SMARTBoard MX series
interactive displays
INSTALLATION AND MAINTENANCE
FOR MODELS:
lSBID-MX265
lSBID-MX275
lSBID-MX286
smarttech.com/kb/171257
Trademark notice
SMARTBoard, smarttech, the SMART logo and all SMART taglines are trademarks or registered trade marks of SMARTTechnologie sULC in the U.S. and/or other
countries. All third-party product and company names may be trademarks of their respective owners.
Copyright notice
© 2018SMARTTechnologiesULC. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrie val system or
translated into any language in any form by any means without the prior written consent of SMARTTechnologie sULC. Information in this manual is subject to change
without notice and does not represe nt a commitment on the part of SMART.
This product and/or use there of is covered by one or more of the following U.S. patents:
www.smarttech.com/patents
06-2018
i smarttech.com/kb/171257
Important information
IMPORTANT
There are critical software updates for the display that you need to install to ensure the display is
fully functional and provides the best experience. Connect the display and iQ appliance to a
wired or wireless network with Internet access to automatically download and apply these
updates as well as future updates.
WARNING
lFailure to follow the installation instructions shipped with the SMART product could result in
injury and product damage which may not be covered by the warranty.
lDo not open or disassemble the SMART product. You risk electrical shock from the high
voltage inside the casing. Opening the casing also voids the warranty.
lDo not stand (or allow children to stand) on a chair to touch the surface of the SMART
product. Rather, mount the product at the appropriate height.
lTo reduce the risk of fire or electric shock, do not expose the SMART product to rain or
moisture.
lIf the SMART product requires replacement parts, make sure the service technician uses
replacement parts specified by SMARTTechnologies or parts with the same characteristics
as the original.
lEnsure that any cables that cross the floor to the SMART product are properly bundled and
marked to avoid a trip hazard.
lDo not insert objects inside the cabinet ventilation holes, because they could touch
dangerous voltage points and cause electric shock, fire or product damage which may not
be covered by the warranty.
lDo not place heavy objects on the power cable. Damage to the cable could cause shock,
fire or product damage which may not be covered by the warranty.
lUseonly extension cords and outlets that can fully accommodate the display’s polarized
plug.
IMPORTANT INFORMATION
ii smarttech.com/kb/171257
lUse the power cable provided with the display. If a power cable is not supplied, contact
your supplier. Use only power cables that match the AC voltage of the power outlet and that
comply with your country’s safety standards.
lIf the glass is broken, do not touch the liquid crystal. To prevent injury, handle glass
fragments with care when disposing of them.
lDo not move or mount the display by connecting rope or wire to its handles. The display is
heavy, and failure of the rope, wire or handle could lead to injury.
lUse only VESA®-approved mounts if using a mount other than the one supplied with the
display..
lDisconnect all of the display’s power cables from the wall outlet and seek assistance from
qualified service personnel if any of the following occur:
oThe power cable or plug is damaged
oLiquid is spilled into the display
oObjects fall into the display
oThe display is dropped
oStructural damage, such as cracking, occurs
oThe display behaves unexpectedly when you follow operating instructions
lBefore inserting or removing the iQ appliance from the display, turn off the display using the
switch at the back of the display. See Open Pluggable Slot computer (OPS) disclaimer for
more information.
CAUTION
lTurn off the display before cleaning its screen. Otherwise, you may scramble the desktop
icons or inadvertently activate applications when you wipe the screen.
lAvoid setting up and using the SMART product in an area with excessive levels of dust,
humidity and smoke.
lMake sure an electrical socket is near the SMART product and remains easily accessible
during use.
IMPORTANT INFORMATION
iii smarttech.com/kb/171257
lThe SMART product should be used only with European TN and TT power distribution
systems.
It is not suitable for older, IT-type power distribution systems found in some European
countries. This system (IT-type) is widely used isolated from earth, in some installations in
France, with impedance to earth, at 230/400V, and in Norway, with voltage limiter, neutral
not distributed, at 230V line-to-line.
Contact qualified personnel if you’re uncertain of the type of power system available where
you’re installing the SMART product.
lThe accessory slot’s maximum available power is 60 W. The slot is not a limited power
source. To reduce the risk of fire, make sure that accessories connecting to the slot satisfy
the fire enclosure requirements of IEC60950-1.
lYou must connect the USB cable that came with the SMART product to a computer that has
