Industrial 2-channel
Optical Fiber Bypass Switch
IFB-244 Series
User’s Manual
Table of Contents
1. Package Contents ...................................................................... 3
2. Product Features ....................................................................... 4
3. ProductSpecications ................................................................ 5
4 Hardware Introduction ............................................................... 7
4.1 Three-View Diagram............................................................ 7
4.2 LEDDenition ...................................................................10
4.3 Wiring the Power Inputs .....................................................10
5. Hardware Installation ................................................................12
5.1 DIN-rail Mounting Installation .............................................12
5.2 Wall-mount Plate Mounting .................................................12
5.3 Side Wall-mount Plate Mounting ..........................................13
6. Optical Fiber and Power Connections ..........................................14
6.1 Optical Fiber Connection .....................................................14
6.2 Power Connection ..............................................................16
6.3 Recovering Communication from Power Failure .....................16
Customer Support ..........................................................................19
3
1. Package Contents
Thank you for purchasing PLANET Industrial 2-channel Optical Fiber
Bypass Switch, IFB-244 Series. In the following section, the term
“Optical Bypass Switch means the IFB-244 Series.
The descriptions of these models are as follows:
Models Optic Connectors Optic Mode Optic Wavelength
IFB-244-SLC 4 x Duplex LC Single Mode 1310nm & 1550nm
IFB-244-SSC 4 x Duplex SC
IFB-244-MLC 4 x Duplex LC
Multimode 850nm & 1300nm
IFB-244-MSC 4 x Duplex SC
Open the box of the Optical Bypass Switch and carefully unpack it. The
box should contain the following items:
Optical Bypass Switch x 1 User’s Manual x 1
DIN-rail Kit Wall-mount Kit
If any of these are missing or damaged, please contact your dealer
immediately; if possible, retain the carton including the original packing
material, and use them again to repack the product in case there is a
need to return it to us for repair.
