Oldal 1/8
ROTH BAR3
High-Power Soundbar with
on-board DSP and Wireless Subwoofer
Turn it up.
''
''
2 | Roth BAR3 Sub Zero User Manual
ROTH BAR3
Powered Soundbar System
Important Safety InStructIonS
reaD Before operatInG eQuIpment
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of a sufficient magnitude
to constitute a risk of electric shock to a person.
The exclamation point within an equilateral
triangle, is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
reaD manuaL
Read all the safety and operating instructions before the
product is operated.
retaIn manuaL
This manual should be retained for future reference.
HeeD WarnInGS
All wamings on the product and in the operating instructions
should be adhered to.
foLLoW InStructIonS
All operating and use instructions should be followed.
cLeanInG
The product should be deaned only with a polishing doth
or a soft dry doth. Never use volatile liquids since they may
damage the product.
Water anD moISture
Do not use this product near water such as near a bathtub,
kitchen sink, in a wet basement; or near a swimming pool, etc.
oBJect or LIQuID entry
Do not insert any kind of object into this product through any
opening as they may make contact with electrical points and
result in a fire or electric shock. Avoid spilling any kind of liquid
on the product.
VentILatIon
Openings in the cabinet are provided for ventilation and to
protect the product from overheating, and these openings
must not be blocked or covered.
Heat
The product should be placed away from sources of heat
such as radiators, stoves, or other products that produce heat.
Leave a comfortable gap between this product and all other
electronics in your Home Theater system.
LocatIon
This product should be installed in a stable location.
poWer-corD protectIon
Power-supply cords should not be stepped on or pinched by
items placed upon or against them. Pay particular attention
to cords at plugs and the point where they exit from the
product.
oVerLoaDInG
Do not overload wall outlets, extension cords, or power strips
as this can result in a risk of fire or electric shock.
poWer SourceS
This product should be operated only from the type of power
source indicated on the label. If you are not sure of the
type of power supply to your home consult your local power
company.
nonuSe perIoDS
The power cord should be unplugged from the outlet when
left un-used for a long period of time.
LiGHtnInG
For extra protection during a lightning storm or when the
product is left unattended and unused for long periods of
time, unplug the power cord. This will prevent damage due to
lightning and power surges.
rothaudio.co.uk | 3
USER MANUAL
enGLISH
Proper disposal of this product. This label indicates that,
in the EU, electronic devices cannot be disposed of
with regular household waste. Please use the return or
collections systems of your municipality or contact the
seller where you purchased this product
WIrInG InStructIonS
The supply cable will be either 2-core or 3-core. Follow the
appropriate wiring instructions given below. In both cases
ensure that the outer sheath of the cable is firmly held by the
cable clamp.
SerVIcInG
Do not attempt to service this product yourself as opening the
product may expose you to electric shock, or the product may
be damaged. Refer all sell/icing to qualified service personnel.
DamaGe reQuIrInG SerVIce
Unplug this product from the wall outlet and contact a
qualified service personnel under the following conditions:
• Whenthepower-supplycordorplugisdamaged.
• Ifliquidhasbeenspilled,orobjectshavefallenintothe
product.
• Iftheproducthasbeenexposedtorainorwater.
• Iftheproductdoesnotoperatenormallyfollowingthe
instructions in this manual.
• Iftheproducthasbeendroppedordamagedinanyway.
• Whentheproductexhibitsadistinctchangein
performance.
eLectrIcaL InformatIon
This system is fitted with a BS1363/A 13 amp plug. If it
is not suitable for your supply sockets it must be removed
and replaced with an appropriate plug. If the plug becomes
damaged and/or needs to be replaced please follow the wiring
instructions below. The plug removed must be disposed of
immediately. It must not be plugged into a supply socket as
this will be an electrical hazard. If the fuse needs to be replaced
it must be of the same rating and ASTA approved to BS1362.
If the plug is changed, a fuse of the appropriate rating must
be fitted in the plug, adapter or at the distribution board. If
the fuse in a moulded plug is replaced, the fuse cover must be
refitted before the appliance can be used.
to prevent the risk of electric shock.
do not open this product.
no user- serviceable parts inside.
refer servicing to qualified service personnel.
risk of electric shock
do not open
Caution
CAUTION To prevent electric shock do not plug a cable
into a wall outlet, extension cord, or other recepticle unless the
metal blades can be fully inserted to prevent blade exposure.
2 - core pLuG
WarnInG!
Do not connect either wire to the earth terminal.
This symbol indicates that this 2-core appliance is Class II and does
not require an earth connection. The wire coloured blue must be
connected to the terminal marked with the letter N or coloured black. The
wire coloured brown must be connected to the terminal marked with the
letter L or coloured red.
Blue
(Neutral)
Fuse
Brown
(Live)
3 - core pLuG
The wire coloured green and yellow must be connected to the terminal
marked with the letter E, or by the earth symbol or coloured green or
green and yellow. The wire coloured blue must be connected to the terminal
marked with the letter N or coloured black. The wire coloured brown must be
connected to the terminal marked with the letter L or coloured red.
Blue
(Neutral)
Fuse
Brown
(Live)
Green &
Yellow
(Earth)
WarnInG! This appliance must be earthed.
