hobby product. It must be operated with caution and common sense and requires some

basic mechanical ability. Failure to operate this product in a safe and responsible manner could result in injury

or damage to the product or other property. This product is not intended for use by children without direct adult

supervision. Do not attempt disassembly, use with incompatible components or alter product in any way without

the approval of Horizon Hobby, LLC. This manual contains instructions for safety, operation and maintenance. It

is essential to read and follow all the instructions and warnings in the manual, prior to assembly, setup or use, in

order to operate correctly and avoid damage or serious injury.

The following terms are used throughout the product literature to indicate various levels of potential harm when

operating this product:

WARNING: Procedures, which if not properly followed, create the probability of property damage, collateral

damage, and serious injury OR create a high probability of superﬁcial injury.

CAUTION: Procedures, which if not properly followed, create the probability of physical property damage AND a

possibility of serious injury.

NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND little or

no possibility of injury.

Notice

All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon

Hobby, LLC. For up-to-date product literature, visit horizonhobby.com or towerhobbies.com and click on the sup-

port or resources tab for this product.

Age Recommendation: Not for children under 14 years. This is not a toy.

WARNING: To reduce the risk of fire or electric shock, carefully follow these instructions.

CAUTION: This appliance is not intended for use by persons (including children) with reduced physical

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure they do not play with the appliance.

• Cleaning and user maintenance shall not be performed by children without supervision.

Meaning of Special Language

S10

Output Port Connector IC2

Input Voltage (required power supply, not included )DC 5.0V (3.0A Max)

Charge Current 1-8.4V (1.5A Max)

Supported Battery Type Smart G2 LiPo 2S

Related Battery Capacity (Max.) 500–5300mAh

Display LED

Operating Temperature 0–40°C (32–104°F)

Storage Temperature -20~60°C (-4–140°F)

Dimensions

Length 44mm

Width 24mm

Height 14.5mm

Weight 25g

Specifications

• Always keep the battery away from any material that

could be affected by heat.

• Always monitor the charging area and have a ﬁre

extinguisher available at all times.Always end the

charging process if the battery becomes hot to the

touch or starts to change form (swell) during the

charge process.

• Always connect the charge cable to the charger ﬁrst,

then connect the battery to avoid short circuit between

the charge leads. Reverse the sequence when

disconnecting.

• Always connect the positive red leads (+) and negative

black leads (–) correctly.

• Always disconnect the battery after charging, and let

the charger cool between charges.

• Always charge in a well-ventilated area.

• Always terminate all processes and contact Horizon

Hobby if the product malfunctions.

• Charge only rechargeable batteries. Charging non-

rechargeable batteries may cause the batteries to

burst, resulting in injury to persons and/or damage to

property.

• The socket-outlet shall be installed near the

equipment and shall be easily accessible.

WARNING: Never leave charger unattended,

exceed maximum charge rate, charge with

non-approved batteries or charge batteries in the

wrong mode. Failure to comply may result in

excessive heat, fire and serious injury.

CAUTION: Always ensure the battery you are

charging meets the specifications of this

charger and that the charger settings are correct. Not

doing so can result in excessive heat and other

related product malfunctions, which can lead to user

injury or property damage. Please contact Horizon

Hobby or an authorized retailer with compatibility

questions.