a USB compliant interface and that bears the USB logo. In addition, the USB source
computer must be compliant with CSA/UL/EN 60950 and bear the CE mark and CSA and/or
UL Mark(s) for CSA/UL 60950. This is for operating safety and to avoid damage to the
SMART product.
IMPORTANT
lThe following are the normal operating requirements for the display, including AM module
and speakers:
Model Power requirements
SBID-MX265 100V to 240V AC, 50 Hz to 60 Hz, 115 W max
SBID-MX275 100V to 240V AC, 50 Hz to 60 Hz, 224 W max
SBID-MX286 100V to 240V AC, 50 Hz to 60 Hz, 265 W max
lFor additional requirements and other information, refer to the display’s specifications (see
More information on page9).
Federal Communication Commission
interference statement
This device complies with Part 15 of the FCC Rules.Operation is subjectto the following two conditions:
1. This device may not cause harmful interference, and
2. this device must accept any interference received,including interference that may cause undesired operation.
IMPORTANT INFORMATION
iv smarttech.com/kb/171257
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules.These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
CAUTION
Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate this equipment.
Radiation exposure statement
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should
be installed and operated with minimum distance of 20 cm between the antenna of this device and allnearby persons. This
transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Innovation, Science and Economic Development
Canada statement
This device complies with RSS-247 of the Innovation, Science and Economic Development Canada Rules. Operation is subject
to the following two conditions:
1. This device may not cause harmful interference, and
2. this device must accept any interference received,including interference that may cause undesired operation.
Radiation exposure statement
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should
be installed and operated with minimum distance of 20 cm between the antenna of this device and allnearby persons. This
transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Cet appareil est conforme à la norme ISED CNR-247pour les appareils radio agréés. Son fonctionnement est soumis aux deux
conditions suivantes:
1. le dispositif ne doit pas produire de brouillage préjudiciable,et
2. ce dispositif doit accepter tout brouillage reçu,y compris un brouillage susceptible de provoquer un fonctionnement
indésirable.
Déclaration d’exposition aux radiations
Cet équipement est conforme aux limites d’exposition aux rayonnements ISED établies pour un environnement non contrôlé.
Cet équipement doit être installé et utilisé avecun minimum de 20 cm de distance entre la source de rayonnement et votre
corps. Cet émetteur ne doit pas être co- implantés ou exploités conjointement avec une autre antenne ou émetteur.
EU declaration of conformity: AM40
Hereby,SMART Technologies ULCdeclares that the radio equipment type OPS, AM40 is in compliance with Directive
2014/53/EU.
The full text of the EU declaration of conformity is available at the following internet address: smarttech.com/compliance
The frequency band and the maximum transmitted power in EU are listed below:
IMPORTANT INFORMATION
v smarttech.com/kb/171257
Transmitting Band (MHz) Maximum Transmit Power EIRP (dBm)
2400–2483.5 19
5150–5350 16
5470–5725 16
Restrictions in
AT/BE/BG/CZ/DK/EE/FR/DE/IS/IE/IT/EL/ES/CY/LV/LI/LT/LU/HU/MT/NL/NO/PL/PT/RO/SI/SK/TR/FI/SE/CH/UK/HR. 5150MHz-
5350MHz is for indoor use only.
CAUTION: EXPOSURE TO RADIO FREQUENCY RADIATION
This equipment complies with EU radiation exposure limits set forth for an uncontrolled environment. This equipment should
be installed and operated with minimum distance 20 cm between the radiator and your body.
CONTENTS
viii smarttech.com/kb/171257
Chapter 6: Maintaining the display 51
Checking the display installation 51
Cleaning the screen 51
Cleaning the touch sensors 52
Maintaining ventilation 53
Preventing condensation 53
Replacing the pens 53
Turning the display off and back on 53
Resetting the display 54
Removing and transporting the display 54
Chapter 7: Troubleshooting 57
Troubleshooting the display 57
Troubleshooting the iQ system software 62
Referring to the SMART knowledge base for additional troubleshooting information 73
Contacting your reseller for additional support 73
Appendix A: Using iQ system settings 75
Network settings 75
Application settings 75
System settings 76
Appendix B: Using display settings on your SMARTBoard MX 79
Accessing the display’s settings 79
Exiting the display’s settings 79
Network 80
Screen lock 80
Advanced 81
Update 82
Recovery 82
About 83
Appendix C: Remotely managing the display 85
Connecting a computer to the display 86
Configuring the computer’s serial interface settings 86
Power states 87
Commands and responses 88
Commandinventory 89
Resolving issues with remote management 92
Appendix D: Identifying your display 93
Identify your display 93
Appendix E: Supported resolutions 95
