Oldal 1/25
42” to 90”
TV WALL MOUNT
RF-TVLFMA
INSTALLATION GUIDE
Safety information and specifications......................2
Tools needed......................................................................2
Package contents.............................................................3
Installation instructions .................................................5
For wood-stud and concrete
wall installations
Before using your new product, please read these instructions to prevent any damage.
2Need help? Call 1-800-620-2790 (U.S. and Canada)
Safety information and specifications
IMPORTANT
SAFETY
INSTRUCTIONS
- SAVE THESE
INSTRUCTIONS
CAUTION: Do not use this
product for any purpose not
explicitly specified by
Rocketfish.
Improper installation may
cause property damage or
personal injury. If you do
not understand these
directions, or have doubts
about the safety of the
installation, contact Customer Service or call a qualified contractor. Rocketfish is not
responsible for damage or injury caused by incorrect installation or use.
The weight of your TV must not exceed 125 lbs. (56.6 kg). The wall must be
capable of supporting five times the weight of your TV and wall mount
combined.
This product contains small items that could be a choking hazard if
swallowed. Keep these items away from young children!
Tools needed
You will need the following tools to assemble your new TV wall mount:
Maximum TV weight: 125 lbs. (56.6 kg)
Screen size: 42" to 90" diagonal
Overall dimensions (H × W × D):
17.7 x 29.3 x 2.7 in. (450 x 743.8 x 69 mm)
Wall mount weight: 28 lbs. (12.7 kg)
We’re here for you
www.rocketfishproducts.com
For customer service, call:
1-800-620-2790 (U.S. and Canada)
Edge-to-edge
stud finder
Pencil Level
Phillips screwdriver
Socket wrench with
1/2 in. (13 mm) socket
or adjustable wrench
Measuring tape
Drill
Tape
Hammer
7/32 in. (5.5 mm) wood drill
bit for wood stud wall
OR
3/8 in. (10 mm) masonry drill
bit (concrete only)
Awl
3
Need help? Call 1-800-620-2790 (U.S. and Canada)
RF-TVLFMA
Package contents
Make sure that you have all the hardware necessary to assemble your new TV wall
mount:
2 Horizontal TV
brackets (Qty. 2)
5 Wall plate (Qty. 1)
3 Template (Qty. 1)
1 Vertical TV
bracket (Qty. 1)
4 Arm assembly (Qty. 1)
