Single Channel DC Power Supply
Programming Manual
www.owon.com
i
Table of Contents
Introduction to the SCPI Language ............................................................................................... 1
Syntax ......................................................................................................................................... 1
Syntax Rules 1................................................................................................................................
Command Abbreviation .............................................................................................................. 2
Contact Us .................................................................................................................................. 3
Third-party API ............................................................................................................................ 3
IEEE488.2 Common Commands 4.........................................................................................................
*IDN? ................................................................................................................................... 4
*RST ..................................................................................................................................... 4
SCPI Commands 5..................................................................................................................................
Measurement Commands 5...........................................................................................................
MEASure:VOLTage? ............................................................................................................. 5
MEASure:CURRent? ............................................................................................................ 5
MEASure:POWer? ............................................................................................................... 6
MEASure[:SCALar]:ALL[:DC]? .............................................................................................. 6
MEASure[:SCALar]:ALL[:DC]:INFO? ..................................................................................... 6
Output Setup Commands ........................................................................................................... 7
OUTPut ................................................................................................................................ 7
CURRent .............................................................................................................................. 8
CURRent:LIMit ..................................................................................................................... 8
VOLTage ............................................................................................................................... 9
VOLTage:LIMit 9.....................................................................................................................
System control Commands ....................................................................................................... 10
SYSTem:LOCal .................................................................................................................... 10
SYSTem:REMote ................................................................................................................ 10
1
Introduction to the SCPI Language
Syntax
SCPI commands present a hierarchical tree structure and contain multiple sub-systems, each of
which is made up of a root keyword and one or more sub-keywords. The command string
usually starts with ":", the keywords are separated by ": and are followed by the parameter "
settings available, "?" is added at the end of the command string to indicate query and the
command and parameter are separated by "space".
For example,
VOLTage:LIMit <value>
VOLTage:LIMit?
VOLTage is the root keyword of the command. the second-level keywords. The LIMit is
command string starts with " " which separates the multiple-level keywords. : <value>
represents parameters available for setting, " " represents query and the command ?
VOLTage:LIMit and the parameter are separated by "space".<value>
Syntax Rules
SCPI language itself defines a group of sub-system keywords, and at the same time allows users
to add or reduce keywords. Those keywords can be some meaningful English words and are easy
to remember, which are called mnemonics. Mnemonic has long and short types. The short are
the abbreviation of the long.
➢ Rule to format mnemonics:
1) If the letter number of an English word is less than or equal to 4, then the word itself can be
the mnemonic.(such as "Free" can be "FREE")
2) If the letter number of an English word exceeds 4, then the first four letters will be the
mnemonic.(such as "Frequency" can be "FREQ")
3) If the forth letter is vowel, then mnemonic uses the former three letters. Vowels consists of
a, e, i, o, and u.(such as "Power" can be "POW")
4) If it is not a word but a sentence, then use the first letters of the former words and the
whole of the last word. (such as "Input Voltage" can be "IVOLtage")
➢ Usage of symbols
1) Space
The space is used to separate command and parameter.
2) Colon :
