Használati útmutató Procare EF-3068

Procare Vezeték nélküli műsorvezető EF-3068

Olvassa el alább 📖 a magyar nyelvű használati útmutatót Procare EF-3068 (5 oldal) a Vezeték nélküli műsorvezető kategóriában. Ezt az útmutatót 12 ember találta hasznosnak és 2 felhasználó értékelte átlagosan 4.5 csillagra

Letöltés PDF
Oldal 1/5
English Version
EF-3068
EF-3068L
(With Laser Pointer)
English 01
PRODUCT SPECIFICATIONS:
DIMENSIONS: L 155 X W 100 X H 40 mm
INTRODUCTION:
eFlash is a palm-size device for holding office documents for presentation using a projector. The device replaces
the notebook computer for presentations outside of the office. The user creates and edits the presentation on
the desktop PC and then downloads the file into eFlash through a USB cable using the included software. Once
the presentation is downloaded, eFlash can be brought to the presentation site as a stand-alone device and
connected directly to the projector. eFlash holds multiple presentation files up to 256 MB (about 5000 pages of
graphics).
Packaging List:
1 Main body
1 Battery case
1 Remote control
1 Soft protective pouch
1 USB cable
1 S-video cable
1 Pak2Go software CD ( instruction manual
included )
One 3V-CR2025 battery for EF-3068 or three
1.5V-LR44 batteries for EF-3068L included.
Packaging List:
Trademarks appearing in the following pages are properties of their respective owners.
1 2 3 4 5 6 1. S-video connector
2. Remote control bay
3. IR receiver window
4. SD card slot
5. Status indicators
6. USB B-type socket
PRODUCT CONSTRUCTION:
EF-3068 BODY PARTS:
BATTERY CASE:
REMOTE CONTROL:
USB SOCKET / POWER JACK:
Battery Installation:
Remove the battery cap and insert
four AA (1.5V) batteries. Please make
sure the batteries are inserted correctly
and the battery cap is put back into
position securely.
Please make sure the power switch is
turned to the "ON" position when in
use.
1. Power switch (On & Off)
2. USB power plug
3. Battery cap
(Front) (Back)
Four AA batteries not included.
1 2 3
Remote Control Battery Installation:
EF-3068: One 3V-CR2025 battery
EF-3068L: Three 1.5V-LR44 batteries
Remove the battery cap on the remote control and insert
the required batteries. Remove batteries from their plastic
wrapping. Please make sure the batteries are inserted
correctly and the battery cap is put back into position
securely.
1. Laser pointer button(EF-3068L model only)
2. IR transmitter
3. Laser diode(EF-3068L model only)
4. Remote control battery lock
5. LR44 battery -
6. Remote control battery cap
7. LR44 battery +
8. 1.5V-LR44 batteries
9. CR2025 battery + up
10. 3V-CR2025 battery
1 2 3 4 5 6 7 8 9 10
EF-3068L (Back)(Front) EF-3068 (Back)
Connecting the EF-3068 Main
Unit with Battery Case:
Insert the USB connector on the
battery case into the USB socket
on the main unit. Please make
sure it is securely inserted.
1. Triple adapter
USB socket
Power adapter
Battery connector
2. Power plug
1 2
English 02
1. CD-Rom 2. S-video connector 3. IR receiver window
4. SD card slot
DOWNLOAD FILES FROM PC ONTO SD MEMORY CARD:
SOFTWARE INSTALLATION:
CONNECTING eFlash:
1432
Visit http://www.IAdea.com/iFlash/Procare_eFlash/ for the latest software updates.
For first-time usage, install the software on the enclosed CD-Rom Disc.
Plug your eFlash into your computer. You should see a new storage device representing eFlash.
English 03
Install the software provided on the enclosed CD-
Rom Disc, Microsoft Windows XP or 2000 is
recommended. A parallel port hardware is
required for Windows 98 and ME. Most functions
will work on Windows 98 and ME as well.
Insert the SD card into the slot on the main unit.
Then plug the square-end of the USB cable into
the main unit.
Plug flat-end of the USB cable into your computer.
eFlash appears as a disc drive in Windows
Explorer.
