PAL300CHF

300 Litre Chest Freezer

INSTALLATION INSTRUCTIONS

Before Using Your Freezer

• Remove the exterior and interior packing.

• Check to be sure you have all of the following parts:

 2 s Storage Basket

 1 Instruction Manual

 1 Plastic Scraper

• Before connecting the freezer to the power source, let it stand upright for approximately 2

hours. This will reduce the possibility of a malfunction in the cooling system from handling

during transportation.

• Clean the interior surface with lukewarm water using a soft cloth.

Installing Your Freezer

• -This appliance is designed to be free standing only, and should not be recessed or built

in.

• Place your freezer on a floor that is strong enough to support the freezer when it is fully

loaded.

• Allow 15 cm of space between the back and sides of the freezer, which allows the proper

air circulation.

• Locate the freezer away from direct sunlight and sources of heat (stove, heater, radiator,

etc.). Direct sunlight may affect the acrylic coating and heat sources may increase

electrical consumption. Extreme cold ambient temperatures may also cause the freezer

not to perform properly.

• Avoid locating the freezer in moist areas.

• -Plug the freezer into an exclusive, properly installed grounded wall outlet. Do not under

any circumstances cut or remove the third (ground) prong from the power cord. Any

questions concerning power and/or grounding should be directed toward a certified

electrician or an authorized service center.

• After plugging the appliance into a wall outlet, allow the unit to cool down for 2~3 hours

before placing food in the freezer compartment.

Electrical Connection

For your safety please read the following information

OPERATING YOUR FREEZER

Temperature Control

• Your freezer has one control for regulating the temperature. The temperature control is

located on the lower right hand corner.

• The range of the temperature control is from position" 1" the warmest to "6" the coldest.

Adjust the temperature control to the setting that best suits your needs. The setting of “4”

should be appropriate for home or office freezer use.

• To turn the freezer off, turn the temperature control to "OFF".

NOTE:

• Turning the temperature control to "OFF" position stops the cooling cycle but does not

shut off the power to the freezer.

• If the unit is unplugged, lost power, or turned off; you must wait 3 to 5 minutes before

• R estarting the unit. If you attempt to restart before this time delay, the freezer will not

start.

• Large amounts of food will lower the cooling efficiency of the appliance.

• If you choose to change the thermostat setting, adjust thermostat control by one

numerical increment at a time. Allow several hours for temperature to stabilize between

adjustments.

Defrosting Your Freezer

• When? For the most efficient operation and minimum energy consumption, defrost

the freezer when the frost on the freezer walls is excessive or 5 to 10 mm thick.

• Choose a time when the stock of frozen food is low.

CAUTION

Do not use boiling water because it may damage the plastic parts. In addition, never

use a sharp or metallic instrument to remove frost as it may damage the cooling coils

and will void the warranty. We recommend using the plastic scraper provided with

your unit.

• Remove the frozen food from the freezer and place it in a cooler to protect the food.

• Turn the thermostat knob to “OFF”.

• Unplug the freezer. The Power Supply light should be off (green light out).

• During defrosting, the ice melts into the cabinet.

• Remove the drain plug on the inside floor of the freezer by pulling straight out.

• Place a shallow pan outside drain outlet. The defrost water will drain out.

• Check the pan occasionally so the water does not overflow.

• Clean the interior of the freezer.

• Replace the plug on the inside floor.

• Reset the thermostat to desired setting.

• Allow the cabinet to cool for one hour.

• Return food to the freezer.

HELPFUL HINT:

Defrosting usually takes a few hours. Leaving the door open will help speed the

process. Also, pouring warm water (not boiling) on the ice/frost will help speed

melting. If you must use a scraper please use caution it is very easy to damage the - -

freezer compartment and void your warranty.

The Freezer Compartment

• - This compartment is designed for the long term storage of frozen food. Storage time is

up to three months.

• The storage life of frozen foods varies and the recommended storage time should not be

exceeded. The instructions regarding the care of frozen foods should be followed when

defrosting the freezer.

• -Pre packed commercially frozen food should be stored in accordance with the frozen

foods manufacturer’s instructions for a three star frozen food storage compartment or

home freezer.

• Place frozen food into the freezer as quickly as possible after purchase. If there are

instructions on the packet, carefully follow these instructions regarding storage times.

• The freezer door is susceptible to breaking due to excessive ice build up. Be sure to

defrost when the ice reaches 5 to 10 mm thick.

• -A storage basket is provided for the organization of odd shaped items. To reach other

packages in the freezer, just slide the basket to one side, or lift it out.

CARE AND MAINTENANCE

Cleaning Your Freezer

• Upon installation of your new appliance, it is recommended that it be cleaned thoroughly.

• Turn the temperature control to "OFF", unplug the freezer, remove the food and storage

basket.
