Personal 2 plus
Thank you for choosing a Meliconi remote control.
The Personal 2 plus remote control is designed to command digital television sets. a LG
Its ergonomic shape and soft rubber body make it easy to grip and protect it from shocks and drops.
By LEARN function, you can capture and store infrared signals from other remotes and match at will to one or more buttons.
The MELICONI remote control reproduces infrared signals corresponding to the original; the functions that operate in radio
frequency (e.g. voice commands and pointers) are not supported.
The remote control has a permanent memory, so it does not lose its settings even if there are no batteries in it.
The remote control requires 2 new 1.5V alkaline batteries, not included in the AAA/LR03
package. Insert with the correct polarity as shown in gure.
DO NOT use batteries. rechargeable
BATTERIES TEST: Press and hold the 5 button and check that the LED remains on
continuously until the button is released. If the light is o or blinks, the inserted batteries are low,
therefore they need replacement.
If necessary it is possible to reset the remote control and bring it back to the initial conditions. completely
WARNING : All user settings will be lost. Operate as follows:
• On the MELICONI remote control press and hold the button until the LED lights up; release.
• Enter the code . 0100
• Three nal ashes indicate that the operation has been completed successfully.
RESET THE REMOTE CONTROL
Do not leave exhausted batteries inserted, as liquid may leak and damage the remote control
INSERTING THE BATTERIES
SAFETY WARNINGS
The remote control and batteries should not be exposed to excessive heat such as sunlight, re
or the like.
The product . Keep out of reach of children or domestic animals. is not a toy
This remote control, after inserting the batteries, is normally ready for use as it is already set at the
factory with a specic code.
Keep this booklet for future reference
Remote control for TV sets ready e LG to us
The Personal 2 plus remote control is equipped with Learn technology that can acquire and memorise signals from other
infrared remote controls. This feature is particularly useful in several cases.
To add or change a function connected to a button on the MELICONI remote control.
Having activated the remote control and checked it is working correctly, you may need to add or replace a function on one
of the MELICONI remote control buttons with another function you consider to be handier or more frequently used.
Assign some functions to some buttons to control other devices (example: volume +/- SOUNDBAR).
The Personal 2 plus remote control can learn up to a maximum of signals ming from various original remote controls 10 co
and connect at will to the desired buttons.
Signals can also be learnt and set on all the buttons on the MELICONI remote control, except e button; obviously the th
preset functions are lost, but they can be restored by the REMOTE CONTROL RESET procedure.
The Learn operation can be repeated numerous times, and the signals captured are kept in the memory even if the batteries
are removed or go at.
● POSITIONING THE REMOTE CONTROLS CORRECTLY.
• Check that the batteries in both remote controls (the original and the MELICONI remote) are fully
charged; if semi-charged batteries are used the signal acquisition procedure may prove dicult
or fail completely.
• Position the original remote control in front of the MELICONI remote control so the areas which
emit the infrared signals are opposite each other at a distance of approximately 2 cm.
• On the MELICONI remote control press for a moment the button.
• Within 30 seconds, press and hold down one of the buttons on the original remote control; the
LED on the MELICONI remote control should start ashing; if it doesn't, move the remote
controls closer together.
• Gradually move the original remote control away, making sure the two remotes stay aligned,
until the point at which the LED stops ashing; then move the remote control to half the previous
distance and keep both remotes in this position until the process has terminated.
● CAPTURING SIGNALS.
• On the MELICONI remote control press and hold the button until the LED lights up; release.
• Press the button again briey and immediately press for a moment the button to which to combine the capture signal.
• Press the button on the original remote to be captured, hold it down until the LED goes out and then release it.
IMPORTANT If after releasing the button the LED comes back on, press the same button again until the LED goes out :
once more.
• When the signal has been captured correctly the LED will produce three nal ashes.
To capture other signals to connect to other buttons, repeat the procedure described above.
Reached the number of records available, the dedicated memory becomes full, preventing further use.
To free memory use one of the following procedures in relation to the data that you want to delete:
• DELETE FUNCTION BY SINGLE BUTTON
• RESET THE REMOTE CONTROL
If you want to delete the function in combination with a single button, operate as follows:
• On the MELICONI remote control press and hold the button.
• When the LED turn on enter the code ; release the buttons. , without releasing the button, 1600
• Within 30 seconds, press and hold the button of which you want to delete the function; wait three ashes indicating the end
of the operation, release the button. (to recall the original function RESET THE REMOTE CONTROL)
LEARN FUNCTION
watch
the video
The functions of the buttons on the MELICONI remote control are only available if the original device is equipped with it.
Sometimes some functions of the original remote control are not directly present on the MELICONI remote control keypad.
To them, connect to the page, use the on- tool BUTTONS AND FUNCTIONS and continue until you enable www.cme.it line
see the list matching buttons between the original remote control and the MELICONI remote control.
To obtain some functions, press and hold the button and press the corresponding key indicated in the table.
If the function you want to play is matched with an number i color, operate as follows: n orange
• On the MELICONI remote control press and hold the button.
• When the LED turn on , point the remote control towards the device , without releasing the button
and enter the previously identied number corresponding to the function you want to get. (at the last digit
pressure, the remote control already transmits this function)
• Release the buttons; to match the function obtained to a MELICONI remote control button, within 30
seconds, press and hold the desired button.
• Wait three flashes indicate that storage; release the button. (the used button loses the original function
that will be called by the REMOTE CONTROL RESET procedure)
● THE REMOTE CONTROL IS NEW AND YOU CAN NOT MAKE IT WORK IF
Check that you have carried out all the settings procedures correctly. If necessary repeat them, following all the steps
indicated carefully or contact the ASSISTANCE. ,
● IF THE REMOTE CONTROL IS NO LONGER ABLE TO CONTROL THE DEVICE
Disconnect the device from the electric socket and leave it without power for a few minutes; switch the device on again.
Remove the batteries from the remote control, press the butto twice and insert NEW batteries. ON/OFF n
Make sure that the remote control is pointing at the device without any obstacles between them.
If necessary try to the RESET THE REMOTE CONTROL.
● IF SOME FUNCTIONS ARE NOT AVAILABLE ON THE REMOTE CONTROL
Sometimes some functions of the original remote control are not directly present on the MELICONI remote control keypad.
To enable them, operate as described in the BUTTONS AND FUNCTIONS chapter.
● HOW TO CHECK IF THE REMOTE CONTROL SENDS INFRARED SIGNALS
The human eye is not able to detect infrared signals; use a camera (even that of the mobile phone).
Aim the infrared LED located in front of the remote control (not the red LED above) and press and hold on the remote control
the button. 5
If you see through the camera, the LED light with short white / light blue ashes means that the remote control works and
emits infrared.
web: e-mail: www.cme.it telecomandi@meliconi.com
IMPORTANT! To obtain technical assistance, it is essential to indicate the BRAND and MODEL of the appliance you intend
to control and the name of the MELICONI remote control you are using.
ASSISTANCE
ATTENTION!
Most problems are caused by using insuciently charged batteries.
We recommend checking and replace them as shown in the INSERTING THE BATTERIES chapter.
TROUBLESHOOTING (F.A.Q.)
BUTTONS AND FUNCTIONS
