To reduce the risk of fire or electric shock,
do not expose this appliance to rain or
moisture.
To reduce the risk of electric shock, do not
remove cover(or back). No user-
serviceable parts inside. Refer servicing to
qualified service personnel.
For heat dispersal, do not install this unit in a
confined space such as a bookcase or similar
enclosure.
To reduce the risk of fire, do not cover the
ventilation of the apparatus with newspapers,
tablecloths, curtains, etc. And do not place
lighted candles on the apparatus.
To reduce the risk of fire or electric shock, do
not place objects filled with liquids, such as
vases, on the apparatus.
WARNING
• Do not drop, hit or otherwise expose this
unit to strong shock of any kind.
• Do not disassemble or modify the unit in any
way.
• Avoid installation in extremely hot or cold
locations, or in an area that is exposed to
direct sunlight or heating equipment
• Keep the unit free from moisture, water, and
dust.
• Do not let foreign objects in the unit.
• Do not let insecticides, benzene, and thinner
come in contact with the unit.
Caution
Thank you for purchasing this audio receiver with Bluetooth wireless technology.
You can enjoy music wirelessly with a music player featuring Bluetooth wireless technology
such as MP3 player, mobile phone, etc., if this unit is connected to Sherwood compatible
receiver or amplifier such as RD-6503, RD-6513, RX-4503, RX-773, etc..(For information
on Sherwood compatible receivers or amplifiers, contact your dealer.)
• This unit supports the Bluetooth wireless technology specification version 1.2 and A2DP
(Advanced Audio Distribution Profile : Transmitting or receiving audio content of high-quality).
• The music player featuring Bluetooth wireless technology is required to support A2DP, too.
Note on recycling (For EUROPE)
This product’s packaging materials are recyclable and can be reused.
Please dispose of any materials in accordance with the local recycling
regulations.
When discarding the unit, comply with local rules or regulations. Batteries
should never be thrown away or incinerated but disposed of in accordance
with the local regulations concerning chemical waste. This product and the
accessories packed together constitute the applicable product according to
the WEEE directive except batteries.
Pairing with a device featuring Bluetooth
wireless technology
• Devices featuring Bluetooth wireless technology
need to be paired with each other beforehand.
• Once devices are paired, there is no need for
pairing again, except in following cases:
* Pairing information between this unit and the
device is deleted.
* This unit is paired with a new device.
1. Connect this unit to your Sherwood compatible
receiver or amplifier.
• Then the LED of this unit will blink.
2. Place this unit and the device to be paired
together within 1 meter (3 ft).
3. Perform the pairing procedure on the device.
(For details, see the operating instructions of
the device.)
Note: Passcode of this unit is fixed at “0000”.
Depending on the device, it may be necessary
to input the passcode(in this case, “0000”).
4. If the pairing is successful, the LED of this unit
will light up.
• If the LED of this unit blinks, repeat the
procedure from the step 2.
Listening to the music
• You can listen to the music of the device
featuring Bluetooth wireless technology on the
Sherwood compatible receiver or amplifier to
which this unit is connected.
1. Connect this unit to your Sherwood compatible
receiver or amplifier.
• Then the LED of this unit will blink.
2. Select the input source on your receiver or
amplifier.
3. Start playback on the device.
• If the wireless connection featuring Bluetooth
technology between this unit and the device is
established, the LED of this unit lights up and
the sound is heard.
• Bluetooth wireless technology operates within
a range of about 10 meters (33 ft). Maximum
communication range may vary depending on
obstacles (person, metal, wall, etc.) or
electromagnetic environment.
Notes:
• If the wireless connection featuring Bluetooth
technology cannot be established with the device
paired already, try pairing again.
• We do not take any responsibility for leakage of
information during communication.
• Connection with all devices featuring Bluetooth
wireless technology cannot be guaranteed.
• Depending on the device, communication may
take some time.
Troubleshooting
If you run into any problems using this unit, check
the following list.
Should any problem persists, consult your dealer.
• Pairing cannot be done
- Bring this unit and the device closer together.
• Wireless connection featuring Bluetooth
technology cannot be established.
- Check that the device is turned on and the
corresponding function is on.
- Pairing information may be deleted.
Try pairing again.
• No sound or distorted sound
- Check that the device supports A2DP (Advanced
Audio Distribution Profile).
- If a device that generates electromagnetic radiation
such as a wireless LAN, other device featuring
Bluetooth wireless technology or a microwave oven
is nearby, move away from such sources.
- Remove any obstacle between this unit and the
device.
Specifications
• Maximum Communication Range :
Approximately 10 m ( 33 ft)
• Frequency Band : 2.4000 GHz ~ 2.4835 GHz
• Terminals : 24 pin
• Frequency Response, 100 Hz ~ 15 kHz : ±3 dB
• Signal to Noise Ratio : 85 dB
• RF Level : -30 dBm<
=
The Bluetooth word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc. and any
use of such marks by Sherwood Corporation is
under license. Other trademarks and trade names
are those of their respective owners.
Note : Design and specifications are subject to
change without notice for improvements.
QD ID : B013892
