DT44 | DT88 EXPANSION CARD
1English
INTRODUCTION
The DT44 and DT88 are Asystems’ Dante
expansion cards for their digital matrix systems.
This allows for either 4x4 or 8x8 audio networking
with any other Dante-enabled Asystems product.
The DT44 and DT88 are compatible with the
Asystems DMP8800, DMP808, DMA8825,
DMA8813, DMA8425, DMA8813, NT2508,
NT2504, NT1308, NT1304 or NT4004.
Use this expansion card only with appropriate
Asystems models. Using third party hardware
could be detrimental to the operation of the
product.
DANTE CONTROL SOFTWARE
To effectively route signals through your DT
expansion card and your Aystems product,
Asystems suggests installation of the Dante
Controller routing software. This is available for
free on the Audinate website.
https://www.audinate.com/products/software/
dante-controller
Software is compatible with Windows 7, Windows
8.1 and Windows 10. It is also compatible with
Apple OSX 10.10.5, OSX 10.11.6 and macOS
10.12.
Extensive user documentation and tutorial videos
can be found on Audinate’s site to help explain
how the Dante Controller software operates.
For information on routing through the Asystems
product, refer to your product’s user guide.
INSTALLATION
Ensure the power cable is not connected to the
device when installing the DT expansion card.
This ensures there are no live components in the
device that could result in electric shock. If unsure,
consult a qualied engineer for installation.
1. Loosen the two screws and remove the cover
plate.
2. Connect the DT44 or DT88 Dante Networking
card.
3. Tighten the two screws back to secure the
cover plate.
DT44 | DT88
EXPANSION CARD
SAFETY WARNINGS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions provided in this document.
5. Do not use this apparatus near water or in
locations where condensation may occur.
6. Do not submerge in water.
7. Clean only with dry cloth. Do not use aerosol or
liquid cleaners. Unplug before cleaning.
8. Do not block any of the ventilation openings.
Install in accordance with the manufacturer’s
instructions.
9. Do not install near any heat sources such
as radiators, head registers, stoves, or other
apparatus (including ampliers) that produce heat.
10. Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A
grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong
is provided for your safety. If the provided plug
does not t into your outlet, consult an electrician
for replacement of the obsolete outlet.
11. Protect the power cord from being walked
on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
12. Only use attachments/accessories specied
by the manufacturer.
13. Unplug this apparatus during lightning storms
or when unused for long periods of time.
14. Refer all servicing to qualied service
personnel. Servicing is required when the
apparatus has been damaged in any way, such
as power-supply cord or plug damage, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operation normally, or
has been dropped.
15. Do not unplug the apparatus by pulling on the
cord; use the plug.
16. Adhere to all applicable, local codes.
17. Consult a licensed professional when any
question arise regarding installation of the
apparatus.
18. No naked ame sources, such as lighted
candles, should be placed on the apparatus.
19. This apparatus is for professional use only.