HDMI1 in, HDMI 2 in and HDMI 3 in 95
Chapter 1
1 smarttech.com/kb/171257
Welcome
About this guide 1
About the SMARTBoard MX 2
Features 2
Identifying your SMARTBoard MX series interactive display model 3
Components 3
iQ appliance 4
Screen 4
Pens 4
Front connector panel 5
Front control panel 5
Remote control 6
Remote control sensor 7
Status light 7
Ambient light sensor 7
Internal speakers 7
Related products 7
SBA-100 projection audio system 8
SMART Audio 400 classroom amplification system 8
USB extenders 8
More information 9
This chapter introduces the SMARTBoard® MX series interactive displays.
About this guide
This guide explains how to install and maintain a SMARTBoard MX series interactive display. It
includes the following information:
lHow to install the display
lHow to connect power and devices
lHow to turn on the display for the first time
lHow to configure the iQ appliance
CHAPTER 1
WELCOME
2 smarttech.com/kb/171257
lHow to maintain the display for years of use
lHow to troubleshoot issues with the display
In addition, this guide includes information on the display’s settings and remote management
support.
This guide is intended for those who install and maintain displays in their organizations. Other
documentation and resources are available for those who use displays (see More information on
page9).
About the SMARTBoard MX
The SMARTBoard MX series interactive display is the hub of your classroom or meeting room.
PC-free embedded computing provides one-touch access to collaborative tools, including a
whiteboard, wireless screen sharing and a web browser. There’s no need for wires, cables or
manual software and firmware updates.
Features
The display includes the following features:
Feature Description
iQ technology The display’s iQ appliance provides one-touch access to
collaborative tools, including a whiteboard, wireless screen sharing
and a web browser.
Touch support You can do everything on the display that you can do at your
computer—open and close applications, meet with others, create
new documents or edit existing ones, visit websites, play and
manipulate videos, and so on—by touching the display’s surface.
You can use an array of gestures within applications, including
panning, scaling, rotating and zooming in and out.
The display’s support for up to 10 simultaneous touch, writing and
erase points enables you and other users to interact with objects
on the screen at the same time.1
Writing and drawing
support
You can write over applications in digital ink using one of the
supplied pens, and then erase the digital ink using your palm.
Up to two users can write or draw digital ink on the screen at the
same time.
Audio support The display includes integrated speakers for presenting audio from
connected input sources.
1Requires SMART Product Drivers to be installed.Some applications might not support alltouch points.
CHAPTER 1
WELCOME
3 smarttech.com/kb/171257
Identifying your SMARTBoard MX series interactive display model
The following models of SMARTBoard MX series interactive display are available:
Model Screen size (approximate)
SBID-MX265 65" (165 cm)
SBID-MX275 75" (190 cm)
SBID-MX286 86" (218 cm)
Refer to the specifications for detailed technical information for this model, including product
dimensions and weights (see on page9).More information
For help identifying your display, see on page93.Appendix D: Identifying your display
Components
The display consists of the following components:
No. Name More information
Pictured
1 Screen Page4
2Front control panel Page5
3 Light sensor page7
4 Remote control sensor / status light page7
5Pen (×2) Page4
CHAPTER 1
WELCOME
5 smarttech.com/kb/171257
CAUTION
When you return a pen to the magnetic holder, make sure it’s centered in its holder to keep it
from falling and being damaged.
Front connector panel
The front connector panel includes connectors for USB
peripherals and a computer or other input source.
No. Name Procedure
1 USB Type-A connector Connect USB drives and other devices that
you want to use with the currently selected
input source.
2 USB Type-A connector Connect a USBdrive to update the display’s
firmware.
3 USB Type-B connector Connect a USB cable to the display and
computer to provide touch control of the
computer connected to HDMI 3.
4 HDMI 3 input connector Connect a computer or other input source to
the display (see page23).
Front control panel
The front control panel contains the Power, Input Select, Menu,
Freeze, Mute and volume control buttons.
No. Name SMARTBoard MX procedure
1 Power Press to wake the display.
Press to again enter Sleep mode.
2Input select Press to switch input source.
CHAPTER 1
WELCOME
6 smarttech.com/kb/171257
No. Name SMARTBoard MX procedure
3Menu Press to open the display’s settings.
4 Freeze [N/A]
5Mute Press to mute or unmute the volume.
6Volume decrease Press to turn down the volume.
7Volume increase Press to turn up the volume.
Remote control
The table below lists the functions available for the remote control.
No. Name Function
1 MUTE Mute or unmute the volume
2 SOURCE Open the input source menu
3 INFO Press to show the display’s detected
