Oldal 1/8
CSIW SUB10
OWNER’S GUIDE
www.psbspeakers.com
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance
with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-
type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong
are provided for your safety. If the provided plug does not fit
into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused
for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
15. The apparatus shall not be exposed to dripping or splashing
and that no objects filled with liquids, such as vases, shall be
placed on the apparatus.
16. WARNING: To reduce the risk of fire or electric shock, this
apparatus should not be exposed to rain or moisture.
17. The mains plug or an appliance coupler is used as the
disconnect device, the disconnect device shall remain readily
operable.
The lightning flash with arrowhead symbol within an
equilateral triangle, is intended to alert you to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle
is intended to alert you to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
Notice of FCC Compliance
Warning: Changes or modifications to this unit not expressly
approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio TV technician for help.
Notes on environmental protection
At the end of its useful life, this product must not be
disposed of with regular household waste but must
be returned to a collection point for the recycling of
electrical and electronic equipment. The symbol on the
product, user’s manual and packaging, point this out.
The materials can be reused in accordance with their
markings. Through re-use, recycling of raw materials,
or other forms of recycling of old products, you are
making an important contribution to the protection of
our environment.
Your local administrative office can advise you of the
responsible waste disposal point.
Introduction
PSB subwoofers are designed to provide the flattest possible frequency response, full bass extension, low distortion and high output.
Beyond these characteristics there are a few other parameters that we feel are very important in the design of a subwoofer.
The CSIW SUB10 is an in-wall subwoofer which is designed for new frame and drywall construction.
The installation is a two stage process:
1. Pre Drywall Stage
2. Post Drywall Stage
Required Items:
Step 1: Installing the subwoofer cabinet
For stud wall constructed on 16” centres
Stage 1 – Pre Drywall
The subwoofer cabinet is designed to fit between two adjacent studs on standard 16” (40cm) spacing. Attach Bracket A to the top and the
bottom of the subwoofer cabinet. Position the ends of the brackets outboard of the side of the cabinet to be even with the front panel of
the cabinet. Using appropriate wood screws, fasten the cabinet to the stud wall.
Installing the subwoofer cabinet on 16” centre studs
x4
