32-Port USB Charging Station
for Smartphones
Models: CSD32USB, CSDXB32USB, CSDXS32USB
(Series number: AG-0737)
Owner’s Manual
TrippLite.Eaton.com/support
Copyright © 2023 Tripp Lite. All trademarks are the sole property of their respective owners.
WARRANTY REGISTRATION
Register your product today and be
automatically entered to win an ISOBAR
®
surge protector in our monthly drawing!
tripplite.com/warranty
2
1. Important Safety Instructions
SAVE THESE INSTRUCTIONS
This manual contains instructions and warnings that must be followed during the installation and operation of the product described
in this manual. Failure to comply may invalidate the warranty and cause property damage or personal injury.
USB Charger/Hub Unit:
• Connect the unit to an outlet that is in accordance with your local building codes and adequately protected against excess current,
short-circuits and earthly faults.
• The electrical outlet supplying power to the equipment should be installed near the unit and be easily accessible.
• The AC plug on the power supply cord serves as the disconnect device.
• Connect the unit directly to a properly grounded AC power outlet.
• Do not modify the plug, and do not use an adapter that would eliminate the ground connection.
• If any of the following situations arise, schedule an appointment with a service technician to have your equipment inspected:
• The equipment has been exposed to moisture
• The equipment has been dropped and damaged
• The equipment shows obvious signs of breakage
• The equipment is not functioning properly or is not functioning according to the instructions described in this Owner’s Manual
• Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of
the life support equipment or to significantly affect its safety or effectiveness is not recommended.
Charging Station Cabinet:
• Keep the charging station in a controlled indoor environment away from moisture, temperature extremes, flammable liquids and
gasses, conductive contaminants, dust and direct sunlight.
• Leave adequate space around the charging station for proper ventilation. Do not block, cover or insert objects into the charging
station’s external ventilation openings.
• For best performance, keep indoor temperature between 32°F and 86°F (0°C and 30°C).
• Do not remove any warnings, cautions or descriptive labels from the charging cart.
• The charging station is extremely heavy. Use caution when handling the charging station. Do not attempt to unpack or mount it
unassisted. Use a mechanical device such as a forklift or pallet jack to move the charging station in the shipping container.
• Do not place containers of liquid or stack items on the cabinet.
• Inspect the shipping container and the charging station for shipping damage. Do not use the charging station if it is damaged.
• Use caution when cutting packing materials. The charging station could be scratched, causing damage not covered by the warranty.
• Save all packing materials for later use. Repacking and shipping the charging station cabinet or equipment without the original
packing materials may cause product damage that will void the warranty.
For Wall-Mount and Desktop Installations:
• The charging station must be installed by a qualified technician.
• Before mounting, first make sure that the wall surface can safely support the combined load of the charging station, equipment
stored and all attached hardware and components.
• The charging station can support equipment up to its maximum load capacity of 180 lb. (81.6 kg).
• Always use suitable mounting means when installing to cinder blocks, concrete, drywall or wood studs. Install securely to the wall
using proper hardware (not provided).
WARNING: The supporting surface must be able to safely support the combined load of the charging station, equipment stored and all
attached hardware and components (see 8. Specifications for more information on your model’s weight and dimensions).
3
2. Overview
Your charging station is an all-in-one solution for storing, charging and syncing for up to 32 smartphones. Your charging station can be
conveniently mounted to walls as well as used for stationary desktop installations. To prevent theft and device tampering, your
charging station enclosure comes equipped with locking steel doors. A padlock hasp accessory (optional) attaches to the doors to
provide an extra measure of protection.
Explanation of Symbols:
CAUTION: RISK OF DANGER
PROTECTIVE BONDING TERMINAL
AC VOLTAGE
 The wall surface, wall studs and all user-supplied mounting hardware must be able to support the
combined weight of the cabinet and all equipment that will be installed in the cabinet. The cabinet can support equipment up to its
maximum load capacity of 180 lb. (81.6 kg).
Wall-mounting holes are spaced 16 in. (406 mm) apart horizontally to accomodate standard placement of wall studs. It is advised to
safety distribute the weight of the cabinet and all installed equipment.