resolution and refresh rate for the current
input source
4 SYS Open the display’s settings
5 AUDIO Change the display’s audio mode
6 VOL + / VOL - Increase or decrease volume
CHAPTER 1
WELCOME
7 smarttech.com/kb/171257
No. Name Function
7 [Number buttons] Press buttons on the number pad to
customize settings
8 POWER Wake the display.
Enter Sleep mode.
Remote control sensor
The status light blinks green and red when it registers a button being pressed on the remote
control.
Status light
The status light blinks green and red when it registers a button being pressed on the remote
control.
When the status light is red, the display is in a low power state. To wake the display, press the
Power button on the front control panel or POWERon the remote control.
Ambient light sensor
The ambient light sensor can detect the room brightness and adjust the display’s brightness. Make
sure is enabled in Brightness and volume in the display’s settings. SeeAuto Brightness and volume
on page81.
Internal speakers
The display includes two 10 W rms integrated speakers. You can also connect external speakers
(see Connecting external speakers on page25).
Related products
Related products for the display include the following:
lSBA-100 projection audio system
lSMART Audio 400 classroom amplification system
lUSB extenders
CHAPTER 1
WELCOME
8 smarttech.com/kb/171257
SBA-100 projection audio system
The SBA-100 projection audio system consists of two 14 W speakers and is
intended for wall-mounted displays. You can control volume using the
display’s front control panel or the digital volume controls in a connected
computer’s operating system.
For more information, see the SBA-100 projection audio system specifications
(smarttech.com/kb/171146).
SMART Audio 400 classroom amplification system
The SMART Audio 400 classroom amplification system provides high-quality
audio amplification. The system comes with a teacher microphone and optional
student microphone. Multiple speaker options are available, including wall- and
ceiling-mounted speakers. The amplifier receives audio signals from the
microphones and translates them into crystal-clear sound through the speakers.
For more information, see the SMART Audio 400 classroom amplification system specifications
(smarttech.com/kb/171137).
NOTE
The SMARTAudio 400 classroom amplification system is available only in Canada and U.S.
USB extenders
As noted in Connecting cables for room computers, guestlaptops and other input sources on
page23, the USB connection between the display and computer should be no longer than 16'
(5m). If you need to connect a computer that is more than 16' (5 m) from the display, use one of the
following USB extenders:
Extender Specifications
USB-XT smarttech.com/kb/119318
CAT5-XT-1100 smarttech.com/kb/170202
SMARTrecommends only using USBextenders with the USB connectors on the side and bottom
connector panels on the display.
Fore more information, see:
CHAPTER 1
WELCOME
9 smarttech.com/kb/171257
lTroubleshooting and extending the USB 2.0 and USB 3.0 connection to your SMART
interactive display
lUSBcables and connectors
More information
In addition to this guide, SMART provides the following documents for the display:
Document Link
User’s guide smarttech.com/kb/171284
SBID-MX165, MX175, MX186, MX265, MX275 and MX286 installation
instructions
smarttech.com/kb/171274
SBID-MX265 specifications smarttech.com/kb/171240
SBID-MX275 specifications smarttech.com/kb/171259
SBID-MX286 specifications smarttech.com/kb/171260
Comparison smarttech.com/kb/171161
These documents are available in the Support section of the SMART website
(smarttech.com/support). Scan the QR code on the cover of this guide to view the SMARTBoard
MX series interactive displays pages in the Support section.
CHAPTER 2
INSTALLING THE DISPLAY
12 smarttech.com/kb/171257
IMPORTANT
lTransport the display at your own risk. SMART cannot accept liability for damages or injury
that occur during the display’s transportation.
lWhen transporting the display, do the following:
oFollow local safety regulations and standards.
oKeep the display in its original packaging.
oMove the display so that its top frame faces up.
oHave at least two people move the display.
TIP
Display packaging may be labeled to indicate which side is the front. Look for “FRONT” on the
packaging to help orient the box during transportation.
Using transportation aides
You can use the following aides to transport the display:
lCart
lFurniture dolly
lMechanical lift
Accommodating doorways, hallways and elevators
In some situations, you might need to remove the display from its packaging to move it through
narrow doorways or hallways or on to an elevator. In these situations, SMART recommends that
you keep the foam pieces on the bottom corners of the display. These foam pieces protect the
display if you need to set it down during transport.
You might also need to rotate the display so that its top frame faces to the side. You can do this
during transportation, but when you install the display, it must be in landscape orientation (with the
top frame facing up).

Termékspecifikációk

Márka: SMART Technologies
Kategória: nincs kategorizálva
Modell: SBID-MX275

Szüksége van segítségre?

Ha segítségre van szüksége SMART Technologies SBID-MX275, tegyen fel kérdést alább, és más felhasználók válaszolnak Önnek


Útmutatók nincs kategorizálva SMART Technologies

SMART Technologies

SMART Technologies SBID-6286S-PW Útmutató

1 Október 2024
SMART Technologies

SMART Technologies SBID-MX255-V2-PW Útmutató

1 Október 2024
SMART Technologies

SMART Technologies SBID-6265S-PW Útmutató

1 Október 2024
SMART Technologies

SMART Technologies SBID-MX275 Útmutató

1 Október 2024
SMART Technologies

SMART Technologies SBID-6286S Útmutató

30 Augusztus 2024
SMART Technologies

SMART Technologies SBID-6275S-V3 Útmutató

30 Augusztus 2024
SMART Technologies

SMART Technologies SBID-6265S-V3-PW Útmutató

30 Augusztus 2024
SMART Technologies

SMART Technologies SBID-6286S-C Útmutató

30 Augusztus 2024

Útmutatók nincs kategorizálva

Legújabb útmutatók nincs kategorizálva

MOZA

MOZA SR-P Útmutató

10 Április 2025
Soundstream

Soundstream VRN-64HBL Útmutató

10 Április 2025
Panasonic

Panasonic Lumix DMW-AC11 Útmutató

10 Április 2025
Planet

Planet PWR-240-48 Útmutató

9 Április 2025
CaterChef

CaterChef 445001 Útmutató

9 Április 2025
IFM

IFM E40581 Útmutató

9 Április 2025
Livn

Livn Bolt Útmutató

9 Április 2025
Livn

Livn Beats Útmutató

9 Április 2025
Alpine

Alpine DP2-40C-BC Útmutató

9 Április 2025
IFM

IFM O3R252 Útmutató

9 Április 2025
